accelerating business intelligence with oracle timesten in memory database

Accelerating Business Intelligence with Oracle TimesTen In-Memory Database

Jonathan Bar-Gil, ISV/OEM Principal Sales Consultant

the quest for response time
The Quest for Response Time
  • Failure to meet service level agreements (SLA)
    • Due to long response time
  • Customer churns
    • Competitive products offer better response time
  • Decreased user productivity and decreased customer satisfaction
    • Unhappy customers
  • Loss of revenue and decreased profitability
    • Effect of lost business and opportunities
  • Why is Response Time Important?
improving application response time
Improving Application Response Time
  • Define business requirements for latency
  • Evaluate solutions
  • Understanding Latency Requirements

Result-set Cache (Client/Server)

Disk Cache Array

Magnetic Disks

In-Memory Database

Flash Storage, SSD

Network round trips

Buffer Cache

L A T E N C Y

Slower

Faster

timesten in memory database
TimesTen In-Memory Database

Over a Decade of Innovation

enabling the real time world
Enabling The Real-Time World

Market Data,

Market Events,

Order Matching,

Trading

Real-Time Analytics -

Interactive Dashboard

Data Mart, Scorecard

Authorization,

Online Charging,

Location-Based

Services

Real-Time Applications

Instantly Responsive / Highly Scalable / Always-On

Mainstream 64-bit

Processors

Large Capacity RAM

Fast

Networks

Key Enabling Technology

eCommerce,

Personalization,

Real-Time Ad

Serving

agenda
Agenda

TimesTen In-Memory Database

  • Quick Overview
    • Oracle TimesTen In-Memory Database and
    • Oracle In-Memory Database Cache
  • Proven technology for OLTP workloads
  • Expansion into Business Intelligence
  • Summary
agenda1
Agenda

TimesTen In-Memory Database

  • Quick Overview
    • Oracle TimesTen In-Memory Database and
    • Oracle In-Memory Database Cache
  • Proven technology for OLTP workloads
  • Expansion into Business Intelligence
  • Summary
oracle timesten in memory database memory optimized standalone database
Oracle TimesTen In-Memory DatabaseMemory-Optimized Standalone Database

Telco ServicesFinancial Services

CRM, Portal, SaaS,Customer-facing Applications

Intelligence, Defense, Real-TimeBAM & BI

  • Persistent, memory-optimized relational database
  • Delivers extreme performance for real-time applications
  • Highly available
  • Deployed in the middle tier, close to the application
  • Operates as a standalone database
  • Or …

Application

Application

Application

oracle in memory database cache low cost extreme performance in the middle tier

Business

Applications

Business

Applications

Cached tables

Cached tables

In-Memory Database Cache

Real Application Cluster

Automatic Storage Management

Oracle In-Memory Database CacheLow-Cost Extreme Performance in the Middle-tier
  • Accelerates Oracle Database applications
  • Utilizes middle-tier resources
  • Data cached in Oracle TimesTenIn-Memory Database
    • Database tables
    • Subsets of rows and columns
  • Fast, consistent response times
    • High transaction throughput
  • Standard SQL interface
    • Synchronized with Oracle Database
oracle timesten in memory database optimized in memory database technology

Client-Server Application

TimesTen Client Lib

Directly-Linked Application

TimesTen Libraries

Checkpoint Files

Log Files

Memory-Resident Database

Oracle TimesTen In-Memory DatabaseOptimized In-Memory Database Technology
  • In-memory RDBMS
    • Entire database in memory
    • Persistent database
    • Optimized memory layout and algorithms
  • Exceptional performance
    • Instantaneous response time
    • High throughput
    • Embeddable
  • Persistent and durable
    • Transactions with ACID properties
    • Flexible options for data persistence to disk
  • Standard SQL and PL/SQL with
    • JDBC, ODBC, OCI, Pro*C
    • Data types compatible with Oracle Database

Client/Server

JDBC / ODBC / OCI / Pro*c

Fast data

access

lightning fast response time

7

Millionths of

a second

1.78

Millionths of

a second

Lightning Fast Response Time

One Exalogic

Compute Node

Oracle TimesTen In-Memory Database 11.2.2.0 - Intel Xeon 5670 2.93Ghz, 2 CPUs, 6 cores/CPU - Oracle Linux 5.6

throughput scalability for oltp workloads
Throughput Scalability for OLTP Workloads

Throughput on One Compute Node

  • Memory-optimized data layout
  • Memory-optimized access methods
  • No locks acquired on reads
  • 100% Read Workload on Exalogic

Over 4.14M Reads per Sec

throughput scalability for oltp workloads1
Throughput Scalability for OLTP Workloads

Throughput on One Compute Node

  • Memory-optimized data layout
  • Memory-optimized access methods
  • No locks acquired on reads
  • No waits of reads on updates (versioned concurrency control)
  • Multi-threaded logging
  • Read-Update-Insert-Delete Workload on Exalogic

Over 2.13M TPS

slide14
What If .. you have an existing Oracle Database?How to enable your application to use in-memory technology?

Use TimesTen as an In-Memory Database Cache

Oracle In-Memory Database Cache

A product option for Oracle Database Enterprise Edition

timesten in memory database cache

Application

Application

Application

TimesTen In-Memory Database Cache

Application

Transactions

Application

Transactions

  • Runs in the middle-tier
  • Caches subset of Oracle database
  • Full featured in-memory RDBMS
  • Accelerates applications
  • Scale up, Scale out
  • Read/write caching, local or global
  • Cache pre-loaded/loaded-on-demand
  • Automatic synchronization
  • Built-in high availability
  • Accelerates Oracle Database Applications

IMDB Cache Grid

Automatic

Synchronization

scale out with timesten in memory cache grid

Application

Standby

Active

Standby

Active

Standby

Active

Standby

Active

Standby

Active

Scale Out with TimesTen In-Memory Cache Grid

Grid Member

  • On-demand addition/ removal of grid members
  • Built-in HA
  • Integration with Oracle Clusterware for automated failover and recovery
slide17
What does TimesTen offer for high availability?

