### An Experience of ModelingMargaret L. KiddCal State Fullerton

mkidd@fullerton.edu

Session 365 CMC-South

Palm Springs, CA

November 1, 2013

### Definition of Mathematical Modeling

There are many definitions.

There is also a difference in modeling with mathematics as found in the SMP

and the Mathematical Modeling Process as found in the high school curriculum.

Standards for Mathematical Practice

The Importance of Mathematical Practices

Bill McCallum Video

It is not modeling in the sense of, “I do; now you do.”

It is not modeling in the sense of using manipulatives to represent mathematical concepts (these might be called “using concrete representations” instead.)

It is not modeling in the sense of a “model” being just a graph, equation, or function. Modeling is a process.

What is Modeling Not???

It is not just starting with a real-world situation and solving a math problem; it is returning to the real-world situation and using the mathematics to inform our understanding of the world. (I.e. contextualizing and decontextualizing, see MP.2.)

• It is not beginning with the mathematics and then moving to the real world; it is starting with the real world (concrete) and representing it with mathematics.
Mathematical Modeling

Step 1. Identify a situation.

Read and ask questions about the problem. Identify issues you wish to understand so that your questions are focused on exactly what you want to know.

Mathematical Modeling

Step 2. Simplify the situation.

Make assumptions and note the features that you will ignore at first. List the key features of the problem. These are your assumptions that you will use to build the model.

Mathematical Modeling

Step 3. Build the model and solve the problem.

Describe in mathematical terms the relationships among the parts of the problem, and find an answer to the problem. Some ways to describe the features mathematically include:

• define variables, write equations make graphs, gather data, and organize into tables
Mathematical Modeling

Step 4. Evaluate and revise the model.

Check whether the answer makes sense, and test your model. Return to the original context. If the results of the mathematical work make sense, use them until new information becomes available or assumptions change. If not, reconsider the assumptions made in Step 2 and revise them to be more realistic.

Modeling is best interpreted not as a collection of isolated topics but in relation to other standards. Making mathematical models is a Standard for Mathematical Practice, and specific modeling standards appear throughout the high school standards indicated by a star symbol (*). The star symbol sometimes appears on the heading for a group of standards; in that case, it should be understood to apply to all standards in that group.

Areas Modeling is Indicated

Algebra

Seeing Structure in Expressions    A-SSEWrite expressions in equivalent forms to solve problems3. Choose and produce an equivalent form of an expression to reveal and explain properties of the quantity represented by the expression.*a. Factor a quadratic expression to reveal the zeros of the function it defines.b. Complete the square in a quadratic expression to reveal the maximum or minimum value of the function it defines.

Areas Modeling is Indicated
Teacher and Modeler

Teacher/Problem Writer

Begins with mathematics (content standard).

Focus on mathematics and uses applications to illustrate, motivate, develop or understand mathematics.

Results in deeper understanding of the mathematics.

Modeler and Modeling

Begins with life. (Math provides the tools and pathways.)

Focus on understanding or solving a life problem or improving a product or situation.

Leads to a solution, decision, recommendation, modification, plan.

Look around you at the real world. Get used to “noticing” and asking questions.

Be open to your students. Realize you do not have all of the answers but know where to find them.

Get used to using the internet to find answers……and questions to use!

Modeling in the Mathematics Classroom
• Problems
• - Easiest to incorporate in the classroom.
• Should I use the 20% off coupon or the \$10 off coupon?
• Pizza which is the better deal?
• Lessons
• - How should I pack the little boxes into the big box?
• - SBAC: Taxicab Problem, Long Jump Problem, MARS
• Units
• - Extended commitment of time.
• - What is the most efficient way to package soda cans?
• Curriculum/Course

Coupon Choice

Karen had two coupons when she bought her shoes at the department store. The clerk said the \$10.00 off coupon is usually the best. Was the clerk correct?

Pizza Deals

What size pizza is the best deal?

Medium Cheese = \$ 9.99

Large Cheese = \$11.99

X-Large Cheese = \$13.99

Medium = 12” diameter

Large = 14” diameter

X-Large = 16” diameter

More than Enough Problems!

Before you begin writing a lesson plan or perhaps developing a unit of study, examine several websites that provide problems you can use, as is, or adapt for your students.

Consider, also, the many sources of authentic modeling problems found in every-day life.

Modeling in the Mathematics Classroom
• Problems
• - Easiest to incorporate in the classroom.
• Should I use the 20% off coupon or the \$10 off coupon?
• Pizza which is the better deal?
• Lessons
• - How should I pack the little boxes into the big box?
• - SBAC: Taxicab Problem, Long Jump Problem, MARS
• Units
• - Extended commitment of time.
• - What is the most efficient way to package soda cans?
• Curriculum/Course

Space Used

Space Available

Efficient =

Volume of Cans

Volume of Prism

Efficient =

Area of Circles

Area of Polygon

Efficient =

Standard Six Pack

The efficiency of the standard six-pack or twelve-pack is 78.5%.

