Presentation Transcript
slide1

SIPPING

3GPP Requirements

Ad Hoc Meeting

Georg Mayer

IETF#53, Minneapolis

sip the solution for ims
SIP – the Solution for IMS
  • Loose Routing adopted
    • All IMS entities that forward SIP messages support loose routing
    • P/S-CSCF’s are transparent B2BUAs (e.g. network initiated call release, header removal by P-CSCF)
  • Max-Forwards adopted
  • DTMF via RTP (RFC2833)
  • manyfolks-05 & update drafts – adoption still under discussion
  • Path Header – needs further discussion (also in IETF)
loose service binding everything is allowed
Loose Service Binding – Everything is Allowed
  • UMTS Network consists of three domains:
    • Circuit Switched (CS)
    • Packet Switched (PS)
    • IP Multimedia Subsystem (IMS)
  • IMS is on top of PS domain
  • Pure IP / SIP are available via PS domain
  • Value added services are available via IMS
  • Registration is not necessary to set up SIP calls in UMTS
  • Calls to unregistered IMS users are possible (terminated at home service node, e.g. VoiceMail)
  • IMS users can be called from Non-IMS users and vice versa
privacy to from headers
Privacy – To/From headers
  • Request Privacy by an extra header
  • Where is the caller identity transported?
    • Remote Party ID?
    • From header?
  • If From header is the solution then
    • P-CSCF needs to be able to change it
    • P-CSCF should not be mandated to act as B2BUA because of that, i.e. send the changed value also to the UE in responses.
xml bodies and p headers
XML Bodies and P-headers
  • 3GPP specific information currently is transported in a XML body
  • IETF: XML should be opaque to Proxies
  • CSCF’s are transparent B2BUAs
  • 3GPP is basically willing to migrate to P-headers for most of the information
  • It may be more appropriate to transport 3G specific data which is purely not SIP related (e.g. 3GPP filtering related) within XML-bodies
  • Problems?
  • ID (intended as informational RFC) will be brought up in the near future, listing all the 3GPP specific information which should go into P-headers.
p headers
P-Headers
  • Charging-Information
    • ICID (IMS Charging ID) and GPRS CID for correlation and identification purposes – ICID generated by first IMS network entity – globally unique
    • Charging Control Function (CCF) Address
  • Visited Network ID
  • Cell-ID
  • Originally dialed Public User ID (Target Address-of-Record)
    • 3GPP specific or general requirement?
    • Relation to Visited Header?
    • P-Header?
    • Possible to be solved with To-Header manipulation? (Backwards compatibility …)
security
Security
  • AKA via HTTP-Digest
    • How AKA works
    • MD5 versus RES
  • Integrity Protection
    • HTTP-Digest extension
    • IPSec
  • Draft Arkko Sip-Sec agree
  • Key Transport (CK, IK) from S-CSCF to P-CSCF
    • (S)MIME?
    • P-Header?
    • XML Body?
    • Tag in existing header?
