    1. Secure PumpPAY Webinar September 18 & 26, 2008 Jeff Wakefield VP Marketing

    2. Agenda Security Mandates Facing Fuel Retailers Payment Security Mandate Roadmap Secure PumpPAY Overview Models Supported Benefits Installation Content Delivery Questions

    3. What do I need to do and when?

    4. Visa Fuel Pump Security Mandates

    5. VISA Global POS PED TDES Mandates

    6. VISA PED Deployment Mandates

    7. VISA PABP Mandates

    8. VeriFone Solutions

    9. Fuel Pump Fraud & Security

    10. Fuel dispenser skimming is becoming epidemic

    11. Fuel retail breaches are escalating Arizona California Delaware Florida Georgia Indiana Illinois Massachusetts Michigan Nevada New Jersey North Carolina Pennsylvania Texas Washington Wisconsin

    12. Visa reports AFDs as primary targets Findings Fraud activity concentrated in southern California and Florida Specific AFD manufacturers and models targeted Organized groups target locations: goal is track and PIN data Targets High volume stations AFD located away from cashier Access via front panel with shared ‘brass key’ Suspects impersonate pump service technicians Reader device attached to card reader and PIN pad

    13. TDES mandate does NOT mean security at the pump The TDES mandate does not increase security at the fuel dispenser TDES makes decrypting encrypted PIN numbers harder To our knowledge, no one has broken the DES encryption schemes and compromised PIN numbers The current fuel pump payment security risks remain: Limited number of brass keys to provide access to the DCR Available ribbon cables to tap into to steal MSR data No shroud to protect against overhead camera’s stealing PIN’s during entry Criminals know how to tamper with existing DCR’s in the fuel dispenser Criminals know the format of data from these pumps Track data is not encrypted between the MSR and the EPP or current debit module (GSM, etc.)

    14. Secure PumpPAY increases fuel dispenser security Extended bezel around unit eliminates or reduces ability of cameras being used for capturing PIN entries Tactile keypad prevents keyboard overlay skimmers from being installed OP4100 housing conceals all cables making installation of skimmers more difficult PCI EPP 1.3 certified

    15. Secure PumpPAY Product Overview August 1, 2008

    16. Secure PumpPAY feature overview

    17. Secure PumpPAY Security Benefits Meets the latest Payment Card Industry (PCI) requirements to provide the most secure on-line PIN entry as well as Triple DES method of encryption at the fuel dispenser Secure PumpPAY housing conceals all cables making installation of skimmers more difficult New keys for doors will make Secure PumpPAY units more difficult to access as keys are not widely available

    18. Secure PumpPAY Enhanced Security Benefits Extended bezel around unit reduces or eliminates ability of cameras being used for capturing PIN entries Polymer tactile keypad prevents keyboard overlay skimmers from being installed Remote key load feature allows debit keys to be loaded in the field and helps ease the process when changing networks

    19. Integrated, all-in-one design simplifies installation into existing pumps — Retrofit Kits available for all major dispenser manufacturers and models, and can be done in as little as 30 minutes. Large color display provides bright attention-getting messages that help drive customers into the store for high margin sales. Integrated high resolution printer included and can prominently highlight graphics such as company logos and bar-coded receipts for in-store promotions. Additional Secure PumpPAY Benefits

    20. Built in Contactless Reader is included which future proofs your investment Simplify management and customer interface by having the same system at all pumps. Additional Secure PumpPAY Benefits

    21. Compact design streamlines installation PCI approved design streamlines retro-fits or new installs Most dispensers can be completed in about an hour Retrofit Kits include the following OP4100 PCI compliant card reading terminal High speed thermal printer that supports high resolution images and graphics Dispenser door replacement panel that meets original manufacturer design and materials Cables, connectors and power supplies Mounting brackets and door locks Easily integrates into Ruby and Topaz POS systems Integrated, all-in-one design simplifies installation

    22. Gilbarco Advantage Retrofit Kit

    23. Tokheim Premier B Wide Retrofit Kit

    24. Tokheim Premier C Wide Frame Retrofit Kit

    25. Wayne Vista Retrofit Kit

    26. Successful US field trials began in October 2007 16 field trail sites were installed from October 2007 to July 2008 All Released Pump Types Tested in a variety of environments

    27. Installation Pre-Installation Application installed Content Loaded Debit Keys downloaded from the VeriFone Portal Installation Payment Terminal and Printer into the Door frame assembly Day of Installation Half of Dispensers Shut Down Old equipment removed Install the pre-assembled devices Install the new Door Frame assembly Test communication with the POS Activate the new Payment terminals Repeat the above process for the remaining dispensers

    28. Loading Graphical Images using the SPP Installer Program

    29. SPP supports Two Image Prompts Sequences

    30. Save your images in an easy-to-find image library or folder

    31. Loading Images is simply “drag and drop”

    32. Setting the length of time each image appears

    33. Preview Image Playlist to verify timing and image sequence

    34. Downloading the Playlist completes the Process

    35. Graphics displayed throughout SPP application

    36. Graphics displayed throughout SPP application

    37. Brand specific idle images - examples

    38. Examples of promotional images

    39. What are my options for pump security?

    40. VeriFone Payment Security Solutions

    41. VeriFone can help you meet your PCI goals today!
