Presentation Transcript
slide1

COGN1001: Introduction to Cognitive ScienceTopics in Computer Science Formal Languages and Models of Computation

Qiang HUO

Department of Computer Science

The University of Hong Kong

(E-mail: [email protected])

outline
Outline
  • What is a Formal Language?
  • Phrase-Structure Grammars
  • Finite State Automata
  • Formal languages and Models of Computation
natural language vs formal language
Natural Language vs. Formal Language
  • Natural language:

written and/or spoken languages in the world, suchas Chinese, English, Japanese, German, French, Spanish, etc.

    • Syntax
    • Semantics
  • Formal language:

a language specified by a well-defined set of rules ofsyntax.

  • A study of formal languages is important to computer science.
    • For example,we need to understand what kind of statements are acceptable in the Cprogramming language. This is the task of acompiler of a programminglanguage.
formal language
Formal Language
  • We will describe the sentences of a formal language using agrammar.
    • How can we determine whether a combination of words is a validsentence in a formal language?
    • How can we generate the valid sentences of a formal language?
  • We will only be interested in thesyntax, not thesemantics(meaning), of alanguage.
slide5
a sentence is made up of a noun-phrase followed by a verb-phrase;
  • a noun-phrase is made up of an article followed by an adjective followed by a noun, or
  • a noun-phrase is made up of an article followed by a noun;
  • a verb-phrase is made up of a verb followed by an adverb, or
  • a verb-phrase is made up of a verb;
  • an article isa, or
  • an article isthe;
  • an adjective islarge,
  • an adjective ishungry;
  • a noun israbbit, or
  • a noun ismathematician;
  • a verb iseats, or
  • a verb ishops;
  • an adverb isquickly, or
  • an adverb iswildly.

If we define a subset of English using the list of rules shown here that describe how a validsentence can be produced, how the language looks like?

example a subset of english
Example: a Subset of English
  • From the previous rules we can form valid sentences using a series ofreplacementsuntil no more rules can be used.
    • For instance, the valid sentencethe large rabbit hops quicklycan beobtained by the following sequence of replacements:
      • sentence
      • noun-phrase verb-phrase
      • article adjective noun verb-phrase
      • article adjective noun verb adverb
      • theadjective noun verb adverb
      • the largenoun verb adverb
      • the large rabbitverb adverb
      • the large rabbit hopsadverb
      • the large rabbit hops quickly
    • Some other valid sentences:
      • a hungry mathematician eats wildly
      • the rabbit eats quickly
    • An invalid sentence:the quickly eats mathematician
some terminologies
Some Terminologies
  • Avocabulary(oralphabet)Vis a finite, nonempty set ofelementscalledsymbols.
  • Aword(orsentence) overVis a string of finite length of elements ofV .
  • Theempty stringornull string, denoted by , is thestring containingno symbols.
  • The set of all words (orsentences) over V is denoted by V*.
  • AlanguageoverVis a subset of V* .
  • Example: In English,
    • ThealphabetV consists of English letters and other symbols.
    • Aword(orsentence) overVis a finite string of symbols.
    • The meaningful word(orsentence) of English is a subset ofV* .
how to specify a language
How to specify a language?
  • to list all the words (or sentences) in the language; or
  • to give some criteria that a word (or a sentence) must satisfy to be in the language;or
  • to specify a language through the use of agrammar, such as the setof rules we gave in the previous example of English subset.
outline9
Outline
  • What is a Formal Language?
  • Phrase-Structure Grammars
  • Finite State Automata
  • Formal languages and Models of Computation
what is a phrase structure grammar
What is a Phrase-Structure Grammar?
  • Aphrase-structure grammaris G = (V,T,S,P), where
    • V is a vocabulary;
    • T is a subset of V consisting of terminal elements (i.e., the elementsof V which can not be replaced by othersymbols);
      • The elements of N = V–Tare callednonterminal symbols(i.e., the elements ofV which can be replaced by other symbols)
    • S is astart symbolfrom V (i.e., the element of the V that we alwaysbegin with;
    • P is a set ofproductions.
      • We denote by w0w1 the production that specifies that w0 canbe replaced by w1.
      • Every production in P must contain at least one nonterminal onits left side.
example a phrase structure grammar
Example: a Phrase-Structure Grammar
  • G = (V,T,S,P), where
    • V = { a,the,large,hungry,rabbit,mathematician,eats,hops,quickly,wildly; sentence, noun-phrase, verb-phrase, article,adjective, noun, verb,

adverb };

