Presentation Transcript

Reliance Industries Limited

Hazira Manufacturing Division


Reliance Industries Limited , Hazira

Overall Plot Plan


220 KV Switch yard


Raw water ponds





PE 1





Non plant bldg.




Ethylene terminal/Jetty


Ethylene terminal/Jetty


Tank Farm




MPP-3 Fibre fill






hazira progression
Hazira progression

Plants Licensor Startup Capacity ( KTA )

Technology Installed

CPP & U May 1991 60 MW

MEG 1 Shell Sep. 1991 100

PVC Geon Dec. 1991 160

VCM Geon Apr. 1992 160

PE 1 Du Pont Jul. 1992 160

POY Du Pont Dec. 1995 120

PP UCC Sep. 1996 360

PSF Du Pont Sep. 1996 160

PTA 1 ICI Jan. 1997 350

hazira progression5
Hazira progression

Plants Licensor Startup Capacity ( KTA )

Technology Installed

CPP 2 1996-1998 190 MW

Cracker S & W Mar. 1997 750

Aromatics HRI/Mobil Mar. 1997 350

MEG 2 Shell Mar. 1997 120

PE 2 Nova May 1997 200

PET Sinco Oct. 1997 80

PFF Du Pont Oct. 1997 30

MEG 3 Shell Oct. 1997 120

PTA 2 ICI Nov. 1997 350


Hazira - CPP and Utility

CPP-Utility is providing utility services to all plants in complex. These utilities are generated and supplied from :

A. Captive Power Plant :-

1. Steam generation and distribution

2. Power receipt, generation, sale and distribution

B. Utilities

1. Raw water treatment and distribution

2. Cooling water treatment and circulation.

3. DM water production and distribution.

4. Compressed air and instrument air generation and distribution.


Hazira - CPP and Utility

  • Major Equipment Supplier in CPP/Utility :
      • Gas Turbines by M/s. Thomassen International BV of Holland and BHEL of India.
      • Heat Recovery Steam Generators (HRSGs) and one Aux. Boiler by M/s. Stork BV of Holland.
      • DM Water Plant by M/s. Thermax Ltd.
      • Cooling Tower by M/s. Paharpur Cooling Towers.
      • Air Compressors are supplied by M/s. Elliot U. K.
      • Air drying units by M/s. Lloyds Steel Industries Ltd.
      • Raw water treatment and Effluent treatment plants by M/s. Hindustan Oliver Ltd.
  • Cogeneration Plant At Hazira :-
  • The Cogeneration Plant was commissioned in September, 1991. Cogeneration is the combined production of Heat and Electric Power. Each cogeneration plant has Gas Turbines and 125 TPH Heat Recovery Steam Generator. The fuel for the Congeneration plant is natural gas and HSD.
support services logistics
Support Services : Logistics

Receipt of material from plant// Bagging in 25 Kg. Bag and Jumbo Bag on automatic bagging machine// Storage in the Warehouse // Documentation // Dispatch as per marketing advise & Payment of Excise Duty


Solid movement about 550 truck per day - POY, PSF, PP, PE, PVC, etc. // Liquid movement -- about 475 truck per day - MEG, Bz, Xy, EDC, etc // Provision for moving out polymers and polyesters in bulk / containers // Provision for hopper car loading // Adequate tankages and warehousing capacities / loading-unloading facilities // Drumming facility for DEG and TEG

support services hse
Support Services : HSE

“Safety of Person Overrides All Production Targets”

  • HSE Management based on Responsible Care
  • Focus on safety during Engineering, Construction, Startup & Operation
  • Ongoing training and validation for all the employees including contractors
  • 100% compliance with all pollution control norms
  • Periodic health checkup for all employees
  • Regular audits, both internal & external
  • Community awareness & emergency response / disaster management plan
support services cts
Support Services : CTS

Functions & Activities

  • Benchmarking
  • Product development
  • Quality assurance
  • Pinch Technology
  • Process Safety management
  • Cost reduction
  • Process evaluation
  • Process Engineering
  • Test runs & debottlenecking
  • Energy Conservation
support services ces
Support Services : CES

Functions & Activities


1.1 Planning

1.2 Inspection & Corrosion

1.3 Condition Monitoring

1.4 Contract Lineup

1.5 Drawing & FCOs

1.6 Documentation / Technical Library

1.7 Machining & Overhauling


2.1 Motor Over Hauling

2.2 Relay Testing & Calibration

2.3 Transformer Oil Filtration & Oil Checking


Support Services : CES

Functions & Activities


3.1 Testing & Calibration of Instruments / Control Valves

3.2 Maintenance of Analyzer

3.3 Maintenance of DCS

3.4 Maintenance of PLCs

3.5 Import Substitution


4.1 Telecommunication

4.2 Plant Address System

4.3 Fire Protection System

4.4 Maintenance of UPS

4.5 Power Electronics


5.1 Maintenance of Buildings & Roads

5.2 Mini Projects Execution

5.3 Town Ship Maintenance

support services about maintenance
Support Services : About Maintenance

“World Class Maintenance”

