Presentation Transcript
Anaerobic microbes oxygen detoxification without superoxide dismutase l.jpg

Anaerobic Microbes: Oxygen Detoxification Without Superoxide Dismutase

Presented by

J. Spencer King

and

Seth I. Berger


Before we begin a few questions l.jpg
Before we begin… a few questions

  • Why don't pure anaerobes use SOD to remove superoxide, and Catalase to remove Peroxides?

  • SOR in p. furiosus functions efficiently 75° C below the optimal growth temperature of p. furiosus. Why do the authors of the paper believe this is so?

Berger-King 9.17.03


Verbosity to obscure ignorance l.jpg

Verbosity to obscure ignorance

will not be tolerated.


Before we begin a few questions4 l.jpg
Before we begin… a few questions

  • Why don't pure anaerobes use SOD to remove superoxide, and Catalase to remove Peroxides?

  • SOR in p. furiosus functions efficiently 75° C below the optimal growth temperature of p. furiosus. Why do the authors of the paper believe this is so?

Berger-King 9.17.03


Answers l.jpg
Answers

  • Because SOD and Catalase both produce Oxygen.

  • The only time that p. furiosus is exposed to oxygen is when the deep sea vent waters mix with the surrounding cold seawater.


Brief synopsis of anaerobes l.jpg
Brief Synopsis of Anaerobes

  • Aerotolerant Anaerobes

    • O2 not Toxic

    • O2 independent metabolism

  • Facultative Anaerobes

    • Can grow with or without O2

    • Change metabolism depending on O2 concentration

  • Strict Anaerobes

    • O2 is Toxic

Berger-King 9.17.03


About pyrococcus furiosus l.jpg
About Pyrococcus furiosus

  • Archea

  • Strict Anaerobe

  • Hyperthermophilic

    • Deep sea vents

      • 70° to 100° C

      • Up to 200 atm

  • Irregular cocci shape

  • Polar flagella group

  • Hydrogen important in metabolism

Berger-King 9.17.03


Phylogenetic location l.jpg
Phylogenetic location

Berger-King 9.17.03


Superoxide o 2 l.jpg
Superoxide O2-

  • Present in all aerobic environments

    • Molecular oxygen has strong reduction activity

  • Unstable free radical – very toxic

    • Reacts with H2O2 to from hydroxyl radicals

  • Anaerobic organisms need protection too

    • Exposure to oxygen sometime during life cycle is possible especially for microbes living in water, like Pyrococcus furiosus

Berger-King 9.17.03


Superoxide dismutase and catalase l.jpg
Superoxide Dismutase and Catalase

  • Aerobic organism defense superoxide removal enzyme.

  • SOD removes O2-

  • Catalase then processes the H2O2 product

  • In some instances, non-specific peroxidases process the H2O2

Berger-King 9.17.03


Sod and catalase in anaerobes l.jpg
SOD and Catalase in Anaerobes

  • SOD and catalase genes not present in completed anaerobic genomes circa 1999

  • Why?

Both produce Oxygen!

  • Strict Anaerobes need some other method of removing toxic oxygen species…

Berger-King 9.17.03


Requirements for sod replacement l.jpg
Requirements for SOD replacement

  • Remove superoxide before it becomes toxic

  • Do not produce oxygen

  • Be active under the conditions required by Pyrococcus furiosus

  • Data suggests the mechanism for oxygen metabolism in Pyrococcus furiosus is Superoxide Reductase (SOR)


Preliminary steps l.jpg
Preliminary Steps

  • Select model organism

    • P. furiosis: a strictly anaerobic hyperthermophile

  • Isolate Putative Superoxide Dismutase(SOD)

    • Multistep Column Chromatography

    • Denaturing Gel Electrophoresis

      • ~14,000 Daltons

    • Direct Chemical Analysis

      • Contains Iron ( 0.5 atoms/mol) found using a inductively coupled argon plasma spectrometer (ICAP)


Preliminary steps14 l.jpg
Preliminary Steps

  • Clone gene

    • NH2-terminal amino acid sequence information

    • Locate in known genome

      • 124 amino acid protein(14,323 Da)

      • 14 bp downstream of rubredoxin (5895 Da)

        • Previously purified iron-containing redox protein


Sequence homologies l.jpg
Sequence Homologies

  • 40% identity to desulfoferrodoxin’s iron containing COOH-terminal region

  • 50% identity to neelaredoxin

    Both are redox proteins and have been shown to posses SOD activity.