Triangular Six Pack

What is the efficiency of the triangular six-pack?

Is a triangular three-pack or

ten-pack more or less

efficient than the

triangular six-pack?

### SODA CANS

BY: FRANKIE AND ERIKA

RECTANGULAR SIX PACK

The efficiency for a rectangular six pack (or eight pack) is 78.5%

COMPARING

The seven pack has an efficiency of 85%.

The twelve pack has an efficiency of 86%.

They are both more efficient than the rectangular six pack.

Lesson or Unit Design
• Choose a modeling context appropriate for your students and develop a lesson or plan a unit.
• Consider the following while creating your plan:
• Do the problem yourself. Go through the four steps of the modeling process.
• Scaffolding: What information will you provide? What open-ended questions will you ask? Brainstorm and list. Consider your goal and the needs of your students.

The more you scaffold, the less they think and the fewer opportunities they have to develop “patient problem solving.”

• Identify the possible mathematics and standards addressed.
• Identify possible challenges for yourself and your students.
• Identify tools and materials your students might need.
• How will you assess their level of understanding?
• What additional support and resources do you need?

Challenges to

Mathematical

Modeling….

Systemic inertia

To put in perspective the limited large-scale implementation of modeling it has proved difficult to establish any profound innovation in the mainstream mathematics curriculum.

Compared with, say, a home or a hospital, the pattern of teaching and learning activities in the mathematics classrooms we observe today is remarkably similar to that we, and even our grandparents, experienced as children.

Modelling in Mathematics Classrooms: reflections on past developments and the future

Hugh Burkhardt, Shell Centre, Nottingham and Michigan State Universities with contributions by Henry Pollak

ZDM 2006 Vol. 38 (2)

Teacher and Student Role Changes

Responder

Manager

Explainer

The modeling

process is enhanced

by…

The modeling process is enhanced by:

1. The facilitative skill of the teacher. The teacher must create a positive and safe environment where student ideas and questions are honored and constructive feedback is given by the teacher and by other students. Students do the thinking, problem solving and analyzing.

The modeling process is enhanced by:

1. The facilitative skill of the teacher. The teacher must create a positive and safe environment where student ideas and questions are honored and constructive feedback is given by the teacher and by other students. Students do the thinking, problem solving and analyzing.

2. The content knowledge of the teacher. The teacher understands the mathematics relevant to the context well enough to guide students through questioning and reflective listening.

The modeling process is enhanced by:

1. The facilitative skill of the teacher. The teacher must create a positive and safe environment where student ideas and questions are honored and constructive feedback is given by the teacher and by other students. Students do the thinking, problem solving and analyzing.

2. The content knowledge of the teacher. The teacher understands the mathematics relevant to the context well enough to guide students through questioning and reflective listening.

3. Teacher and student access to a variety of representations, and mathematical tools such as manipulatives and technological tools (sketchpad, spreadsheets, internet, graphing calculators, etc.).

The modeling process is enhanced by:

1. The facilitative skill of the teacher. The teacher must create a positive and safe environment where student ideas and questions are honored and constructive feedback is given by the teacher and by other students. Students do the thinking, problem solving and analyzing.

2. The content knowledge of the teacher. The teacher understands the mathematics relevant to the context well enough to guide students through questioning and reflective listening.

3. Teacher and student access to a variety of representations, and mathematical tools such as manipulatives and technological tools (sketchpad, spreadsheets, internet, graphing calculators, etc.).

4. Teacher and student understanding of the modeling process. Teachers and students who have had prior experience have better understanding of the modeling process and the use of models.

The modeling process is enhanced by:

1. The facilitative skill of the teacher. The teacher must create a positive and safe environment where student ideas and questions are honored and constructive feedback is given by the teacher and by other students. Students do the thinking, problem solving and analyzing.

2. The content knowledge of the teacher. The teacher understands the mathematics relevant to the context well enough to guide students through questioning and reflective listening.

3. Teacher and student access to a variety of representations, and mathematical tools such as manipulatives and technological tools (sketchpad, spreadsheets, internet, graphing calculators, etc.).

4. Teacher and student understanding of the modeling process. Teachers and students who have had prior experience have better understanding of the modeling process and the use of models.

5. Teacher and student understanding of the context. Background information/experience may be needed and gained through Internet searches, print media, video, pictures, samples, field trips, guest speakers, etc.

The modeling process is enhanced by:

1. The facilitative skill of the teacher. The teacher must create a positive and safe environment where student ideas and questions are honored and constructive feedback is given by the teacher and by other students. Students do the thinking, problem solving and analyzing.

2. The content knowledge of the teacher. The teacher understands the mathematics relevant to the context well enough to guide students through questioning and reflective listening.

3. Teacher and student access to a variety of representations, and mathematical tools such as manipulatives and technological tools (sketchpad, spreadsheets, internet, graphing calculators, etc.).