  • TPM
  • Benchmarked against World Standards by A T Kearney
  • Special attention to
    • Technician productivity
    • ERV tracking and control
    • Reliability and uptime
  • Contracting strategies
  • Least cost maintenance
  • Material management improvements
    • Stocking policy/JIT
    • Procurement cycle time reduction
    • Vendor development/rating

Support Services : MIS

Set Up & Activities

  • The MIS/IT department at hazira is centralised function for whole site looking after the followings
      • Installation and maintenance of infrastructure required for IT
      • Development, implementation and support of application system for areas of manufacturing and commercial (Now apart from SAP)
      • Providing central help desk support to overcome user' problems in relation to computerised system
  • All the computer system and plant process control systems are connected to a system of network comprising of following………

Fibre optic cable UTP Cable

Switches Hubs

PCs Printers

Modems Servers


Support Services : MIS

Set Up & Activities

  • Hazira site is network is connected to Reliance group through settalite Insat 1C for the office of Makers-Mumbai, Patalganga and Jamnagar. This connection is also used for video conferencing between the offies working at these locations. The IT department is dividied in two sections
  • 1, Infrastructure support activities
      • Network extension and modification project
      • Desktop support
      • System operation support
      • Network management
      • E-Mail administration
  • 2, Application Development and technical support activities
      • Recording of system requirements
      • Approval by HOD
      • System analysis and design
      • Programming, testing, implementation and documentation
      • Testing
      • Implementation and User' training
      • Documentation

Support Services : Fire Fighting & Control System

All the plants are designed and erected / constructed with due regards to the appropriate fire protection measures, [under relevant / adapted standards & codes of practices] broadly in terms of (i) safety distances between equipment as well as between the plants, (ii) fire / safety risk analysis including hazard operability study (hazop) and hazard analysis (hazan) (iii) isolation of process equipment including of emergency shut-down systems & (iv) passive fire protection viz. fire doors, fire barriers, fire resistant coatings & sealant etc.


Support Services : Fire Fighting & Control System

  • Two full-fledged fire stations manned by qualified and experienced fire service personnel including officers (i.e. total complement of 65 personnel).
  • Availability of six major / mobile fire fighting appliances viz. Foam Tenders (04), DCP Tender (01) & Emergency cum Rescue Tender (01).
  • Fixed fire fighting installations viz. Deluge valves, water spray system, pressurized fire water / hydrant system, riser system, water / foam monitors, foam system, modular DCP, CO2 system, Halon system, heat shield water spray units etc.
  • Fire alarm panels [installed in plant control rooms as well as in control rooms of fire stations] interfaced with automatic detectors viz. smoke detectors, heat detectors, UV / IR detectors, & LEL detectors.
  • Portable fire extinguishers, trailer / trolley mounted extinguishers as well as monitors (water / foam).

Support Services : Fire Fighting & Control System

  • Reservoirs / storages of fire water for carrying out fire fighting operations [at a stretch] for 9 hrs.
  • Dedicated fire pumps are installed at two separate locations to feed / convey this water through the net-work of pressurized fire water mains / headers protecting the plants / complex.
  • Adequate inventories of other special extinguishing media viz. foam concentrates / DCPs.
  • Availability of adequate Breathing Apparatus sets, emergency escape sets, special PPEs & emergency tool kits.
  • Mutual Aid agreements with the neighboring industries viz. KRIBHCO, ONGC & NTPC.
  • Well defined On-site & Off-site emergency plans. [which also include predetermined emergency escape routes & occupancy wise evacuation plans]

Support Services : Fire Fighting & Control System

  • The following activities are normally carried out :-
      • Hot work permit / site monitoring by fire service personnel.
      • Deployment of fire tender(s) and crews [at various plants / areas] for standby duties.
      • Fire prevention audits as per checklist.
      • Detailed investigation into cause of fire / explosion.
      • Daily surveillance round by shift fire officer / personnel.
      • Maintenance of round the clock watch and ward by security department [which includes, inter-alia, fire watch from arson / sabotage angles].

Support Services : Fire Fighting & Control System


Tactical Functions Of Fire Service Personnel :-

(a) Handling of Fire Emergencies

(b) Handling of Non - Fire Emergencies [i.e. Spillage, Leakages Etc.] :-

(c) Special Services

Maintenance of Fire Protection Systems :-

Communication Systems :-

Preparedness :-

Training :-
