Presentation Transcript
slide1

IXP Innovation in Ontario: Leveraging Network Peering as Value in CollaborationOUCC2014April 28, 2014

Michael Studniberg

Ministry of Research and Innovation

Ministry of Economic Development Trade and Employment

Randy LaFramboise

Centre for Smart Community Innovation (CSCI)

University of Windsor

agenda
Agenda
  • Introduction
  • Background
  • What is an IXP?
  • Benefits of Peering
  • IT Perspective
  • IXPs in Canada and around the World
  • IXPs and Post-Secondary Institutions
  • A new IXP in Windsor
  • Other new IXPs in Ontario

Ministry of Economic Development, Trade and Employment Ministry of Research and Innovation

government of ontario e business and entrepreneurship
Government of OntarioE-Business and Entrepreneurship
  • Promote the adoption of e-business and access to ultra-fast broadband connectivity by Ontario’s small and medium enterprises.
  • Enable them to improve their efficiencies, increase collaboration and market their goods to a global economy.

Ministry of Economic Development, Trade and Employment Ministry of Research and Innovation

government of ontario basic broadband programs
Government of OntarioBasic Broadband Programs
  • Broadband programs in Ontario:
    • Rural Connections
    • Building Broadband in Rural and Northern Ontario
    • Eastern Ontario Regional Network (EORN)
    • Northwestern Ontario Broadband Expansion Initiative
  • These will all be completed by the end of 2014
  • Since 2007, Ontario invested $170 million and leveraged more than $300 million of private and federal funding to provide high-speed broadband service of at least 1.5 Megabits per second (Mbps)

Ministry of Economic Development, Trade and Employment Ministry of Research and Innovation

canadian context urban v rural
Canadian Context – Urban v. Rural

Close to 100% HH in communities get over 1.5 Mbps, but many rural HH rely on cellular.

Close to 40% HH in communities can get 100 Mbps

Rural areas have much slower speeds.

Source: CRTC Communications Monitoring Report 2013

Ministry of Economic Development, Trade and Employment Ministry of Research and Innovation

slide6
Broadband Conduit CorridorsPercentage of customer connections that are fibre-to-the-home or fibre-to-the-building
  • Canada ranks 24th on the list at 2%
  • Canada is well behind other developed nations such as the USA and the UK

Percentage of fibre connections – June 2013 - OECD broadband statistics [www.oecd.org/sti/ict/broadband]

Ministry of Economic Development, Trade and Employment Ministry of Research and Innovation

the role of government in telecom
The Role of Government in Telecom
  • Encourage and promote competition
  • Government is a large consumer of telecom services
  • Telecom infrastructure runs in government-owned property through rights-of-way
  • Telecom is regulated by the federal government (CRTC)
  • Many telcos in Ontario are publically-owned
  • Broadband is increasingly viewed as an essential service
  • Government services are increasingly offered online
  • Government should ensure equitable access to ultra-fast broadband

Ministry of Economic Development, Trade and Employment Ministry of Research and Innovation

centre for smart community innovation wednet
Centre for Smart Community Innovation - WEDnet
  • WEDnet was created in November 1994 to create a high-speed communications infrastructure in the Windsor-Essex region
  • By 1996, a consortium was formed that looked for similar interest in high-speed infrastructure. This was leveraged cooperatively, and today we have 10 Gigabit core throughput to ORION and by extension, CANARIE
  • WEDnet is part of Connecting Windsor-Essex (CWE), and the Centre for Smart Community Innovation has been mandated to support the network and its related activities
  • WEDnet today is a Regional Advanced Network (RAN) that depends on regional collaboration, both public and private sector, for Intelligent Community initiatives and innovation

Ministry of Economic Development, Trade and Employment Ministry of Research and Innovation

csci communities and internet
CSCI – Communities and Internet

"Intelligent Communities leverage information and communications technology to improve the quality of life of their residents - in the delivery of education, health care and government services."

