Presentation Transcript
  • ANTLR is a popular lexer and parser generator in Java.
  • It allows LL(*) grammars, does top-down parsing.
  • Similarities with LL(1) grammar:
    • Does top-down parsing
    • Grammar has to be fixed to remove left recursion
    • Uses lookahead tokens to decide which path to take
    • You can think of it as recursive-descent parsing.
  • Differences:
    • How far we can look ahead is not constrained
    • CommonTokenStream defines LA(k) and LT(k):
      • Both look ahead to k-th next token
      • LA(k) returns an int, the token code
      • LT(k) returns a Token object
  • ANTLRWorks is ANTLR IDE (integrated dev environ)
  • It has many nice features:
    • Automatically fills in common token definitions
    • Has standard IDE features like syntax highlighting
    • Regexp FSM (lexer machine) for tokens
    • Has a very nice debugger which can show:
      • input and output
      • parse tree and AST (abstract syntax tree)
      • call (rule) stack and events
      • grammar rule that is being executed
      • forward and backward execution
    • But also has some bugs in automatic features
running antlr inputs steps
Running ANTLR: Inputs, Steps
  • You need three files before you run ANTLR:
    • a grammar file, Xyz.g (Microjava.g)
    • a Java test runner, Test.java
    • a test input file, such as sample.mj
  • There are three steps to running ANTLR:
    • antlr: Generate lexer and parser classes:
      • XyzLexer.java
      • XyzParser.java
    • javac: Compile these two and Test.java
      • XyzLexer.class, XyzParser.class
      • Test.class
    • java: Run Test with your input file
    • javac and java need two items in CLASSPATH:
      • antlrworks JAR file (antlrworks-1.3.1.jar)
      • current directory (.)
step 1 antlr
Step 1. ANTLR
  • You may have an antlr executable:
    • antlr Xyz.g
  • Make sure you save a "grammar Xyz" in file Xyz.g
  • If you only have a JAR file instead, use:
    • java -jar antlr-3.2.jar Xyz.g
  • This creates two Java class source code files:
    • XyzLexer.java
    • XyzParser.java
  • By default, these files go in current directory
  • You can instead state where *.java should go:
    • antlr -o src Xyz.g
  • This time, *.java will appear in src directory.
step 2 compile with javac
Step 2. Compile with javac
  • To lexer and parser, you need to add your runner:
    • Test.java
  • See ANTLR examples online for runner examples.
  • Before javac, set CLASSPATH environment var to have:
    • . (the current directory)
    • antlrworks-1.3.1.jar
  • In Linux/Unix, under bash, you may do:
    • export CLASSPATH=.:antlrworks-1.3.1.jar
  • Unlike this example, give full path to antlrworks JAR file.
  • On Windows, you may want to go to System / Environment Variables (and replace : with ; here)
  • Now (go under src if needed), compile everything:
    • javac Test.java
  • As Test uses other classes, everything will be compiled.
step 3 run with java
Step 3. Run with java
  • Again, set CLASSPATH environment var as before
  • Go under src if needed (if you used -o option)
  • Run your test, give your input file:
    • java Test < input.txt
    • java Test < input.txt > output.txt
    • java Microjava < sample.mj
  • A grammar with no evaluation:
    • will be quiet if everything is OK
    • will only give syntax errors if input is not good
  • A grammar with output will display the output.
  • ANTLR doesn't allow running interactively
    • It buffers input and output
    • You can't enter 1+1 and see 2 right away
    • All output will be seen after EOF
    • (Control-Z in Windows, Control-D in Linux/Unix)
antlrworks other java ide
ANTLRWorks, Other Java IDE
  • Instead of these steps, you can use ANTLRWorks.
  • To run under ANTLRWorks, just use its debugger.
  • It has ANTLR inside, and knows how to set the CLASSPATH for compiling and running.
  • *.java files produced by ANTLRWorks will be different, as they contain debugger commands.
  • To run ANTLR under a Java IDE, you may be able to define custom build rules for *.g files.
  • You should add the antlrworks JAR file to your project, to have ANTLR runtime libraries.
  • Make sure the libraries are used during both compilation and running.
next steps
Next Steps
  • We will next see:
    • A demonstration of using ANTLR (three steps)
    • ANTLRWorks screenshots
  • We will also look at some grammar examples:
    • Calculator without evaluation
    • Calculator with evaluation
    • Calculator with AST
    • MicroJava lexer
    • Starting steps for MicroJava parser