Detecting sod activity l.jpg
Detecting SOD Activity

  • Standard SOD Assay

    • Steady-state generation of superoxide

      • Bovine Xanthine Oxidase + Xanthine

    • Superoxide reduces Cytochrome C directly

    • Measure A550increase rate

    • One unit of Activity is amount of protein needed to inhibit rate by 50%


Differences between sod and sor l.jpg
Differences Between SOD and SOR

  • SOR does not oxidize Cytochrome C when it was initially reduced with Sodium Dithionite.

    • It will subsequently oxidize it when a superoxide source is added.

  • No Oxygen is generated

  • Different behaviors in Assays


Bovine sod vs p furiosus sor l.jpg
Bovine SOD vs P. furiosus SOR

Figure 1.Pyrococcus furiosus superoxide reductase is not a superoxide dismutase. Reactions were performed as described (18) in 1-ml cuvettes under aerobic conditions. Superoxide produced by xanthine (0.2 mM) and xanthine oxidase (3.4 µg) directly reduced horse heart cytochrome c (20 µM), as shown by the increase in absorbance at 550 nm (A550) (A and B, trace 1). Addition of bovine SOD (3.4 µg, 1 U) inhibited the rate of reduction [(A), trace 2]. Excess SOD (40 U) prevented reduction completely [(A), trace 3], and additional SOD (60 U) had no further effect [(A), trace 4]. P. furiosus SOR (2.5 µg or 17 nM) also resulted in inhibition of reduction [(B), trace 2], and more SOR (6.2 µg) completely prevented reduction [(B), trace 3]. Addition of excess SOR (15 µg) caused oxidation of the reduced cytochrome c that was present before SOR addition [(B), trace 4]. Time zero is when SOR or SOD was added to the cuvettes (approximately 90 s after addition of xanthine oxidase). Under these conditions, A550 = 0.178 for fully oxidized cytochrome c.

SOD behavior

SOR behavior



Other genomes l.jpg
Other Genomes

  • Homologues are found in almost all complete genomes from anaerobes and a couple incomplete ones.

    • 116 – 138 Residues with 20 – 70% identity

  • Not found in any of the 16 available genomes of true aerobes (circa 1999)


Rubredoxin l.jpg
Rubredoxin

  • Adjacent to SOR in P. Furiosus genome

  • Known Electron Carrier

  • Oxidized by Superoxide

    • (opposed to cytochrome C which is reduced)

    • Can be measured by A490

  • Also autooxidizes in air

  • SOR increased rate of oxidation

    • Effect of SOR required superoxide

    • SOD decreased rate


Rubredoxin22 l.jpg
Rubredoxin

  • Found in almost ever known anaerobic genome despite function previously unknown.

  • NADP-ruberedoxin oxioreductase reduced rubredoxin.

    • Provides a mechanism for providing the reducing power for superoxide reduction.