[From http://www1.uwindsor.ca/csci/]

"Cisco defines the Internet of Everything (IoE) as bringing together people, process, data, and things to make networked connections more relevant and valuable than ever before-turning information into actions that create new capabilities, richer experiences, and unprecedented economic opportunity for businesses, individuals, and countries."

[From http://www.cisco.com/web/about/ac79/innov/IoE.html]

Ministry of Economic Development, Trade and Employment Ministry of Research and Innovation

growth in canadian internet traffic
Growth in Canadian Internet Traffic

23% annual growth

  • Exponential growth in traffic will require Ontario’s telcos to make on-going capital investments
  • Sources:
  • CRTC Report: Navigating Convergence II: Charting Canadian Communications Change and Regulatory Implications. Convergence Policy, Policy Development and Research. August 2011
  • Cisco Visual Networking Index: Forecast and Methodology, 2012-2017.
  • 1 Petabyte (PB) = 1,000,000 Gigabytes

Ministry of Economic Development, Trade and Employment Ministry of Research and Innovation

what is an internet exchange point
What is an Internet Exchange Point?
  • Neutral facility where multiple organizations can inter-connect their networks through a central switching fabric
  • Share data with each other without using the public Internet
    • Directly sharing data is called ‘peering’
    • Peering is the alternative to ‘transit’

Ministry of Economic Development, Trade and Employment Ministry of Research and Innovation

who peers at an ixp
Who Peers at an IXP?
  • Historically, most peers were ISPs or RANs
  • Now:
    • digital media firms, broadcasters, software development companies including gaming companies, web hosting firms, content delivery networks, large enterprises, public sector organizations, and many more!

Ministry of Economic Development, Trade and Employment Ministry of Research and Innovation

how transit works
How Transit Works

All organizations are in the same city/region

Small Company

$

ISP

$

Internet

LargeEnterprise

$

$

ISP

Website Hosting Company

$

Ministry of Economic Development, Trade and Employment Ministry of Research and Innovation

how transit works1
How Transit Works

Small Company

$

ISP

$

Internet

LargeEnterprise

$

$

ISP

Website Hosting Company

$

Ministry of Economic Development, Trade and Employment Ministry of Research and Innovation

how transit works2
How Transit Works
  • Traffic may go through other cities or even other countries
  • Slow
  • Expensive
    • You pay your ISP
    • Your ISP pays another ISP for access to the global Internet
  • Shouldn’t local traffic stay local?

Ministry of Economic Development, Trade and Employment Ministry of Research and Innovation

how peering works
How Peering Works

Small Company

$

ISP

$

Internet

LargeEnterprise

$

$

IXP

ISP

Website Hosting Company

$

Ministry of Economic Development, Trade and Employment Ministry of Research and Innovation

how peering works1
How Peering Works
  • You join the IXP as a member and lease a circuit into the IXP facility
  • You set up peering agreements with other members (bilateral agreements)
  • Traffic destined for other peers goes through the IXP instead of the Internet

Ministry of Economic Development, Trade and Employment Ministry of Research and Innovation

peering vs transit
Peering vs Transit
  • By peering, you lower the volume of traffic you send to the Internet via your ISP
  • Your connection to the IXP is a fixed cost
  • You don’t pay the other members to peer

Small Company

ISP

IXP

Ministry of Economic Development, Trade and Employment Ministry of Research and Innovation

peering vs transit1
Peering vs Transit
  • The goal is to peer sufficient traffic such that the savings realized from peering are greater than the cost of IXP membership

Small Company

ISP

IXP

Ministry of Economic Development, Trade and Employment Ministry of Research and Innovation

benefits of peering
Benefits of Peering
  • Improved quality of service
    • Packets arrive at their destination faster
    • Less chance of encountering congested links on the Internet
    • Important for streaming HD video and other real-time services
  • Local Google, Akamai, Netflix caches

Ministry of Economic Development, Trade and Employment Ministry of Research and Innovation

benefits of peering1
Benefits of Peering
  • Redundancy

Source:

Ministry of Economic Development, Trade and Employment Ministry of Research and Innovation

benefits of peering2
Benefits of Peering
  • Redundancy

Ministry of Economic Development, Trade and Employment Ministry of Research and Innovation

benefits of peering3
Benefits of Peering

Source: PCH for CIRA (2012) Toward Efficiencies in Canadian Internet Traffic Exchange

Ministry of Economic Development, Trade and Employment Ministry of Research and Innovation

benefits of peering4
Benefits of Peering
  • Transit group buying
    • Peers can band together to buy transit in bulk
    • Better transit unit price
    • Attract new ISPs to the city/region
    • Expected savings can be up to 50%

Source: Stanojevic, R, Castro, I, Gorinsky, S, CIPT: Using Tuangou to Reduce IP Transit Costs, ACM CoNext 2011, December 2011.

Ministry of Economic Development, Trade and Employment Ministry of Research and Innovation

benefits of peering5
Benefits of Peering
  • Economic development perspectives
    • Companies lower their operational expenses
      • Re-invest into expansion and new employees
    • Attract new companies to the region
    • Bolster city’s reputation

Ministry of Economic Development, Trade and Employment Ministry of Research and Innovation

it perspective
IT Perspective

ISP 1

ISP 2

ISP 1’s PR

ISP 2’s PR

Ethernet switch

ISP 4’s PR

ISP 3’s PR

ISP 4

ISP 3

IXP

Ministry of Economic Development, Trade and Employment Ministry of Research and Innovation

it perspective1
IT Perspective
  • Simple layer 2 architecture
    • Ethernet
      • Though ATM, frame relay, etc., IXPs do exist
    • Layer 3 IXPs exist (router-centric)
      • More work to setup and run
      • More expensive
      • More typical in for-profit ‘American model’ IXPs

Ministry of Economic Development, Trade and Employment Ministry of Research and Innovation

it perspective2
IT Perspective
  • Redundancy
    • Double up everything, especially the switch!

ISP 1’s PRs

ISP 2’s PRs

Ethernet switches

ISP 4’s PRs

ISP 3’s PRs

Ministry of Economic Development, Trade and Employment Ministry of Research and Innovation

28

it perspective3
IT Perspective
  • Value-added services
    • Attract new peers, improve business case

ISP 1’s PRs

ISP 2’s PRs

Ethernet switches

DNS

NTP

etc.

ISP 4’s PRs

ISP 3’s PRs

Ministry of Economic Development, Trade and Employment Ministry of Research and Innovation

29

ixps around the world
IXPs around the World

Source: TeleGeography’s Internet Exchange Map: http://www.internetexchangemap.com/

Ministry of Economic Development, Trade and Employment Ministry of Research and Innovation

ixps around the world1
IXPs around the World
  • There are approximately 400 exchange points around the world
  • Top 3:

Frankfurt

600+ peers

3,400 Gbps peak

Amsterdam

650 peers

2,700 Gbps peak

London

515 peers

2,000 Gbps peak

Ministry of Economic Development, Trade and Employment Ministry of Research and Innovation

ixps in canada
IXPs in Canada
  • There are eight IXPs in Canada
  • Five are not-for-profit entities

Toronto

100+ peers

146 Gbps peak

Ottawa

12 peers

900 Mbps daily max

Ministry of Economic Development, Trade and Employment Ministry of Research and Innovation

ixps in canada1
IXPs in Canada
  • Three new IXPs have launched in the last year!