    • T = { a,the, large,hungry,rabbit,mathematician,eats,hops,quickly, wildly };
      • V–T= { sentence, noun-phrase, verb-phrase, article, adjective, noun, verb, adverb};
    • S = sentence;
    • Production rules:P
slide12
P = {

sentencenoun-phrase verb-phrase,

noun-phrasearticle adjective noun,

noun-phrasearticle noun,

verb-phraseverb adverb,

verb-phraseverb,

articlea,

articlethe,

adjectivelarge,

adjectivehungry,

nounrabbit,

nounmathematician,

verb eats,

verbhops,

adverbquickly,

adverbwildly}

some terminologies13
Some Terminologies

Let G = (V,T,S,P) be a phrase-structure grammar.

Let w0 = lz0r andw1 = lz1r be strings over V .

  • If z0z1 is a production of G, we say that w1 isdirectly derivablefrom w0 and we write w0w1.
    • Example:

theadjective noun verb adverb the largenoun verb adverbbecause

adjective large

  • If w0,w1, … ,wn, n 0, are strings over V such that

w0w1, w1w2, … ,wn-1wn, then

    • we say that wn isderivablefromw0, and
    • we write w0wn.
    • The sequence of steps used toobtain wn from w0 is called aderivation.
slide14
Example:sentencethe large rabbit hops quickly

via the followingderivation:

sentence  noun-phrase verb-phrase,

noun-phrase verb-phrase article adjective noun verb-phrase,

article adjective noun verb-phrase article adjective noun verb

adverb,

article adjective noun verb adverbtheadjective noun verb adverb,

the adjective noun verb adverbthe largenoun verb adverb,

the largenoun verb adverbthe large rabbitverb adverb,

the large rabbitverb adverbthe large rabbit hopsadverb,

the large rabbit hopsadverbthe large rabbit hops quickly.

what is the language generated by a phrase structure grammar
What is the language generated by a Phrase-Structure Grammar?
  • Let G = (V,T,S,P) be a phrase-structure grammar.
  • Thelanguage generated byG(or thelanguageofG), denotedby L(G), is the set of all strings of terminals that are derivable fromthe starting symbolS.

L(G) = { wT* | Sw }

slide16
Example:Suppose G = (V,T,S,P), where V = {a,b,A,B,S},

T = {a,b},S is the start symbol, and

P = { SABa, ABB, Bab, ABb }.

All the “sentences" (words) generated by this grammar are

{abababa, ba}, since

S  ABa  BBBa  abababa

S  ABa  ba

  • Example:Let G be the grammar with V = {S,0,1},T = {0,1},

starting symbol S, and production rules

P ={ S11S, S0 }.

L(G) = {(11)n0 | n = 0,1,2, …}.

how to construct a grammar that generates a given language
How to construct a grammar that generates a given language?
  • Example:

Find a phrase-structure grammar to generate the set

{ 0n1n | n = 0,1,2, … }

  • Solution:

G = (V,T,S,P), where

V = { S, 0, 1 },

T = { 0,1 },

S isthe start symbol, and

P = { S0S1,S }.

how to construct a grammar that generates a given language18
How to construct a grammar that generates a given language??
  • Example: Find a phrase-structure grammar to generate the set { 0m1n | m,n = 0,1,2, … }
  • Solution 1:G1 = (V,T,S,P), where

V = {S,0,1}, T = {0,1}, Sis the start symbol, and

P = { S0S, SS1, S}

  • Solution 2:G2 = (V,T,S,P), where

V = {S,A,0,1}, T = {0,1},S is the start symbol, and

P = { S0S, S1A, S1, A1A, A1, S }

Two grammars can generate the same language!

how to construct a grammar that generates a given language19
How to construct a grammar that generates a given language???
  • There are many techniques from thetheory ofcomputationwhichcan be used to systematically constructa grammar for a given formallanguage, but
  • This is beyond the scope of this course.
types of phrase structure grammars 1
Types of Phrase-Structure Grammars (1)
  • Phrase-structure grammars can be classified according to thetypes of productionsthat are allowed.
  • Such a classification scheme introduced by NoamChomsky is as follows:
    • Type 0 grammar: has no restrictions on its production.
    • Type 1, or context-sensitive, grammar:can haveproductions only of theform
      • w1 w2, where l(w1)  l(w2), or of the form
      • w1.
    • Type 2, or context-free grammar:can haveproductions only of the form
      • A w2, where A is a nonterminal symbol.
types of phrase structure grammars 2
Types of Phrase-Structure Grammars (2)
    • Type 3, or regular grammar:can have productions only of the form
      • AaB,
      • Aa,
      • S ,

where A and B are nonterminal symbols, S is the start symbol, and ais aterminal symbol.

