  • Major question:

  • Recognition of microbes by dendritic cells (via TLRs) is essential to activate the adaptive response

  • Viruses can be strictly intracellular and usually don’t infect DCs

  • So, how do DCs present viral Ag??



  • Hypotheses:

  • Cells other than DCs (stromal cells) contribute to presentation of Ag

  • TLRs of stromal cells recognize pathogen-associated molecular patterns (PAMPs)


  • Experimental system:

  • Herpes simplex virus type 2 (HSV-2)

  • Thymidine kinase (TK) mutant can infect but not replicate

  • Infect vaginal epithelium of mice

  • Examine response to mucosal infection

  • Primarily measure activation of CD4+ TH1


Figure 1:

IF-THEN??


Figure 1:

IF TLR signalling is required for TH1 response to HSV-2,

THEN disrupting TLR signalling will block TH1 response


Figure 1:

Technique for measuring TH1 response?


  • Figure 1:

  • Technique for measuring TH1 response:

    • Infect mice with HSV-2

    • Isolate CD4+ cells from lymph nodes

      • anti-CD4 on magnetic beads

    • Stimulate in vitro with APCs or DCs ± HSV-2 Ag

    • Assay cytokine production

      • how?


  • Figure 1:

  • Disruption of TLR signalling:

    • MyD88 is an adapter protein in the TLR signal transduction pathway

    • Knockout mice (MyD88 –/–) lack this protein

(why is this better

than knocking out

a TLR?)


  • Figure 1:

  • Activated cells in WT make IFN-g, not IL-4 or 10

  • Activated cells in KO make IL-4 and 10, not IFN-g

APCs

DCs

Significance?

Controls?


  • Figure 1:

  • Activated cells in WT make IFN-g, not IL-4 or 10

  • Activated cells in KO make IL-4 and 10, not IFN-g

  • TLR signalling is needed for TH1 response

APCs

DCs


Figure 2:

IF-THEN??


Figure 2:

IF TLR signalling is required for DC recruitment to mucosa,

THEN disrupting TLR signalling will block recruitment


Figure 2:

Technique for measuring recruitment to mucosa?


  • Figure 2:

  • Technique for measuring recruitment to mucosa:

    • Immunofluorescence staining (in situ)

    • anti-CD11c Ab: specific DC marker


  • Figure 2:

  • Similar recruitment of DCs to infected epithelium

WT

KO

blue = nuclei

red = DCs

green = virus


Figure 3:

IF-THEN??


Figure 3:

IF TLR signalling is required for DC migration to lymph nodes or maturation,

THEN disrupting TLR signalling will block migration or maturation


Figure 3:

Technique for measuring migration to lymph nodes and maturation?


  • Figure 3:

  • Technique for measuring migration to lymph nodes and maturation:

    • Fluorescence-activated cell sorting (FACS)


  • Figure 3:

  • Technique for measuring migration to lymph nodes and maturation:

    • Fluorescence-activated cell sorting (FACS)


  • Figure 3:

  • Technique for measuring migration to lymph nodes and maturation:

    • Fluorescence-activated cell sorting (FACS)

    • DCs are: CDC11c+ / B220– / CD8–

    • Mature DCs are also CD86+

    • Isolate CD11c+ cells

    • Sort with fluorescent anti-CD8 and anti-CD86


  • Figure 3:

  • TLR signalling does not change numbers of CD4 or DC cells in lymph nodes


  • Figure 3:

  • TLR signalling does not change numbers of CD4 or DC cells in lymph nodes

  • TLR signalling does not change number or maturity of DCs

Mock

HSV

WT

KO

mature

DCs


  • Figure 3:

  • TLR signalling does not change numbers of CD4 or DC cells in lymph nodes

  • TLR signalling does not change number or maturity of DCs

  • TLR signalling is not needed for migration or maturity

Mock

HSV

WT

KO

mature

DCs


  • Figure 4:

  • Possible explanations for Fig. 1 results:

    • TH1 activation requires TLR signalling

    • TH1 activation requires IL-1 or IL-18 (also dependent on MyD88)

    • TH1 activation requires IL-12

    • TH1 activation requires IFN-g


Figure 4:

IF-THEN??


