safe rtl annotations for low power microprocessor design
Safe RTL Annotations for Low Power Microprocessor Design

Vinod Viswanath

Department of Electrical and Computer Engineering

University of Texas at Austin

Talk at Tata Institute of Fundamental Research, Mumbai, India.

outline
Outline
  • Power Dissipation in Hardware Circuits
  • Instruction-driven Slicing to attain lower power dissipation
    • Automatically annotates microprocessor description at the Register Transfer Level and Architectural level
  • Correctness of the introduced annotations
  • Case studies
power dissipation
Power Dissipation
  • Switching activity power dissipation
    • To charge and discharge nodes
  • Short Circuit power dissipation
    • High only for output drivers, clock buffers
  • Static power dissipation
    • Due to leakage current

P = 1/2 ¢ C ¢ V2DD¢ f ¢ N + QSC¢ VDD¢ f ¢ N + Ileak¢ VDD

switching activity power dissipation
Switching Activity Power Dissipation
  • Reduce the squared term VDD
    • Leads to exponential increase in Ileak
  • Host of techniques to reduce switching power at the gate level
    • Clock gating
  • Relatively much lesser at the RTL
    • Use program structure and dataflow information available at that level of abstraction
instruction driven slice
Instruction-driven Slice
  • An instruction-driven slice of a microprocessor design is
    • all the relevant circuitry of the design required to completely execute a specific instruction
    • Parts of the decode, execute, writeback etc. blocks
  • Cone of influence of the semantics of the instruction
instruction driven slicing
Instruction-driven Slicing
  • Given a microprocessor design and an instruction
    • Identify the instruction-driven slice
    • Shut off the rest of the circuitry
  • This might include
    • Gating out parts of different blocks
    • Gating out floating point units during integer ALU execution
    • Turning off certain FSMs in different control blocks since exact constraints on their inputs are available due to instruction-driven slicing
algorithm high level
Algorithm (High Level)
  • Algorithm instruction-driven-slicing.

Begin

      • Inputs: vRTL (Verilog RTL), insts (instructions)
      • Output: aRTL (Annotated RTL)
    • Parse vRTL to obtain the Abstract Syntax Program Graph (ASPG)
    • For each instruction I in insts repeat
      • Slice the ASPG for instruction I
      • Traverse the ASPG
      • Add annotation variables if such a block is found
      • If a particular flop is already gated, then

add the current annotation in an optimal fashion

      • Return the annotated ASPG
    • Generate Verilog code (aRTL) for the annotated ASPG

End.

instructions as ltl properties
Instructions as LTL Properties
  • Let I = i1Æ X i2Æ XX i3 ... Xn-1 in be an instruction written as an LTL property, such that ir represents the conditions for the instruction I on clock cycle r.
  • i1 represents the instruction word.
risc pipeline or1200
RISC Pipeline (OR1200)
  • 5 stage RISC pipeline implementation
  • Condition for slicing on ADDC instruction
    • i1: ((icpu_dat_i[31:26]==6’b 111000) Æ

(!rst) Æ (!flushpipe) Æ (!if_freeze))

    • i2: (!id_freeze)
    • i3: (!ex_freeze)
    • i4: (!mem_freeze)
    • i5: (!wb_freeze)
  • I = i1Æ X i2Æ X2i3Æ X3i4Æ X4i5
or1200 addc instruction
OR1200 ADDC Instruction
  • Introduces five variables:
    • iADDC_if = i1
    • iADDC_id = #1 iADDC_if Æ i2
    • iADDC_ex = #1 iADDC_id Æ i3
    • iADDC_mem = #1 iADDC_ex Æ i4
    • iADDC_wb = #1 iADDC_mem Æ i5
correct annotations
Correct Annotations
  • Notion of correctness
    • Original RTL and the annotated RTL should be functionally equivalent under all conditions
  • Correctness theorem

(defthm or1200_slicing_correct

(equal (or1200_cpu n)

(or1200_cpu_sliced n)))

acl2 theorem prover
ACL2 Theorem Prover
  • First order logic general purpose theorem prover
  • Breakdown the theorem into sub-goals
  • Many engines work on the sub-goals and will either prove them or break them down further and add to the central pool of goals to be proved
  • Success story in Hardware
    • Verified FDIV in the AMD processors
proof methodology
Proof Methodology
  • The RTL is a shallow embedding in ACL2
  • Convert Verilog RTL into ACL2RTL
  • We have created a large RTL library to recognize as well as analyze ACL2RTL
  • Slicing is done on the Verilog code
  • Both original and annotated Verilog are converted into ACL2 and we construct the functional equivalence proof in ACL2
methodology
Methodology
  • In order to demonstrate our technique
    • We have incorporated instruction-driven slicing as part of the traditional design flow
    • The vRTL model is annotated to obtain the aRTL model
    • Synopsys Design Environment has been sufficiently modified to accept the aRTL, SPEC2000 benchmarks and power process parameters and estimate the power dissipation due to switching activity
    • The annotated Architectural model is fed to the SimpleScalar simulator with the Wattch power estimator to estimate the power dissipation
experiment or1200
Experiment: OR1200
  • We have used our tool-chain to test our methodology on OR1200
    • OR1200 is a pipelined microprocessor implementing the OpenRISC ISA.
    • 5-stage integer pipeline with single instruction issue per cycle
    • We have annotated both the RTL and the architectural models of OR1200
or1200 power gain results
OR1200 Power Gain Results
  • Results are shown after annotating the
    • RTL (left) and Architectural (Right) models
    • For un-sliced and sliced on 1, 4, 10 instructions
    • For SPECINT2000 benchmarks
  • Power dissipation decreases consistently
or1200 results contd
OR1200 Results (contd.)
  • Power gains are consistently good (Fig. 1)
  • Power gains far outperform area losses (Fig 1)
  • Flop distribution shown before slicing (Fig. 2a) after slicing on add (Fig. 2b) and after slicing on load (Fig. 2c)

Fig.2a

Fig.2b

Fig. 1

Fig.2c

experiment puma
Experiment: PUMA
  • We have used our tool-chain to test our methodology on PUMA
    • PUMA is a dual-issue, out-of-order super-scalar, fixed-point PowerPC core
    • We have annotated both the RTL and the architectural models of PUMA
puma power gain results
PUMA Power Gain Results
  • Results are shown after annotating the
    • RTL (left) and Architectural (Right) models
    • For un-sliced and sliced on 1, 4, 10 instructions
    • For SPECINT2000 benchmarks
  • Power dissipation decreases consistently
puma results contd
PUMA Results (contd.)
  • Power gains are good upon slicing for a few instructions (~7) before delay losses start dominating (Fig. 1)
  • Power gains far outperform area losses (Fig 2)
  • Flop distribution shown before slicing (Fig. 3a) after slicing on add (Fig. 3b) and after slicing on load (Fig. 3c)

Fig.3a

Fig. 1

Fig. 2

Fig.3b

Fig.3c

conclusions
Conclusions
  • Proposed Instruction-driven Slicing as a new technique to automatically reduce power dissipation
  • Implemented the methodology of incorporating instruction-driven slicing into the design flow tool-chain
  • Inserting these annotations preserves the functionality of the circuit
conclusions continued
Conclusions (continued)
  • This technique seems most applicable to single-issue multi-staged pipelined machines.
  • When there are multiple instructions in-flight in the same pipeline stage, the gains of a single-instruction-abstraction are lost.
  • Graphics processors, various embedded applications are more often better suited for this technique than general purpose out-of-order superscalars.