  • Alanguagegenerated by a
    • type 1 grammaris called acontext-sensitive language;
    • type 2 grammaris called acontext-free language;
    • type 3 grammaris called aregular language.
examples
Examples
  • { 0m1n | m,n = 0,1,2, … } is a regular language, since it can begenerated by a regular grammarGwith P:

P = { S0S, S1A, S1, A1A, A1, S }

  • { 0n1n | n = 0,1,2, … }is a context-free language, since it can begenerated by a context-free grammarGwith P:

P = { S0S1, S }

  • { 0n1n2n | n = 0,1,2, … }is a context-sensitive language, since itcan be generated by a type 1 grammar

G = (V,T,S,P) withV = {0,1,2,S,A,B}, T = {0,1,2}, starting symbol S, and productions

P = { S0SAB, S, BAAB, 0A01, 1A11, 1B12, 2B22 };

but not by any type 2 grammar.

example a phrase structure grammar23
Example: a Phrase-Structure Grammar
  • G = (V,T,S,P), where
    • V = { a,the,large,hungry,rabbit,mathematician,eats,hops,quickly,wildly; sentence, noun-phrase, verb-phrase, article,adjective, noun, verb,

adverb };

    • T = { a,the, large,hungry,rabbit,mathematician,eats,hops,quickly, wildly };
      • V–T= { sentence, noun-phrase, verb-phrase, article, adjective, noun, verb, adverb};
    • S = sentence;
    • Production rules:P
slide24
P = {

sentencenoun-phrase verb-phrase,

noun-phrasearticle adjective noun,

noun-phrasearticle noun,

verb-phraseverb adverb,

verb-phraseverb,

articlea,

articlethe,

adjectivelarge,

adjectivehungry,

nounrabbit,

nounmathematician,

verb eats,

verbhops,

adverbquickly,

adverbwildly}

example backus naur form
Example: Backus-Naur Form
  • What is the Backus-Naur Form of the grammar for a subset of English described before?

::=

::=

|

::= |

::= a | the

::= large | hungry

::= rabbit | mathematician

::= eats | hops

::= quickly | wildly

what is backus naur form bnf
What is Backus-Naur Form (BNF)?
  • There is another notation that is used to specify a type 2 (context-free) grammar, called theBackus-Naur Form:
    • all productions having the same nonterminal as their left-hand sideare combined with the different right-hand sides of these productions, each separated by a bar ( | ), with
      • nonterminal symbols enclosed in angular brackets (<>), and
      • the symbol  replaced by ::=
  • Example:The Backus-Naur form for a grammar that produces signedintegers is as follows:

::=

::= +|-

::= |

::= 0|1|2|3|4|5|6|7|8|9

what is a derivation or parse tree
What is a Derivation (or Parse) Tree?
  • A derivation in the language generated by a context-free grammar can berepresented graphically using an ordered rooted tree, called aderivation (orparse) tree:
    • the root represents the starting symbol,
    • internal vertices represent nonterminals,
    • leaves represent terminals, and
    • the childrenof a vertex are the symbols on the right side of a production, in order from left to right, where the symbolrepresented bythe parent is on the left-hand side.
example
Example
  • Construct a derivation tree for the derivation of the sentence,the hungry rabbit eats quickly, discussed previously.
how to determine whether a string is in the language generated by a context free grammar
How to determine whether a string is in the language generated by a context-free grammar?
  • Top-down parsing:
    • begins with the starting symbol and proceedsby successively applying productions to see if the given string can bederived.
  • Bottom-up parsing:
    • work backwards.
slide30
Top-down parsing:

