  1. Ultrasonic transducer-Used for the non-destructive testing

  2. The ultrasonic transducer is the device used for the non-destructive testing that uses the high-frequency sound waves to measure the parameter. • People use this in industrial applications to detect the flaws, weld inspection and thickness gaging. It does come in various shapes or sizes that can be challenging when you will identify it. • It even helpstodetermine the transducer that is the most appropriate way for the application. You can choose anultrasonic transducerwhichdoescome in several different types. • For More Information Please visit, https://piezodirect.com/ultrasonic-piezo-transducers

  3. Dual Element transducer • The dual transducer will consist of the two main crystal elements separated by the acoustic barrier. It helps generate the sound waves, and the other element there will work as the receiver. • It transmits and receives the beams which cross under the surface of examinationand even helps in enhancing the resolution in the focal zone. Here will be an increase in the sensitivity that helps examine the parts with a rough back wall surface.

  4. Contact transducers • Another type of transducer which you can find is contact transducers which help is applicable to detect the straight beam flaw detection and also for the thickness gagging. • It has a single element which has the wear resistance surface in most of the metal, which makes it durable for the person to use. Through this, you can detect and size the delimitations. It will even help you in measuring the velocity.
