  1. Wireless Broadband Networks Portfolio Overview Jim Garlington Regional Sales Manager

  2. Customers Looking for Efficiency and Productivity Why Choose Wireless Broadband • Cost Reduction: • 1/5 to 1/8th the cost of wired • Leased Line replacement • Resource Efficiency • Application: • Connecting the Unconnected • Video Surveillance • Mobile Office • … IP Cloud and/or Backbone • Now it’s feasible • More reliable • More secure

  3. One Point Wireless Management Suite Indoor Backhaul Distribution Mesh Proven, Reliable, Cost Effective Wireless Broadband Optimized transport networks Wireless bridging from wireline data network to outdoor distribution Distributing wireless backhaul to camera population & mesh access Campus wide wireless mesh data network to send & receive data & video Indoor networks for client connectivity and more

  4. Wireless transport network WirelineData Network Point-to-Point Backhaul Backhaul Wireless bridging from wireline data network to outdoor distribution CanopyPoint-to-Multipoint Access Point Remote Control / Telemetry Distribution Canopy Subscribers & Mesh Access Points Canopy Subscribers & Camera Population Distributing wireless backhaul to camera population & mesh access Access Indoor & Outdoor Self-Forming Mesh Access Points Indoor and On-the-street wireless mesh network to send & receive data & video Access Layer Devices

  5. Upwards of 300 Mbps, up to 155 miles, NLOS, OFDM, MIMOPoint-to-Point bridging & backhaul Wireless transport network - Backhaul • High speed fixed point-to-point Ethernet connections between facilities or tower sites • Linking to the terrestrial Internet via fiber or other point of presence • Operate in the licensed or unlicensed spectrum to provide reliable connectivity for the entire system • With Multiple-In-Multiple-Out technology, can adjust throughput based on conditions to provide maximum connectivity in the most harsh environments

  6. High Bandwidth, Long Distance or NLOS Wireless IP PTP (Point To Point) Line-of-sight (LOS) Up to 155 miles near Line-of-sight (nLOS) Up to 25 miles Non Line-of-sight (NLOS) Up to 6 miles

  7. When there are obstacles, each data burst is sent with both horizontal and vertical polarization and heard by both receivers Multiple-Input Multiple-Output

  8. PTP300/500/600 Radios support Dual Payload Operating mode is selected automatically Data1 Data1 Data1 Data1 Data1 Data2 What is Dual Payload? Clear LOS Dual Payload Highest throughput NLOS path Single Payload 4xDiversity

  9. PTP200 provides installation flexibility - Competitive advantage to low cost PTP technologies that are not as robust PTP 200 • Now Available • General Characteristics • Based on Canopy 400 Series using OFDM • 5.4GHz and 4.9GHz • Integrated and Connectorized Options • DES and AES Options • Performance • 8 km range using integrated 17 dBi antenna • 10 MHz Channel • 21 Mbps maximum aggregate throughput

  10. Complete Management = more efficient operations Integrated Antenna = lower deployment costs “T” mode possible with better in band filtering = more flexible solution “Optimized” Linear OFDM BH Design PTP200 PTP200

  11. Easy, Simple, Affordable deployment Introducing the PTP 800 • Split-mount architecture: • Outdoor Unit (ODU) • Channel, modulation independent • Compact Modem unit (CMU) • Frequency & capacity independent • Compact modem design: • Small footprint / easy installation • Outdoor rated operating temperature range (-33 to +55 C) • Single Ethernet traffic port – Gig-E copper, Gig-E SFP option • 100/10 BaseT out of band management port ODU IDU

  12. (SFP) Small Form Factor, Large Capability PTP800 Front Panel

  13. Typical PTP 800 Order(BOM for 1+0) • PTP 800: • 2 x CMU (Compact Modem Unit) with a software key for the throughput CAP • 2 x ODU (Outdoor Unit) for the frequency desired – ODU is frequency dependent • 2 x Antennas • RG-8 IF Cable • 2 x Cable Installation Kits

  14. GPS Synch Box • Synchronises the TDD cycle between multiple PTP links • Minimizes interference • Improves frequency re-use • Closer packing of multiple links around a mast • Implemented using external GPS sync Unit • Can retrofit existing links • 1xGPS Sync Unit per link PTP600 ODU GPS Sync Unit PTP LPU SYNC ETH

  15. Path Profile Configuration Detail Network Map Performance Summary PTP LINKPlanner • Perform calculations for licensed and unlicensed PTP products2 • Plan and optimize a single link or multiple links simultaneously • Accurately predict PTP link performanceand set realistic expectations • Automatically compiles PTP equipment list with SKUs and pricing • Displays an overview of the entire wireless network via Google™ Earth DOWNLOAD it form Here: http://motorola.wirelessbroadbandsupport.com/software/ptp/ 2 LINKPlanner may not perform calculations for the entire PTP portfolio, PTP800 will be available in Link Planner in 2009.

  16. PTP Portfolio * PTP800 band rollout scheduled in 2009 and 2010

  17. Robust, LOS to NLOS, easy to deploy, High Bandwidth links Industry Advantages - PTP • Spectral Efficiency • Best in Class Link budget • MIMO • Intelligent DFS • Space Diversity • TDD Synchronization • Link Planner tool • One Point WM

  18. Deployed over 2,500,000 units in more than 120 countries Wireless transport network - Distribution • Fixed point-to-multipoint connections linking video cameras, hotspots, Mesh networks and facilities • Equipped with GPS synchronization and are the industry leader in interference tolerance • Provides reliable connectivity in the presence of other emitters and noise • Unmatched latency & interference mitigation • Connectivity to video surveillance cameras and also an infrastructure layer for the mobile access mesh network • More than 3,000 service providers since 2002