S AB

S AB CaB

S  AB CaB cbaB

S  AB  CaB  cbaB  cbab

  • Example:Determine whether the word cbab belongs to the L(G), where, G = (V,T,S,P) with

V = {a,b,c,A,B,C,S},

T = {a,b,c},

S is the starting symbol, and the productions are

S  AB

A  Ca

B  Ba

B  Cb

B  b

C  cb

C  b

  • Bottom-up parsing:

Cab cbab

Ab Cab  cbab

AB Ab  Cab  cbab

SAB Ab  Cab  cbab

outline31
Outline
  • What is a Formal Language?
  • Phrase-Structure Grammars
  • Finite State Automata
  • Formal languages and Models of Computation
finite state machines with no output
Finite State Machines with No Output
  • Finite-state machines with no output are also calledfinite-state automata.
  • Finite-state automata do not generate output. But they have a set of specialstates, calledfinal states.
  • A finite-state automaton is often used for language recognition.
    • This application plays a fundamental role in the design and construction of compliers for programming languages.
what is a deterministic finite state automaton
What is a Deterministic Finite-State Automaton?
  • Afinite-state automatonM = (S,I,f,s0,F) consists of
    • a finite set S ofstates,
    • a finiteinput alphabetI,
    • atransition functionf that assigns a state to every pair of state andinput,
    • aninitial states0, and
    • a subset F of S consisting offinal states.
how to represent a finite state automaton
How to represent a Finite-State Automaton?
  • We can represent a finite-state automaton using either a state table or a state diagram. Final states are indicated in the state diagram by using double circles.
  • What is the state table of the above finite-state automaton?
what is the language recognized by a given finite state automaton
What is the language recognized by a given Finite-State Automaton?
  • Aninput string is recognizedoracceptedby an automaton M if thestring takes the automaton to one of its final states.
  • The languagerecognized by an automaton M,denoted by L(M), is the set of all strings that are recognized by M.

The language recognized by the above finite-state automaton M is L(M) = { 0n,0n10x | n=0,1,2, …, and x is any string }.

deterministic vs nondeterministic finite state automata
DeterministicvsNondeterministicFinite-State Automata
  • The finite-state automata discussed so far are deterministic, since for eachpair of state and input value there is a unique next state given by the transitionfunction.
  • There is another important type of finite-state automaton in which there maybe several possible next states for each pair of state and input value.
    • Suchmachines are callednondeterministic.
  • Nondeterministic finite-state automataare important in determiningwhich languages can be recognized by a finite-state automaton.
what is a nondeterministic finite state automaton
What is a Nondeterministic Finite-State Automaton?
  • Anondeterministic finite-state automaton

M = (S,I,f,s0,F)consists of

    • a finite set S ofstates,
    • a finiteinput alphabet I,
    • atransition function f that assignsa set of statesto each pair ofstate and input,
    • aninitial state s0, and
    • a subset F of S consisting offinal states.
how to represent a nondeterministic finite state automaton
How to represent a NondeterministicFinite-State Automaton?
  • Using a state table:for each pair of state and input value we give a list ofpossible next states.
  • Using a state diagram: include an edge from each state to all possible nextstates, labelling edges with the input(s) that lead to this transition.
slide39
What is the language recognized by a given Nondeterministic Finite-State Automaton?
  • What does it mean for a nondeterministic finite-state automaton torecognizea string x = x1x2 … xk?
    • x1 takes the starting state s0 to a set S1of states;
    • x2 takes each of the states in S1 to a set of states.

Let S2 be the union ofthese sets;

    • Continue this process, including at a stage all states that can be obtained using
      • a stateobtained at the previous stage and
      • the current input symbol;
    • The string x isrecognized oraccepted if there is a final state in the set ofall states that can be obtained from s0using x.
  • The language recognized by a nondeterministic finite-state automatonis the set of all strings recognized by this automaton.
example40
Example
  • Determine the language recognized by the nondeterministic finite-state automaton M shown in the following figure.
  • Solution: L(M) = {0n, 0n01, 0n11 | n=0,1 ,2, … }.
an important fact
An Important Fact
  • Theorem:

If the languageL is recognized by a nondeterministic finite-state automaton M0, then L is also recognized by a deterministic finite-stateautomaton M1.