TimesTen Replication provides real-time replication of transaction data between TimesTen databases

real time replication high availability low latency durability on line upgrades

Standby

Active

Subscriber

Subscriber

Subscriber

Real-Time ReplicationHigh Availability, Low-Latency Durability, On-Line Upgrades

Application Reads on Hot Standby

  • Real-time transactional replication
  • High performance
    • Synchronous / asynchronous
    • Memory-to-memory replication of log records
    • Parallel send of log streams
    • Parallel apply of changes on Standby
    • Data compression
  • Multiple topologies, including
    • Active Standby Pair + Read-only Subscribers with parallel apply of changes on Subscribers
    • Active Active – Split Workload
  • LAN and WAN configurations
  • Online upgrades – no downtime

Application

Transactions

  • Read-only subscribers
  • Reader Farm
  • Disaster Recovery
read write and read only caching

Standby

Active

Read-write and Read-only Caching

Application

Transactions

Hot Standby available for reads

  • Read-write caching
    • Transactions applied to Active
    • Parallel replication of committed transactions to Standby
    • Parallel writethrough of committed transactions to Oracle database
  • Read-only caching
    • Multi-stream refresh of committed transactions from Oracle database
    • Parallel replication of refresh transactions to Standby
  • Application continues operating even if connection to Oracle database is down
  • High Availability

Automatic

Synchronization

agenda2
Agenda

TimesTen In-Memory Database

  • Quick Overview
    • Oracle TimesTen In-Memory Database and
    • Oracle In-Memory Database Cache
  • Proven technology for OLTP workloads
  • Expansion into Business Intelligence
  • Summary
oracle timesten with exalogic and exadata extreme performance on oracle exa stack
Oracle TimesTen with Exalogic and ExadataExtreme Performance on Oracle Exa Stack
  • TimesTen is deployed in the middle-tier
  • TimesTen can be a cache to Oracle Database, including Exadata
  • TimesTen is certified on Exalogic

In-Memory Database Cache Grid

Application

Tier

Database

Tier

slide22
TimesTen In-Memory Database Cache GridScalability on Exalogic – Mobile Prepaid Subscriber Application

Java/JDBC application

5 different transactions

Authenticate user/account

Check account balance

Update account profile

Credit or debit account

Search for accounts that meet certain criteria

Transactions executed in TimesTen and propagated asynchronously to Oracle DB

TimesTenIn-Memory Cache Grid on Exalogic

8 compute nodes (One Quarter Rack)

4 grid members/compute node, 32 grid members total

40 TB shared storage

Presentation

Exalogic Cloud

timesten on exalogic extreme performance
TimesTen on Exalogic – Extreme Performance
  • Scalability and Peak Throughput on Exalogic

8.7 Million TPS

agenda3
Agenda

TimesTen In-Memory Database

  • Quick Overview
    • Oracle TimesTen In-Memory Database and
    • Oracle In-Memory Database Cache
  • Proven technology for OLTP workloads
  • Expansion into Business Intelligence
  • Summary
how is timesten used in exalytics
How Is TimesTen Used in Exalytics?
  • TimesTen is used as an in-memory cache for BI aggregates
  • Summary Advisor determines what data to load using ETL tool within OBI

Runs constantly with near zero impact

Optimizes for maximum impact. Administrator override available

Scripts persisted for cache update

in memory analytics
In-Memory Analytics
  • Adaptive In-Memory Cache
        • Decides what gets stored in-memory
        • Adapts to change in analytic workload
  • TimesTen In-Memory Database
    • Enhanced with columnar compression
    • Enhanced with analytic functions

1 TB RAM

TimesTen In-Memory Database

Adaptive In-Memory Cache

in memory columnar compression
In-Memory Columnar Compression
  • Columnar compression applied to one or more columns of a table
  • Optimized for in-memory storage
  • Suitable of OLTP and BI workloads
  • Compressed data remains available for online access
  • Space reduction of over 5x on sample customer data
in memory columnar compression how
In-Memory Columnar Compression – How?
  • One or more columns in a table can be compressed called a compressed column group
  • Dictionary table is created for each compressed column group
  • The compressed column group contains a pointer to row in the dictionary
  • Width of pointer can be 1, 2, or 4
olap reporting features
OLAP Reporting Features
  • Enhanced SQL aggregation
    • GROUPING SETS
    • CUBE
    • ROLLUP
  • Analytic functions
    • Ranking functions
    • Statistical functions
    • With/without partitions and with/without sliding windows
  • Query optimization and query processing optimized for in-memory data management
grouping sets example
GROUPING SETS – Example

The example specifies the grouping sets of (region_name, country_name), state_province, and grand totals

analytic functions rank example
Analytic functions – RANK Example

Use the RANK function to rank the first 10 employees in department 80 based on their salary and commission. Identical salary values receive the same rank and cause nonconsecutive ranks.

agenda4
Agenda

TimesTen In-Memory Database

  • Quick Overview
    • Oracle TimesTen In-Memory Database and
    • Oracle In-Memory Database Cache
  • Proven technology for OLTP workloads
  • Expansion into Business Intelligence
  • Summary
summary
Summary
  • TimesTen enables the real-time enterprise
  • Optimized for OLTP and Business Intelligence workloads
  • Complements Exadata with microsecond response time for real-time applications
  • Certified on Exalogic
  • Optimized for Exalytics
