  1. SATELITFunCube-1 (AO-73) 9A2EY ŽELJKO ULIP RADIO KLUB ”ZAGREB”

  2. MEHANIČKA STRUKTURA

  3. RASPORED MODULA

  4. PA Board

  5. CCT Board

  6. RF Board

  7. ASIB

  8. EPS B OARD (GOMSpace)

  9. AntS (ISIS)

  10. SOLARNI PANELI

  11. ISIPOD ZACube-1 FUNCube-1 HiNCube

  12. RAKETA DNEPR U PODZEMNOM SILOSU

  13. 21.11.2013. 07.10 UTC

  14. GB NRC, BLETCHLEY PARK, NR LONDON

  15. GRAHAM, G3VZV

  16. NAČIN RADA LINEARNI TRANSPONDER (CW, SSB) UP LINK: 435.150 – 435.130 MHz (LSB) DOWN LINK: 145.950 – 145.970 MHz (USB), 300 mW (TRANSPONDER JE UKLJUČEN KAD JE SATELIT U ZEMLJINOJ SJENI) TELEMETRIJA BPSK-1200 (SSB) 145.935 MHz ± DOPPLER, 300/30 mW 300 mW KAD JE TRANSPONDER ISKLJUČEN 30 mW KAD JE TRANSPONDER UKLJUČEN

  17. ZONA POKRIVANJA

  18. LINEARNI TRANSPONDER (CW) ZLATKO 9A2SB

  19. LINEARNI TRANSPONDER (SSB) Branko, 9A3ST

  20. 02.12.2013. 20.47-20.55 UTC

  21. FUNcube Dongle

  22. SKICA: NADER, ST2NH AUTOMATSKO SLANJE PRIMLJENIH TLM PODATAKA

  23. TELEMETRIJA BPSK 1200

  24. FT-817 (RX) IC-7000 + HM PA 50W (TX) W570 RFL G-5500 CTRL

  25. TONNA VHF YAGI 2 X 9 EL RHCPTONNA UHF YAGI 2 X 19 EL RHCP ANTENSKI SUSTAV YAGI VHF (144 – 146 MHz) YAGI UHF (430 – 440 MHz)

  26. 73 73
