1. Base Ventilated Super-Cavitating Hydrofoils for Fast Ferry Motion Control Bryce Pearce Research Student
Dr Paul Brandner - Supervisor
2. Ventilated & Supercavitating Foils Non-attached types of cavities are known as super-cavities, I.e. those where the cavity closure happen off the foil itself. The lower figure shows a typical design of super cavitating hydrofoil. The upper figure is an example of a base ventilated foil where again the cavity closes off the foil surface. Both these foil shapes are unsymemetrical, and produce lift in one direction only.Non-attached types of cavities are known as super-cavities, I.e. those where the cavity closure happen off the foil itself. The lower figure shows a typical design of super cavitating hydrofoil. The upper figure is an example of a base ventilated foil where again the cavity closes off the foil surface. Both these foil shapes are unsymemetrical, and produce lift in one direction only.
3. [Elms Australia] Patent Improved Hydrofoil device
4. Intercepted Hydrofoil with Base Ventilated Cavity
Symmetric foil section with an interceptor or fence attached to the trailing edge to produce lift.
A cross section of the wedge foil showing an approximate cavity shape (NTS).A cross section of the wedge foil showing an approximate cavity shape (NTS).
5. Some Definitions
6. Flow region near Interceptor
7. 2-D Panel Method Numerical prediction of Cavity Shape & Hydrodynamic characteristics.
Non-linear method A numerical code has been developed based on a 2D potential flow method published by Lee, Kim & Lee, which enables the cavity shape and hence the hydrodynamic lift acting on the foil to be predicted. This will be utilized in optimising the shape of the foil section.Each of the curves sows the iterations that the code goes through converging to give the cavity shape.A numerical code has been developed based on a 2D potential flow method published by Lee, Kim & Lee, which enables the cavity shape and hence the hydrodynamic lift acting on the foil to be predicted. This will be utilized in optimising the shape of the foil section.Each of the curves sows the iterations that the code goes through converging to give the cavity shape.
8. Ramp Shape
9. Ramp Shape
10. Constant T.E. angle / variation in Chord
11. Some More Definitions
12. Constant T.E. angle / variation in Chord
13. Constant Chord / variation in T.E. angle
14. Super-Cavitating Hydrofoils (with ramp) Some preliminary numerical results
15. Foil & Cavity Nomenclature
16. Foil Section Parameters TCR foil thickness to chord ratio
HCR ramp height to foil chord ratio
HLR ramp height to length ratio
g te foil foil trailing edge angle
g te ramp ramp trailing edge angle
17. Base Foil - 1xx Series Single term nth - order Polynomial
19. Intercepted Foil Numerical Model
20. Results: Cavity Shape
21. Results: Cavity Shape
22. Results: Cavity Shape
23. Results: Cavity Shape A non-linear relation
Only weakly effected by incidence
24. Results: Cavity Shape
25. Another Definition
26. Results: Pressure Distribution
27. Results: Pressure Distribution
28. Results: Pressure Distribution
29. Results: Hydrodynamic Forces
30. Results: Hydrodynamic Forces
31. Conclusions & Further Work
32. Questions? With ventilated cavityWith ventilated cavity