YYCIX

Winnipeg

Calgary

Montréal

Ministry of Economic Development, Trade and Employment Ministry of Research and Innovation

ixps and post secondary institutions
IXPs and Post-Secondary Institutions
  • Internationally, IXPs have a long association with colleges and universities
    • This is not as common in North America
  • Peering and research opportunities
    • Bring the world "closer", while bringing local resources closer
  • Opportunities for the next generation of Internet leaders
  • The "Internet of Everything" means the participation of everyone to truly succeed
  • Post-secondary institutions bring together new ideas with exposure to what is working now

Ministry of Economic Development, Trade and Employment Ministry of Research and Innovation

ixps and post secondary institutions1
IXPs and Post-Secondary Institutions
  • Vienna Internet Exchange (VIX)
    • Provided and operated by the University of Vienna, Austria
    • Redundant dual sites
    • The VIX Network Operations Center service is exclusively provided by staff members of the University of Vienna Computer Center
  • Norwegian Internet Exchange (NIX)
    • Owned and operated by the Centre for Information Technology Services, University of Oslo

Ministry of Economic Development, Trade and Employment Ministry of Research and Innovation

ixps and post secondary institutions2
IXPs and Post-Secondary Institutions
  • Hong Kong Internet Exchange (HKIX)
    • Founded in 1995 by the Information Technology Services Centre of the Chinese University of Hong Kong
    • Its aim is to keep all HK’s traffic in HK
  • Singapore Open Exchange (SOX)
    • Hosted by the National University of Singapore

Ministry of Economic Development, Trade and Employment Ministry of Research and Innovation

ixps and post secondary institutions3
IXPs and Post-Secondary Institutions
  • Malawi Internet Exchange (MIX)
    • Hosted at College of Medicine, University of Malawi
    • Malawi Internet Service Providers' Association operates the IXP
    • The University was one of three co-founders

Ministry of Economic Development, Trade and Employment Ministry of Research and Innovation

a n ew ixp in windsor
ANew IXP in Windsor
  • MEDTE/MRI has been working with Windsor’s CSCI
  • Windsor is a suitable location for a new IXP
    • Windsor is a designated Intelligent Community (2011) by the Intelligent Community Forum
    • Most of Windsor’s Internet traffic must travel through Toronto, even if its destination is also in Windsor
    • Transit in the region is expensive compared to other urban areas
    • The region is transitioning away from its traditional manufacturing-sector past

Ministry of Economic Development, Trade and Employment Ministry of Research and Innovation

a new ixp in windsor
A New IXP in Windsor
  • An IXP in the Windsor-Essex region is the next logical step in enabling enhanced communication and participating in a global economy.
  • The "Internet of Everything" involves the participation of everybody.
  • The two quotes from earlier have this in common...quality of life, collaboration, improving economic circumstance and services. But the only way it starts is by communication...and by having the framework to achieve it...
  • Who should be involved? Anybody who leverages the Internet to do business!

Ministry of Economic Development, Trade and Employment Ministry of Research and Innovation

a n ew ixp in windsor1
ANew IXP in Windsor
  • Presented to CWE board of directors and won approval to proceed
  • Support from the local technology accelerator, WEtech Alliance, a member of the ONE, and from the Windsor-Essex Small Business Centre
  • Currently focused on raising awareness, outreach to industry, and securing funding for marketing and capital expenses

Ministry of Economic Development, Trade and Employment Ministry of Research and Innovation

current potential internet exchange points in ontario for discussion purposes only
Current & Potential Internet Exchange Points in OntarioFOR DISCUSSION PURPOSES ONLY

To

Thunder

Bay

QIX

Montreal

OTTIX

Ottawa

Sudbury-North Bay

Orillia-Barrie

TORIX

Toronto

London-Waterloo

Kingston

St Catharines

Draft for Discussion

41

To Chicago

Windsor

Ministry of Economic Development, Trade and Employment Ministry of Research and Innovation

To

New York

thank you
Thank you!

Michael Studniberg

Randy LaFramboise

Network and Systems SpecialistCentre for Smart Community Innovation (CSCI) - ITSUniversity of Windsor

R.Laframboise@uwindsor.ca

Senior Analyst Engineer

Government of Ontario

(416) 212-6176

michael.studniberg@ontario.ca

Ministry of Economic Development, Trade and Employment Ministry of Research and Innovation