Figure 4:

IF MyD88 KO mice lack TH1 response due to lack of IL-1 (or IL-18), IL-12 or IFN-g,

THEN lack of one of these products would have the same effect as the MyD88 KO


Figure 4:

Technique for measuring effects of cytokines on TH1 activation?


  • Figure 4:

  • Technique for measuring effects of cytokines on TH1 activation:

  • Additional KO mice:

    • caspase-1 (IL-1 b-converting enzyme) KO mice: lack functional IL-1

    • IL-12 p40 KO mice: lack functional IL-12

    • IFN-gR KO mice: DCs can’t respond to IFN-g

  • Same cytokine assay as Fig. 1


  • Figure 4:

  • Lack of IL-1 does not affect TH1 activation

  • Lack of IL-12 does not affect TH1 activation

  • Lack of DC response to IFN-g does not affect TH1 activation

APCs

DCs


  • Figure 4:

  • Lack of IL-1 does not affect TH1 activation

  • Lack of IL-12 does not affect TH1 activation

  • Lack of DC response to IFN-g does not affect TH1 activation

  • Activation appears to specifically require TLR signal

APCs

DCs


Figure 5A:

IF-THEN??


Figure 5A:

IF epithelial cells are involved in TLR signalling,

THEN these cells must express TLR genes


Figure 5A:

Technique for measuring expression of TLR genes?


  • Figure 5A:

  • Technique for measuring expression of TLR genes:

  • RT-PCR

    • Primer pair specific for each TLR gene

    • Isolate mRNA

    • Reverse transcriptase  DNA

    • PCR to amplify: band indicates mRNA was present


  • Figure 5A:

  • Epithelial cells express all tested TLR genes


Figure 5B-E:

IF-THEN??


Figure 5B-E:

IF TLR signalling by epithelial cells is needed for TH1 activation

THEN MyD88 KO in epithelial cells will block TH1 activation even if WT DCs are present


Figure 5B-E:

Technique for making mice with genetically different epithelial and DC cells???


  • Figure 5B-E:

  • Technique for making mice with genetically different epithelial and DC cells:

  • Bone marrow (BM) chimera:

    • lethal irradiation of mouse to kill bone marrow cells

    • “bone marrow transplant” from a different strain

    • epithelial cells have original genotype; DCs have donor genotype

MyD88 (-/-)

DCs

MyD88+

epithelium

WT

MyD88

KO BM cells

KO BM  WT


  • Figure 5B-E:

  • Technique for making mice with genetically different epithelial and DC cells:

  • Bone marrow (BM) chimera

  • Same cytokine assay for CD4 cell activation


APCs

DCs

  • Figure 5B-E:

  • MyD88 required in DCs for activation

MyD88 (-/-)

DCs

MyD88+

epithelium


APCs

DCs

  • Figure 5B-E:

  • MyD88 required in epithelial cells for activation

MyD88 (-/-)

epithelium

MyD88+

DCs


APCs

DCs

  • Figure 5B-E:

  • MyD88 required in DCs for activation

  • MyD88 required in epithelial cells for activation

  • Both DCs and stromal cells participate in Ag presentation and require TLR signalling


Figure 6:

IF-THEN??


Figure 6:

IF signalling by a specific TLR is required for TH1 activation,

THEN KO of that TLR in stromal cells and/or DCs will block TH1 activation


Figure 6:

Technique for testing TLR KO in DC and stromal cells?


  • Figure 6:

  • Technique for testing TLR KO in DC and stromal cells?

  • Chimera with WT DCs and TLR KO stromal cells or vice-versa

  • Same cytokine assay


  • Figure 6:

  • TLR9 not required for activation

  • Not shown: TLR2, TLR3, TLR4 also not required


  • Conclusions:

  • Stromal cells and DCs are involved in presentation of intracellular virus Ag to TH cells

  • Requires TLR signalling by both stromal cells and DCs
