kernel synchronization in linux uni processor and multi processor environment
Kernel Synchronization in Linux Uni-processor and Multi-processor Environment

By Kathryn Bean and Wafa’ Jaffal (Group A3)

topics
Topics
  • Linux History
  • Kernel Control Path
  • Synchronization Technique
  • SMP Architecture
  • Hardware Support for Synchronization (Pentium-based Architecture)
  • Linux/SMP kernel
  • Conclusion
linux history
Linux History
  • University of Helsinki (1997), Master’s thesis –

“Linux, a Portable Operating System” by L. Torvalds

  • OS for IBM-compatible personal computers (Intel 80386 microprocessor).
  • Source code under GNU General Public License
kernel control path
Kernel Control Path
  • Kernel control path is the sequence of instructions executed in Kernel Mode to handle a kernel request.
  • Kernel control path executes due to the following reasons:
    • System calls
    • Exceptions
    • Interrupts
synchronization technique
Synchronization Technique
  • Nonpreemptability
  • Atomic Operations
  • Interrupt Disabling
  • Locks
condition to be preempted
Condition to be Preempted
  • Kernel control path can preempt a running process; however, when an interrupt handle terminates, the process resumes.
  • Only kernel control path can interrupt another kernel control path.
atomic operation
Atomic Operation
  • An atomic operation - performed by executing a single assembly language instruction
  • Linux kernel provides special functions such as:

atomic_int(v)  v++

interrupt disabling
Interrupt Disabling
  • Because of its simplicity, interrupt disabling is used by kernel functions for implementing a critical region.
  • This technique does not always prevent kernel control path interleaving.
  • Critical section should be short because any communication between CPU and I/O is blocked while a kernel control path is running in this section.
locking
Locking
  • Two kinds of locking:
    • Kernel semaphores, used by both uni-processor and multiprocessor systems
    • Spin Locks, used by only multiprocessor systems
kernel semaphore implementation
Kernel Semaphore Implementation
  • Kernel semaphore – is object of type structure semaphore, see include/asm/semaphore.h file
  • Fields
    • count – integer number
      • count > 0 – semaphore is available
      • count  0 – semaphore is busy, |count| - number of processes waiting for resource.
      • Count = 0 – one use, nothing is waiting

The count field is decremented when a process acquires the lock and is incremented when the same process releases it.

kernel semaphore implementation continued
Kernel Semaphore Implementation, Continued
  • wait – the address of a wait queue.
  • waking – integer.
    • The releasing process increments waking field(s).
    • Each of awakened process PI then enters a critical region of the down() function
    • Is PI’s waking <> 0, if waking > 0 – 1. acquire the resource

2. other PK’s waking--

if waking < 0 – go back to sleep

kernel semaphore implementation continued1
Kernel Semaphore Implementation, Continued
  • Function
    • down() – called, if process wishes to acquire a semaphore.
      • count --
      • count <> 0, if count  0 – process enter the critical section

if count < 0 – process is suspended

    • up() – called, if process releases a semaphore
      • count ++
      • count <> 0 – if count > 0 – up() terminates

if count < 0 – wake up other processes

  • Deadlock – semaphore requests are performed in the address order.
smp architecture
SMP Architecture
  • Scalability of Linux - supports multiprocessing through Shared Memory Symmetric Multiprocessors (SMM) architecture.

scalability is the capability of a system to adapt to an ever-increasing work load.

smp architecture continued
SMP Architecture, Continued

CPU 1

CPU n

system bus

Graphical card

Memory

  • CPUs share the same memory unit
  • application processing and kernel processing are spread amongst all CPUs.
other multiprocessor architectures
Other Multiprocessor Architectures
  • Asymmetric Multiprocessing

Master CPU executes the operating system code and application programs run on the remaining CPUs.

  • Massively Parallel Processing (MPP)

Assemble hundreds or thousand of CPUs, each with own system memory

hardware support for synchronization
Hardware Support for Synchronization
  • Shared Memory

Memory arbiter – (chip between bus and every RAM chip) grants access to a CPU if the chip is free and delays access if the chip is busy.

  • Cache Synchronization

Hardware cache is utilized using the localityprinciple. In multiprocessor environment, each CPU has its own cache. Process of updating cache -cache snooping

hardware support for synchronization continued
Hardware Support for Synchronization, Continued
  • SMP Atomic Operation
    • Lock instruction prefixes for atomic operations were introduced.
    • If control unit detects them  lock the memory bus, no other processes can access this memory location
hardware support for synchronization continued1
Hardware Support for Synchronization, Continued
  • Distributed Interrupt Handling

CPU 1

CPU n

Local APIC

Local APIC

ICC bus

I/O APIC

APIC – Advanced Programmable Interrupt Controller

ICC – Interrupt Controller Communication

I/O APIC - router

IRQ lines

linux smp kernel
Linux/SMP Kernel
  • Process Descriptor Modification
    • has_cpu: if has_cpu > 0 – process is running
    • Processor – logical number of its CPU
  • Spin Locks

Blocked process keeps its own CPU by spinning while waiting for a resource.

conclusion
Conclusion
  • Modern versions of Linux are available
    • Compaq Alpha
    • SPARC
    • PowerPC
    • Motorola MC680x0
    • IBM System/390
  • Multiprocessor operating system

Supports up to 32 CPUs

bibliography
Bibliography
  • D. P. Bovet, M. Cesati. Understanding the Linux Kernel. O’Reilly, 2000
  • Linus Torvalds. Linux: a Portable Operating System. Master of Science Thesis, University of Helsinki, Finland, 1997
  • D. Mosberg, S. Eranian IA-64 Linux Kernel

Prentice Hall PTR, 2002

thank you
Thank You

Any Questions?
