iterative context bounding for systematic testing of multithreaded programs

Iterative Context Bounding for Systematic Testing of Multithreaded Programs

Madan Musuvathi

Shaz Qadeer

Microsoft Research

testing multithreaded programs is hard
Testing multithreaded programs is HARD
  • Specific thread interleavings expose subtle errors
    • Testing often misses these errors
  • Even when found, errors are hard to debug
    • No repeatable trace
    • Source of the bug is far away from where it manifests
current practice
Current practice
  • Concurrency testing == Stress testing
  • Example: testing a concurrent queue
    • Create 100 threads performing queue operations
    • Run for days/weeks
    • Pepper the code with sleep( random() )
  • Stress increases the likelihood of rare interleavings
    • Makes any error found hard to debug
chess unit testing for concurrency
CHESS: Unit testing for concurrency
  • Example: testing a concurrent queue
    • Create 1 reader thread and 1 writer thread
    • Exhaustively try all thread interleavings
  • Run the test repeatedly on a specialized scheduler
  • Explore a different thread interleaving each time
    • Use model checking techniques to avoid redundancy
  • Check for assertions and deadlocks in every run
    • The error-trace is repeatable
state space explosion
State space explosion

Thread 1

Thread 2

x = 1;

y = 1;

x = 2;

y = 2;

Init state: x = 0, y = 0

0,0

2,0

1,0

x = 1;

1,0

2,2

1,1

2,0

y = 1;

x = 2;

1,2

1,2

2,1

2,1

1,1

2,2

y = 2;

1,2

1,1

1,1

2,1

2,2

2,2

state space explosion1
State space explosion
  • Number of executions

= O( nnk )

  • Exponential in both n and k
    • Typically: n < 10 k > 100
  • Limits scalability to large programs (large k)

Thread 1

Thread n

x = 1;

y = 1;

x = 2;

y = 2;

k steps

each

n threads

techniques
Techniques
  • Iterative context bounding
    • Strategy for searching large state spaces
  • State space optimization
    • Reduces the size of the state space
iterative context bounding
Iterative context bounding
  • Prioritize executions with small number of preemptions
  • Two kinds of context switches:
    • Preemptions – forced by the scheduler
      • e.g. Time-slice expiration
    • Non-preemptions – a thread voluntarily yields
      • e.g. Blocking on an unavailable lock, thread end

Thread 1

Thread 2

x = 1;

if (p != 0) {

x = p->f;

}

x = 1;

if (p != 0) {

p = 0;

preemption

x = p->f;

}

non-preemption

iterative context bounding algorithm
Iterative context-bounding algorithm
  • The scheduler has a budget of c preemptions
    • Nondeterministically choose the preemption points
  • Resort to non-preemptive scheduling after c preemptions
    • Run each thread to the next yield point
  • Once all executions explored with c preemptions
    • Try with c+1 preemptions
  • Iterative context-bounding has desirable properties
    • Property 0: Easy to implement
property 1 polynomial state space
Property 1: Polynomial state space
  • n threads, k steps each, c preemptions
  • Number of executions <= nkCc . (n+c)!

= O( (n2k)c. n! )

Exponential in n and c, but not in k

Thread 1

Thread 2

  • Choose c preemption points

x = 1;

y = 1;

x = 1;

x = 2;

y = 2;

x = 2;

  • Permute n+c atomic blocks

y = 1;

y = 2;

property 2 deep exploration possible with small bounds
Property 2: Deep exploration possible with small bounds
  • A context-bounded execution has unbounded depth
    • A thread may execute unbounded number of steps within each context
  • Can reach a terminating state from an arbitrary state with zero preemptions
    • Perform non-preemptive scheduling
    • Leave the number of non-preemptions unbounded
property 3 coverage metric
Property 3: Coverage metric
  • If search terminates with c preemptions,
    • any remaining error must require at least c+1 preemptions
  • Intuitive estimate for
    • the complexity of the bugs remaining in the program
    • the chance of their occurrence in practice
property 4 finds the simplest error trace
Property 4: Finds the ‘simplest’ error trace
  • Finds the smallest number of preemptions to the error
  • Number of preemptions better metric of error complexity than execution length
techniques1
Techniques
  • Iterative context-bounding
    • Strategy for searching large state spaces
  • State space optimization
optimization for race free programs
Insert context-switches only at synchronization points

Massive state-space reduction

Num steps (k) = num synch. operations (not memory accesses)

Run data-race detection to check race-free assumption

Goldilocks algorithm [PLDI ’07] implemented for x86

Theorem: When search terminates for context-bound c

Either find an erroneous execution

Or find a data-race

Or the program has no errors reachable with c preemptions

Optimization for race-free programs
conclusion
Conclusion
  • Iterative context-bounding algorithm
    • Effective search strategy for multi-threaded bugs
  • Exposes many concurrency bugs
  • Implemented in the CHESS model checking tool
    • Applying CHESS to Windows drivers, SQL, Cosmos, Singularity
  • Visit http://research.microsoft.com/projects/CHESS/
partial order reduction
Partial-order reduction
  • Many thread interleavings are equivalent
    • Accesses to separate memory locations by different threads can be reordered
  • Avoid exploring equivalent thread interleavings

T1: x := 1

T2: y := 2

T2: y := 2

T1: x := 1

optimistic dynamic partial order reduction
Optimistic dynamic partial-order reduction
  • Algorithm [Bruening ‘99] :
    • Assume the program is data-race free
    • Context switch only at synchronization points
    • Check for data-races in each execution
  • Theorem [Stoller ‘00] :
    • If the algorithm terminates without reporting races
    • Then the program has no assertion failures
  • Massive reduction:
    • k = number of synchronization accesses (not memory accesses)
combining with context bounding
Combining with context-bounding
  • Algorithm:
    • Assume the program is data-race free
    • Context switch only at synchronization points
    • Explore executions with c preemptions
    • Check for data-races in each execution
  • Theorem:
    • If the algorithm terminates without reporting races,
    • Then the program has no assertion failures reachable with c preemptions
      • Requires that a thread can block only at synchronization points
