  1. DUCO Umbilicals27th June 2006Subsea North East Launch

  2. Overview • Duco manufactures Control Umbilicals for Subsea Production Systems • Electrical and hydraulic power transferred from host facility to subsea wells • Fluids to assist well productivity tranferred from host facility to subsea wells • Control signals between wells and host facility to monitor production. • Worldwide market • Broad client base • Majors and Independant Oil Companies • State Oil Producers • EPIC contractors • Wellhead equipment manufacturers • International business with a local North East focus

  3. Make Up of an Umbilical? Outer Sheath Armour Layers Inner Sheath Fillers Tube Electric Cable Fibre Optic Cable Electric Cable

  4. UMBILICAL ASSEMBLY • Typical Umbilical Lay-up

  5. A Sense of Proportion - LENGTH

  6. 1990 - £7m DUCO moves to Walker Plant 1978 Dunlop enters umbilical business Southampton facility 2004 - £61m Angoflex Ltda factory opens 1989 - £5m New joint venture between Dunlop & Coflexip DUCO 2006 - £100m Reviewing options for further international and local expansion 1983 Joint Venture formed between Dunlop & Pirelli 2001- £37m Technip & Coflexip merge *Newcastle Revenue only 1998 - £33m DUCO LTD first umbilical manufacturer to be awarded API 17E licence 1996 - £25m DUCO Inc Channelview, Houston Opens 1994 - £14m Coflexip Merge with Stena Offshore

  7. DUCO Inc. USA Houston Angoflex Angola DUCO Ltd. Newcastle HQ LOCATIONS

  8. DUCO Ltd – Newcastle, UK • Capacity 300km per annum • Workforce : 350 approximately • Facility located 30m (100ft) from 800m (2625ft) long quayside

  9. SIGNIFICANT MANUFACTURING ACHIEVEMENTS • Largest Single Length Thermoplastic Umbilical Produced by Newcastle Facility • Exxon Mobil Arthur : 31km ; 983 tonnes ; 146mm diameter • Supplier of the GOMEX longest umbilical (DUCO Inc.) • SHELL, MENSA DEVELOPMENT, 106 km • Supplier of the world’s heaviest and largest umbilical (DUCO Ltd.) • PETROCANADA, TERRA NOVA @ 170kg/m, 320mm diameter • Supplier of the world’s largest number of components (DUCO Ltd.) • TALISMAN, BUCHAN ALPHA, 98 HOSES • Currently manufacturing world’s heaviest umbilical • BP SECU 305mm diameter @ 190kg/m • Safety Performance • In excess of 1400 days incident free

  10. WHY IS MARKET SO ATTRACTIVE? • High oil price here to stay • Next 5 years:- • 40% increase in subsea production • Doubling FPSO’s • Planned delays to decommissioning • Enhanced recovery to existing subsea production systems By 2013 oil demand predicted to exceed supply