  • Two finite-state automata are calledequivalentif they recognize the samelanguage.
outline42
Outline
  • What is a Formal Language?
  • Phrase-Structure Grammars
  • Finite State Automata
  • Formal languages and Models of Computation
build an fsa from a regular grammar
Build an FSA from a Regular Grammar
  • Suppose that G = (V,T,S,P) is a regular grammar generatingthe set L(G), where each production is of the form

S ,Aa, or AaB, with a being a terminal symbol, A and Bare nonterminal symbols.

  • We can build a nondeterministic finite-state machine

M = (S,I,f,s0,F) that recognizes L(G).

slide44
M = (S,I,f,s0,F)
    • S: contains a statesA for each nonterminal symbol A of G,and an additional final state sF ;
    • The start state s0 is the state formed from the start symbol S;
    • A transition from sA tosF on input of a is included if

Aais a production;

    • A transition from sAto sB on input of a is included if

AaBis a production;

    • s0 will also be a final state if S is a production.
  • It can be shown that L(M) = L(G).
example45
Example
  • Construct a nondeterministic finite-state automaton that recognizes the language generated by the regular grammar G = (V,T,S,P)where
    • V = {0,1,A,S},
    • T = {0,1}, and
    • the productions in P are

S1A,S 0, S,

A 0A, A 1A, and

A 1.

construct a regular grammar from an fsa
Construct a Regular Grammar from an FSA
  • Suppose thatM = (S,I,f,s0,F) is a finite-state machine with the property that s0is never the next state for a transition.
  • A regular grammar G = (V,T,S,P) can be defined as follows:
    • V is formed by assigning a symbol to each state of S and eachinput symbol inI;
    • T is formed from the input symbols in I;
    • S is the symbol formed from the start state s0;
    • The set P of productions is formed from the transitions inM:
      • As a is included if the state s goes to a final state underinput a, where As is the nonterminal symbol formed from s;
      • As aAt is included if the state s goes to t under input a.
      • S is included if and only if L(M).
  • It can be shown that L(G) = L(M).
example47
Example
  • Find a regular grammar that generates the language recognized by the finite-state automaton shown in the following figure:

Soultion:G = (V,T,S,P) where

  • V = {S,A,B,0,1}, the symbols S,A, andB correspondto the states S0,S1, and S2, respectively;
  • T = {0,1};
  • S is the start symbol; and
  • The productions are

S  0A, S 1B, S 1, S ,

A 0A, A 1B, A 1,

B 0A, B 1B, B 1.

more powerful types of machines 1
More Powerful Types of Machines (1)
  • The main limitation of finite-state automata is their finite amount of memory.This prevents them from recognizing languages that are not regular, such as{0n1n|n = 0,1,2,…}.
  • A more powerful model of computation calledpushdown automatoncan beused to recognize the above language.
  • Theorem:A set is recognized by apushdown automatonif and only if itis the language generated by acontext-free grammar.
  • However, there are sets that cannot be expressed as the language generatedby a context-free grammar. One such set is { 0n1n2n|n = 0,1,2, … }.
more powerful types of machines 2
More Powerful Types of Machines (2)
  • Actually, there exists an even more powerful machine than pushdown automata, calledlinear bounded automatawhich
    • can recognizecontext-sensitive languagessuch as the sets

{ 0n1n2n | n=0,1,2, …}; but they

    • cannot recognize all the languages generated by phrase-structure grammars.
  • The most general model of a computing machine is the so-calledTuring Machinewhich can
    • recognize all languagesgenerated by phrase-structure grammars;
    • model all the computationsthat can be performed on a computing machine.
future scientists vs engineers
Future: Scientists vs Engineers
  • Scientiststry tounderstand what is .
  • Engineerstry tocreate what has never been !
    • The really great engineers have astrong background in science so that they thoroughly understand what is.
    • These special people also have to have theimaginationto create whathas never been, and this is what really sets them apart !
  • The methodology of engineering research:
    • There exists some phenomenon of nature for which a model shouldbe found;
    • The mathematical analysis is just a tool that helps one to find this model;
    • The results of any analysis should be confirmed by experiments.
  • Future:What you make it to be !
reference
Reference
  • Sections 11.1, 11.3, 11.4 of the following book
    • Kenneth H. Rosen, Discrete Mathematics and Its Applications, Fifth Edition, McGraw-Hill International Editions, 2004; or
  • The relevant sections of the above book in earlier editions.
ad
