Presentation Transcript
overview
SQL Server Architecture

SQL Server with SAP

Performance Monitoring and Tuning

Administration and Troubleshooting

Database Backup and Restore

Overview
cache and cpu tuning

+

Cache and CPU Tuning

?

Poor SQL

statements?

Tune poor

statements

Yes

No

2 * CPU idle

> CPU busy?

Cache hit ratio

> 95%?

Increase

CPUs forSQL Server

Yes

Yes

No

No

OS paging?

All CPUs available

for SQL Server?

No

No

Increase

server main

memory

Add CPU(s)

to server

Yes

Yes

database configuration
Database Configuration
  • affinity mask
  • awe enabled
  • cost threshold for parallelism
  • max degree of parallelism
  • fillfactor
  • index create memory
  • lightweight pooling
  • Locks / open objects / connections
  • Max/Min server memory
database configuration1
max worker threads

min memory per query

network packet size / protocol

priority boost

query governor cost limit

query wait

recovery interval

set working set size

Database Configuration
slide10

Add / speed up I/O bus

Add RAID

+ move disks

Check disk

+ controller

I/O System Tuning

?

Slow RAID

identified?

Check all

logical disks

with NT perfmon

No

Yes

Avg. disk queue

length > 2 * phys.

Disks in RAID

RAID 5

and mostly write

queue?

No

Decrease

max async I/O

Yes

Yes

Switch to

RAID 0+1

Peak I/O

on I/O bus

< 133 MB/sec

Peak I/O

on RAID

< 40 MB/sec

Yes

No

No

Yes

Yes

No

server configuration
Server Configuration

Poor configuration

Hardware

configuration

Poor database

configuration

Main memory

Disk

layout

Disks

CPU

Parameter

settings

Cache hit ratio

Operating system paging

Disk response times

High I/O times

CPUutilization

>95%

SQL Server CPU utilization DB error log

Select 1 row

via prim. key

> 10 ms

Page in

> 100 MB / h

Wait queue

and low

transfer rate

2 * idle > busy

(total)

2 * idle > busy

(SQL Server)

dynamic locking
Dynamic Locking

Isolationlevel

Scan type (Range, Table, Probe)

Locking strategy(Table, Page, Row)

# of rows

in scan

# of rows/page

Operation type (scan, update)

multi granular locking
To lock a fine granule must place intent locks at higher granules

Row

Row

Row

Multi-Granular Locking

T2: IS

T1: IX

Table

T2: IS

T1: IX

Page

Page

Page

T1: X

T2: S

lock modes
Lock Modes
  • Standard multi-granular lock modes

Mode Description

S Share - used for reading

X Exclusive - typically used for writing

U Update - used to evaluate prior to writing

IS Intent Share - share locking at finer level

IX Intent Exclusive - X locking at finer level

SIX Share Intent Exclusive

how does sql lock
HOW does SQL lock ?
  • How do you identify a lock?
    • Lock “resource”
      • Table “Authors”
      • Page 23
      • Row with Key = “23812”
    • Lock manager knows nothing about resource format; it simply does a “memcmp()”
  • Lock resource format:

Resource Type

Database ID

Resource Specific Data

lock resource format
Lock Resource Format
  • Example resource formats:
    • Table:
    • Page:
    • RowID:
    • Key:

5

5

325658

Object ID

6

5

2:328

File#: Page#

File# : Page# : Slot on Page

9

5

2:328:11

Object ID : IndexId : 6byte Hash

7

5

325658:2:2341186

Resourcetype

Database ID

new lock hints
New Lock Hints
  • Granularity Hints
    • ROWLOCK, PAGLOCK,TABLOCK
  • ISOLEVEL Hints
    • HOLDLOCK, NOLOCK
    • READCOMMITTED, REPEATABLEREAD, SERIALIZABLE, READUNCOMMITTED [All New]
new lock hints1
New Lock Hints
  • READPAST
    • Useful for implementing work queues
  • UPDLOCK
    • Select for update
    • Deadlock due to select for update
    • Starving lock waits
  • LOCK_TIMEOUT(not a hint)
    • Application response time
concurrency issue analysis
sp_who, sysprocesses

sp_locks

SQL Profiler

sp_indexoption

Deadlock

DBCC inputbuffer

Kill

Lock waits

Latches

Concurrency issue analysis
lockwait situations

MARA

Lockwait Situations

4. Work process

Update MARA

Requests

MARA Lock

WAITING ...

3. Work process

Update MARA

Requests

MARA Lock

Acquires

MARA Lock

WAITING!

Working...

2. Work process

Update MARA

Requests

MARA Lock

Acquires

MARA Lock

WAITING!

Working...

Commit

1. Work process

Update MARA

Acquires

MARA Lock

A long period of processing

Commit

Time

WP 1

WP 2

WP 3

Locked by:

monitoring lockwaits
Monitoring Lockwaits

R/3 Lock Monitor

query issues
Unnecessary results

Select with no where clause

Select * instead of selecting few columns

Queries not qualified properly

Poorly written queries

Missing index

Old statistics

Incorrect optimization

Index Tuning Wizard

Query issues
choosing index
Space utilized by index

Index maintenance overhead

To cluster or not

Bookmark lookup

Range scan(OLTP Vs OLAP)

Index columns

Short & with high selectivity

Often used in many statements

Covered

Multi index query

Choosing index
monitoring query execution
Analyze query execution plan

Analyze the right plan - connection settings

spid, blocked, waittype, cpu physical_io, memusage, open_tran from sysprocesses

Execution plan, read, write, duration in SQL Profiler

Monitoring Query execution
monitoring query execution1
Stats I/o

Stats time

Write your own trace

Expected time / threshold

Worktable

Scan Vs Seek

Monitoring Query execution
query execution
Query Hints

Join, Index, Lock, Processing

Distributed query execution

TOP / SET ROWCOUNT

FASTFIRSTROW

IN / OR and subquery

Selecting with alias

Query execution
using stored procedures
Cached execution plan

Recompiled when stats changes

Warning: Wrong Parameter to stored proc

Binding parameter by position

Set nocount

sp_executesql

Auto-parameterization in SQL7

sp_recompile

Using stored procedures
table statistics1
Auto update stats

Rowmodctr and StatVersion

Fullscan and sampling

Auto column stats

Explicit update stats

Explicit column stats

sp_autostats

Queue / log table

sp_recompile

Table statistics
tuning expensive sql statements
Tuning Expensive SQL Statements

Poor

statement

SQL

Explain

Where

used list

DDIC

info

Is there asuitableindex?

GoodOptimizer

decision?

Inefficientcoding?

Yes

Yes

No

No

Statistics

page

Yes

Re-code

Index

statistics

up to

date?

Autoupdate

stats on?

Yes

Yes

Update

statistics

No

No

Re-code

or

change index

Switch on

auto updstats

slide51
Lab
  • Improve the slow running report
    • Use ST05
    • Stats on SPs(ST04)
    • And other methods