4. Teacher and student understanding of the modeling process. Teachers and students who have had prior experience have better understanding of the modeling process and the use of models.

5. Teacher and student understanding of the context. Background information/experience may be needed and gained through Internet searches, print media, video, pictures, samples, field trips, guest speakers, etc.

6. Richness of the problem to invite open-ended investigation. Some problems invite a variety of viable answers and multiple ways to represent and solve. Some contrived problems may appear to be real-world but are not realistic or cognitively demanding.

The modeling process is enhanced by:

1. The facilitative skill of the teacher. The teacher must create a positive and safe environment where student ideas and questions are honored and constructive feedback is given by the teacher and by other students. Students do the thinking, problem solving and analyzing.

2. The content knowledge of the teacher. The teacher understands the mathematics relevant to the context well enough to guide students through questioning and reflective listening.

3. Teacher and student access to a variety of representations, and mathematical tools such as manipulatives and technological tools (sketchpad, spreadsheets, internet, graphing calculators, etc.).

4. Teacher and student understanding of the modeling process. Teachers and students who have had prior experience have better understanding of the modeling process and the use of models.

5. Teacher and student understanding of the context. Background information/experience may be needed and gained through Internet searches, print media, video, pictures, samples, field trips, guest speakers, etc.

6. Richness of the problem to invite open-ended investigation. Some problems invite a variety of viable answers and multiple ways to represent and solve. Some contrived problems may appear to be real-world but are not realistic or cognitively demanding.

7. Context of the problem. Selecting real-world problems is important, and real-world problems that tap into student experience, (prior and future), and interest are preferred.

What extra skills do teachers need to make this a reality? The key elements here include:

1. Handling discussion in the class in a non-directive but supportive way, so that students feel responsible for deciding on the correctness of their and others' reasoning and do not to expect either answers or confirmation from the teacher;

2. giving students time and confidence to explore each problem thoroughly, offering help only when the student has tried, and exhausted, various approaches (rather than intervening at the first signs of difficulty);

3. providing strategic guidance and support without structuring the problem for the student or giving detailed suggestions

4. finding supplementary questions that build on each student's progress and lead them to go further.

Challenge
• Teaching through modeling is a paradigm shift.
• The results are worth it:
• Students retain more of what they learn.
• Students are more engaged.
• Teachers are much less tired at the end of the day!
Let’s Have Some Fun!
• With your group, select one of the four problems.
• Solve the problem:
• Record your group thinking as you do each step.
• Go through the process as many times as necessary until you feel you have a good answer.
• Each group will report to everyone.

Elevator Problem

• Suppose a building has 5 floors (1 – 5) which are occupied by offices. The ground floor (0) is not used for business purposes. Each floor has 80 people working on it, and there are 4 elevators available. Each elevator can hold 10 people at one time. The elevators take 3 seconds to travel between floors and average 22 seconds on each floor when someone enters or exits. If all of the people arrive at work at about the same time and enter the elevators on the ground floor, how should the elevators be used to get the people to their offices as quickly as possible?
• Pasture Land
• A rancher has a prize bull and some cows on his ranch. He has a large area for pasture that includes a stream running along one edge. He must divide the pasture into two regions, one region large enough for the cows and the other, smaller region to hold the bull. The bull’s pasture must be at least 1,000 sq. meters (grazing) and the cow pasture must be at least 10,000 sq. meters to provide grazing for the cows. The shape of the pasture is basically a rectangle 120 meters by 150 meters. The river runs all the way along the 120 meter side. Fencing costs \$5/meter and each fence post costs \$10.00. Any straight edge of fence requires a post every 20 meters and any curved length of fence requires a post every 10 meters. Help the rancher minimize his total cost of fencing.
• Faculty
• When confronted with a rise of 142 students in a school of 480, and a capacity for 7 new teachers, in what departments should the new teachers be placed? Placing the new teachers should maintain the ideal student-teacher ratio. The current makeup of the faculty and student enrollment in each department is:
• Art 1, 99 Biology 4, 319 Chemistry 3, 294 English 5, 480 French 1, 122 German 1, 51
• Spanish 1, 110 Mathematics 6, 613 Music 1, 95 Physics 3, 291 Social Studies 4, 363
• A Country and Its Food Supply
• The population of a country is initially 2 million people and is increasing at 4% per year. The country’s annual food supply is initially adequate for 4 million people and is increasing at a constant rate adequate for an additional 0.5 million people per year.
• (a) Based on these assumptions, in approximately what year will this country first experience shortages of food?
• (b) If the country doubled its initial food supply, would shortages still occur? If so, when? (Assume the other conditions do not change).
• (c)  If the country doubled the rate at which its food supply increases, in addition to doubling its initial food supply, would shortages still occur? If so, when? (Again, assume the other conditions do not change.)
• (Problem from Connally, Hughes Hallett et al.)
Thank You!

Do not hesitate to contact me if you have questions or want more information.

Margaret Kidd

session 365

mkidd@fullerton.edu
