Development of a Lightweight and Cost-Effective Motor Module for RP1 Gen 2

Our team, led by Lauren Farnsworth, is focused on creating a new motor module tailored to transport a 1kg payload. This design aims to significantly reduce weight and size compared to RP1 Gen 1 while being more cost-effective. It must pass rigorous reliability testing, be suitable for mass production, and incorporate user-friendly features. The module will include software and electronics from P09204 with infinite steering capabilities. We will utilize commercial off-the-shelf components, emphasizing open-source documentation and recognizable RP family design principles.

selia
Download Presentation

Development of a Lightweight and Cost-Effective Motor Module for RP1 Gen 2

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. P09203RP1 Motor Module Gen 2

  2. Our Team • Team Leader • Lauren Farnsworth • General (to be decided at a later date) • Michael Egan • Matthew Missel • Gregory Leaper

  3. RP1 GEN2 • Create a motor module designed to carry 1Kg • Requirements • Design should be significantly lighter and smaller than RP1 GEN1 • Design must be more cost effective than GEN1 • Design must pass reliability testing • Design must be easily mass produced • Design must be user friendly • Must integrate software and electronics developed in P09204

  4. Customer Needs as Defined in Gen1 • Transport 1kg payload • Motors to be driven with PMW signal • Encoder feedback from drive and steering motors • Infinite steering • Open source & Open architecture – Well Documented • Use COTS components when possible • Easily recognizable as belonging to the RP family • Reflect design knowledge gained throughout the RP family • Vertical configuration of drive and steering motors • Professional quality construction • Modular design – motor modules can be interchanged • Withstand a drop test from a level equal to a table top • Meet existing regulatory and RP family constraints