  19. Greater PMP Reach Leader in Point to Multi Point Connectivity FSK OFDM Traditional Canopy / PMP, enabling multi MD throughput for Point to Multi Point connectivity Based on the PTP portfolio. A robust interface enabling nLOS connectivity and higher throughputs / longer ranges

  20. Sears Tower Access Point 8 story buildings SM LOS LocationCanopy SM: 14Mbps*Canopy 400 SM: 19Mbps SM NLOS LocationCanopy SM: No ConnectionCanopy 400: 6.2Mbps SM NLOS LocationCanopy SM: No ConnectionCanopy 400: 6.1Mbps *Actual Aggregate Throughputs PMP400 NLOS Performance vs. Canopy - Urban

  21. PMP 400 Series PMP Advantage PMP Range (Miles) Frequency > 20 900 MHz 2.5-7 2.4 GHz 1-15 4.9 GHz 1-2 5.1 GHz 1-2 5.2 GHz 1-5 5.4 GHz 1-10 5.7 GHz 1-10 5.9 GHz Agile Portfolio

  22. PMP Agile Portfolio Total Aggregate Throughput CIR in Each Direction VoIP Channels Supported Typical Application Product Burst Residential and/or Enterprise Broadband Services PMP 400 Series SM 21 Mbps 21 Mb No Cap Multiple Enterprise Broadband Services PMP Advantage SM 14 Mbps 14 Mb No Cap Multiple Residential and/or Enterprise Broadband Services PMP SM 7 Mbps Multiple 7 Mb No Cap

  23. Interoperable WiMAX for Fixed links PMP 320 • Designed specifically for FixedOutdoor applications • Improved range / coverage / performance with 2x2 MIMO • Can be deployed with no back-end server equipment - Fixed WiMAX capabilities without the large investments in infrastructure • Access to low-cost standards-based CPE’s 802.16e micro

  24. Leader in Point to Multipoint Connectivity Industry Advantages - PMP (Point To Multipoint) • Industry Leading Interference Tolerance • Lowest carrier to interference rating • Environmentally Rugged • Performance in harsh environments • Low Field Failure Rates • Reduce operational expenses over the long term • Scalable to Sustain Performance as the Network Grows • GPS synchronization mitigates self interference

  25. Decentralized, self-healing, self-forming Mobile broadband Access MOTOMESH 4300 Access Network • Motorola’s Dual Radio Mesh Platform • Band-optimized radio performance • Complete standards support • MeshConnex hybrid routing algorithm – it’s NOT Spanning Tree!!!! • Best in class deployment tools and management capabilities • Most flexible mesh platform on the market today in terms of features, tools & scalability.

  26. MOTOMESH Duo VMM4300 - July Proven Mesh Routing ORLA (Opportunistic Radio Link Adaptation) is the new improved routing algorithm for MeshConnex™, which enables faster route convergence and recovery. ORLA improves throughput by maintaining a high packet completion rate and it increases performance in noisy environments. Best in Class Security The best in class security is supported with Motorola’s own Secure Mesh, which ensures the highest data security within the meshed WiFi network. Links are authenticated and encrypted. Quality of Service The VMM 4300 supports IEEE 802.11e based traffic prioritization, which enables flawless execution of video and voice applications. High Power Radio The VMM 4300 supports maximum power to ensure a robust connection to and from the vehicle is maintained.

  27. AP7181 – November • Dual Radio 802.11n Draft 2.0 (supports a/b/g/n) • 2.4 GHz/5.X GHz • 2x2/3x3 MIMO • 20 MHz and 40 MHz channels • 802.11 DFS v1.4.1, v1.5.1 • ADEPT™ MIMO Antenna System • Integrated 2.4/5.x GHz with polarization diversity • Software configurable down-tilt • Remote mounting of Panel antennas • Robust IP67 with NEMA 4x enclosure • POE 802.11af power out

  28. Unmatched, Cross network capabilities Motorola One Point WMS • Serve end customers more efficiently • Less Hardware, Less Training • A Fully Integrated Solution • Design networks: • LAN Planner • Link Planner • Mesh Planner • Deploy • LAN Scanner • Mesh Scanner • Manage

  29. Wireless Broadband is the Enabler IP Solutions A few application we have worked with:

  30. Wireless transport network WirelineData Network Point-to-Point Backhaul Backhaul Wireless bridging from wireline data network to outdoor distribution CanopyPoint-to-Multipoint Access Point Remote Control / Telemetry Distribution Canopy Subscribers & Mesh Access Points Canopy Subscribers & Camera Population Distributing wireless backhaul to camera population & mesh access Access Indoor & Outdoor Self-Forming Mesh Access Points Indoor and On-the-street wireless mesh network to send & receive data & video Access Layer Devices

  31. Proven, Reliable, Cost Effective Wireless Broadband – Continuous Innovation Only Motorola • Full, end-to-end Solutions • PTP • PMP • Mesh • EWLAN • Technology that is second to none • Over 2,500,000 PMP/Canopy devices deployed • Over 1,000,000 Indoor Access Points deployed • Over 63,000 PTP radios shipped • Over 20,000 MOTOMESH nodes deployed • Complete Support Systems One Point Wireless Management Suite

  32. INTERNET A B C D Point to Point ….. Linear Architecture PMP/Canopy Hub & Spoke Architecture F E Mesh Architecture A E INTERNET A D B D B C INTERNET C Architecture

  33. ROI Summary ROI = (annual TCO) / (annual TBO) • TBO = Total Benefit of Ownership • Video Security = $300 to $700k/yr • Connecting City Admin = $820,050/yr • Connecting Public Safety = $95,600/yr • Meter Reading = $230,560/yr • Lease line replacement = $6,000 to $60,000 per replaced link • More….. • TCO = ….. One Point Wireless Manager * Assumptions for a medium sizes municipality
