Presentation Transcript
what is i o multiplexing
What is I/O multiplexing?
  • When an application needs to handle multiple I/O descriptors at the same time
    • E.g. file and socket descriptors, multiple socket descriptors
  • When I/O on any one descriptor can result in blocking
non forking concurrent server
Non-forking concurrent server

Concurrent Server

select()

listenfd

Sockets 

fd1

fd2

fd3

fd4

fd5

C1

C2

C3

C4

C5

Clients 

i o models
I/O Models
  • Blocking I/O
  • Non-blocking I/O
  • I/O multiplexing – select()
  • Signal driven I/O
  • Asynchronous I/O
blocking i o
Blocking I/O

Application

Operating system

System call

No datagram ready

recvfrom()

Wait for data

datagram ready

Process blocks

Copy datagram

Copy data to user

Return ok

Process datagram

Copy complete

non blocking i o
Non-Blocking I/O

Application

Operating system

System call

No datagram ready

recvfrom()

EWOULDBLOCK

System call

No datagram ready

recvfrom()

EWOULDBLOCK

System call

datagram ready

recvfrom()

Copy datagram

Copy data to user

Process blocks

Return ok

Process datagram

Copy complete

i o multiplexing7
I/O Multiplexing

Application

Operating system

System call

No datagram ready

select()

Wait for data

Process blocks

Return readable

datagram ready

System call

recvfrom()

Copy datagram

Copy data to user

Process blocks

Return ok

Process datagram

Copy complete

signal driven i o
Signal driven I/O

Application

Operating system

Establish SIGIO

Signal handler

System call

No datagram ready

Wait for data

Process continues

Deliver SIGIO

datagram ready

Signal Handler

System call

recvfrom()

Copy datagram

Copy data to user

Process blocks

Return ok

Copy complete

Process datagram

asynchronous i o
Asynchronous I/O

Application

Operating system

System call

No datagram ready

aio_read()

return

Wait for data

datagram ready

Process continues

Copy datagram

Copy data to user

Return ok

Copy complete

Signal handler

Process datagram

select call
select() call
  • Allows a process to wait for an event to occur on any one of its descriptors.
  • Types of event
    • ready for read
    • ready for write
    • Exception condition
select call11
select() call

int select(

int maxfdp1, /* max. fd + 1 */

fd_set *readfds, /* read ready? */

fd_set *writefds, /* write ready? */

fd_set *exceptfds, /* exceptions? */

struct timeval *timeout);

struct timeval {

long tv_sec; /* seconds */

long tv_usec; /* microseconds */

}

struct fd set
struct fd_set
  • Set of descriptors that we want to wait on for events.
  • Typically holds 256 descriptor states.
  • Manipulation macros
    • void FD_ZERO(fd_set *fds)
    • void FD_SET (int fd, fd_set *fds)
    • void FD_CLR (int fd, fd_set *fds)
    • void FD_ISSET(int fd, fd_set *fds)
non forking concurrent server13
Non-forking Concurrent Server

fdset rdset, wrset;

int listenfd, connfd1, connfd2;

int maxfdp1;

………

Connection establishment etc.

………

/* initialize */

FD_ZERO(&rdset);

FD_ZERO(&wrset);

slide14
for( ;; ) {

FD_SET(connfd1, &rdset);

FD_SET(connfd2, &wrset);

FD_SET(listenfd, &rdset);

maxfdp1 = max(connfd1, connfd2, listenfd) + 1;

/* wait for some event */

Select(maxfdp1, &rdset, &wrset, NULL, NULL);

if( FD_ISSET(connfd1, &rdset) ) {

Read data from connfd1…

}

if( FD_ISSET(connfd2, &wrset) ) {

Write data to connfd2…

}

if( FD_ISSET(listenfd, &rdset) {

Process a new connection…

}

}

high resolution timer
High resolution timer!
  • Select can be used as a millisecond resolution timer.

select ( 0, NULL, NULL, NULL, &timeval)

  • Usual sleep(…) call has resolution of seconds.
managing socket options 3 ways
Managing socket options – 3 ways
  • getsockopt() and setsockopt()
  • fcntl()
  • ioctl()
getsockopt and setsockopt
getsockopt() and setsockopt()

int getsockopt(

int sockfd,

int level, /* SOL_SOCKET, IPPROTO_IP, IPPROTO_TCP etc */

int optname, /* option name */

void *opt­val, /* option value */

socklen_t *optlen); /* data length of option*/

int setsockopt(

int sockfd,

int level,

int optname,

const void *optval,

socklen_t optlen);

some socket options
Some socket options
  • SO_BROADCAST - enable socket for sending broadcast
  • SO_KEEPALIVE – regularly probes on inactive TCP connection.
  • SO_LINGER – linger till all data is sent before returning from close() on a TCP connection.
  • SO_RCVBUF/ SO_SNDBUF – size of receive/send buffers on socket.
  • SO_RCVTIMEO/SO_SNDTIMEO – place timeout on receive/send operation.
fcntl
fcntl()
  • int fcntl(int fd, int cmd, long arg);
  • Miscellaneous file control operations
    • Non-blocking I/O (O_NONBLOCK, F_SETFL)
    • Signal-driven I/O (O_ASYNC, F_SETFL)
    • Set socket owner (F_SETOWN)
