  1. The Impacts of Positive Definite Moisture Advection and Microphysical Advances in Orography Robert Hahn & Cliff Mass University of Washington

  2. Advection Schemes • Until recently, several notable mesoscale models did not conserve moisture because of overlooked numerical challenges in advection schemes. • Advection schemes can introduce both positive and negative errors, particularly when there are sharp gradients. • This becomes significant when dealing with microphysical quantities because some moisture values can have sharp edges where the quantity goes to zero. • When negative mass values are generated, models often reset or ‘clip’ these values to zero and moisture is added to the model, artificially. • Positive Definite Advection (PDA) schemes eliminate non-physical generation of negative values, while conserving mass (see figure). *graphics from a presentation by Morris Weisman

  3. Why Orography? • Theory indicates that PDA should have it’s greatest effect where large gradients in moisture species are present. • Both convection and orography induce such large gradients in many microphysical fields. • Orography also provides temporal stability of the flow pattern and associated microphysical fields, making it ideal for examining the generation of spurious sources of mass in a real-time simulation.

  4. Dec 13-14th Case • Passage of a strong barocliniczone. • Cross-barrier flow with winds in excess of 40 m s-1 at crest level. • Heavy precipitation with deep reflectivity and orographic enhancement. • Wealth of observational assets providing and in-depth view of dynamic and microphysical characteristics of the storm. • Vigorous synoptic and orographic forcing combine to make this case ideal for the study of PDA.

  5. Model Setup • WRF ARW Version 2.2 • Thompson Microphysics • MRF PBL scheme • CAM radiation • Runge-Kutta (RK3) time integration scheme with splitting for stabilization of higher-frequency acoustic modes (Skamarock et al., 2008). • 5thorderhoriz.advective transport • 3rdorder vert. advective transport

  6. 36-hour Storm-Total Precipitation NOPDA PDA-NOPDA a b PDA % Difference b d

  7. Statistics: Percentage Difference • Areas with orography tend to be affected more at coarser grid resolution. • Grid spacing increases % Difference. • Even at the lowest resolutions, the effects are significant.

  8. Vertical Distribution of Mixing Ratios

  9. HEIGHT (m) HEIGHT (m) DIFF HORIZ-AVERAGED MIXING RATIO (g kg-1) PCT DIFF HORIZ-AVERAGED MIXING RATIO (g kg-1)

  10. The Effect of PDA on the cloud field • Small contributions accumulate in time. • The cloud field in the COAMPS model broaden without the PDA Limiter. COAMPS-LES results provided courtesy of Dr. Chris Golaz and Jerome Schmidt

  11. Qcloud Advection Mag. Of Gradient Edge Gradient

  12. Hydrometeor Edge Mixing Ratios • Definition: Positive mixing ratios that touch zero values of like mixing ratios within the plane of the E-W cross-section shown in previous slide. • The range of each histogram distribution corresponds to the magnitude of spurious production of moisture in non-PDA schemes.

  13. Microphysics • Thompson Scheme (Thompson et al., 2008) • Assumed snow size distribution depends upon ice water content and temperature. • Non-spherical snow crystal shape and correspondingly varying bulk density. • Variable collection efficiency for rain, snow, and graupel collecting cloud droplets. • Morrison Scheme (Morrison & Grabowski, 2007a,b) • Builds from the existing double-moment warm rain scheme • 3rd prognostic var: Number concentration of ice.

  14. Precipitation Bias Scores: Thompson

  15. Precipitation Bias Scores: Morrison

  16. Bias Scores • Undercatchment is expected at most observation sites. • Garvert et al. (2005) had noted particularly high bias scores over the windward valleys and in the immediate lee of the crest (simulations performed using MM5, Reisner-2 micro). • Morrison bias scores are quite large in the immediate lee of the Cascade Crest for the Morrison, but reasonable in the Thompson. • Both schemes studied overpredict on the windward slopes. Is there a dependence upon model elevation? MODEL ELEV (m) THOMPSON BIAS SCORE MORRISON BIAS SCORE

  17. Thompson =

  18. Morrison =

  19. Mixing Ratios • Morrison tends to have fewer precipitation hydrometeors than Thompson overall, but slightly more at the lowest altitude. • Thompson has more cloud. • The next few panels further illustrate these points.

  20. SNOW Morrison Background Contours = Morrison - Thompson

  21. RAIN Morrison Background Contours = Morrison - Thompson Signature of excess snow aloft in Thompson

  22. CLOUD Morrison Background Contours = Morrison - Thompson

  23. SUMMARY • PDA scheme eliminates a large spurious source of moisture noted at all grid scales. • PDA was applied uniquely to individual hydrometeor variables. • Large horizontal gradients in moisture fields induced by orographically generated mountain waves helped generate sharp gradients and strong advections at cloud edges, resulting in strong negative tendencies on upwind side of clouds. • New Microphysics in WRF Version 3 appears promising. • Verifications illustrate similar biases to those found by Garvert et al (2005), but are somewhat improved in the latest Thompson Scheme and did not appear to be model elevation dependent for either Thompson or Morrison.