  • HOWEVER, still produces peroxide

    • Must be removed, but not via O2 producing catalase


Bovine sod vs p furiosus sor23 l.jpg
Bovine SOD vs P. furiosus SOR

SOD behavior

Figure 2.Pyrococcus furiosus SOR is a rubredoxin-superoxide oxidoreductase. Reactions were done as in Fig. 1, except that reduced rubredoxin replaced cytochrome c. Superoxide directly oxidized P. furiosus rubredoxin, as shown by the increase in A490. Rubredoxin (28 µM) reduced by the addition of sodium dithionite (42 µM) slowly auto-oxidized upon exposure to air (A and B, trace 1). Addition of superoxide rapidly increased the rate of oxidation [(A) and (B), trace 2]. Catalase (10 U) had little effect [(A), trace 5], whereas in a separate experiment, bovine SOD (1 U) abolished the effect of superoxide [(A), trace 3], and excess SOD (10 U) slowed down even the spontaneous oxidation of rubredoxin [(A), trace 4]. In contrast, addition of P. furiosus SOR (1.2 µg) increased the rate of superoxide-dependent rubredoxin oxidation [(B), trace 3], and the rate increased with additional SOR [1.2 µg; (B), trace 4].

SOR behavior


Detoxification system l.jpg
Detoxification System

Figure 3. Model for detoxification of reactive oxygen species in anaerobes such as P. furiosus. Abbreviations are as follows: NROR, NAD(P)H-rubredoxin oxidoreductase; Rdred, reduced rubredoxin; Rdox, oxidized rubredoxin; XH2, unknown organic electron donor. Enzymes and proteins shown in bold were purified from P. furiosus; the others are hypothetical, based on genome sequence analyses.


Superoxide reductase l.jpg
Superoxide Reductase

  • SOR and NROR are both catalytically active and efficient at 25° C.

    • ~75° C cooler than P. furiosus growth temperature.

  • Exposure to O2 in the deep sea vents is limited to cold exposure to seawater

    • SOR and NROR together are a constitutively expressed defense mechanism which becomes active when the cell is exposed to a hostile environment.


Critiques l.jpg
Critiques

  • Sequence comparisons

    • %-similarity is not shown.

    • Sequence analysis methods not detailed

  • What to do with the H2O2 ?

    • Only hypothetical peroxidases

      • Peroxidase activity at 25°C?

  • Formatting and layout

    • Diagrams are informative but not attractive

    • More detailed materials and methods

      • Science publication requirements.

  • Fortuitousness of Fig 1 line B,3


Bovine sod vs p furiosus sor27 l.jpg
Bovine SOD vs P. furiosus SOR

Figure 1.Pyrococcus furiosus superoxide reductase is not a superoxide dismutase. Reactions were performed as described (18) in 1-ml cuvettes under aerobic conditions. Superoxide produced by xanthine (0.2 mM) and xanthine oxidase (3.4 µg) directly reduced horse heart cytochrome c (20 µM), as shown by the increase in absorbance at 550 nm (A550) (A and B, trace 1). Addition of bovine SOD (3.4 µg, 1 U) inhibited the rate of reduction [(A), trace 2]. Excess SOD (40 U) prevented reduction completely [(A), trace 3], and additional SOD (60 U) had no further effect [(A), trace 4]. P. furiosus SOR (2.5 µg or 17 nM) also resulted in inhibition of reduction [(B), trace 2], and more SOR (6.2 µg) completely prevented reduction [(B), trace 3]. Addition of excess SOR (15 µg) caused oxidation of the reduced cytochrome c that was present before SOR addition [(B), trace 4]. Time zero is when SOR or SOD was added to the cuvettes (approximately 90 s after addition of xanthine oxidase). Under these conditions, A550 = 0.178 for fully oxidized cytochrome c.

SOD behavior

SOR behavior


Follow up article l.jpg
Follow up Article

June 2002:

“The evidence for superoxide reduction by SOR is now overwhelming and comes from a variety of anaerobic and microaerophilic species...”

“The catalytic Fe site of SOR is structurally and electronically tuned to mediate superoxide reduction rather than oxidation...”

“NAD(P)H, via rubredoxin and NAD(P)H:rubredoxin oxidoreductase [is] the source of reductant...”

“What is still to be determined is the fate of the peroxide generated by the SOR reaction…”

Journal of Biological Inorganic ChemistryIssue: Volume 7, Number 6 Date: June 2002 Pages: 647 - 652
