Presentation Transcript
diameter general purpose session draft liebsch dime diameter gps 01 txt

Diameter General Purpose Sessiondraft-liebsch-dime-diameter-gps-01.txt

M. Liebsch, G. Punz

IETF80, PragueDiameter Maintenance and Extensions (DIME) WG

01st April 2011

history
History
  • Initial version presented at IETF78 in Maastricht
  • Updated version presented at IETF79 in Beijing
  • First revision addresses comments and adds more details as well as clarifications
    • GP Session concept
    • Context Grouping
      • Analysis
      • Approaches
idea behind the gp session 2 2
Idea behind the GP Session (2/2)

AVPs apply to single user

Single-user context(RFC3588)

Diameter Hdr

Session-ID

AVPs

Maintain standard format,but adopt new interpretation

AVPs apply to group of users

Multi-user context/ Bulk signaling

Diameter Hdr

GP Session-ID

Users

AVPs

- Group-ID

- List of individual Session-IDs

- Grouped AVP

coding options for bulk signaling in the order of efficiency
Coding options for bulk signaling(in the order of efficiency)
  • Group-ID identifies multiple users, list of attributes/values applies to all users of the group
  • List of Session-IDs identifies a group of users, list of attributes/values applies to all users of the group
  • List of Session-IDs identifies multiple users, each Session-ID has an individual list of AVPs associated

Diameter Hdr

GP Session-ID

AVP 1

AVP 2

AVP N

Group-ID

Diameter Hdr

GP Session-ID

AVP 1

AVP 2

AVP N

Session-ID 1

Session-ID K

Diameter Hdr

GP Session-ID

Session-ID 1

AVP 1.1

AVP 1.2

AVP 1.N

Session-ID K

AVP K.1

AVP K.2

AVP K.N

valuable positive feedback
Valuable & Positive Feedback
  • More use cases and enlarged scope
  • GP Session has value, but represents a new application
    • Platform for specification: DIME or alternative group
  • Good idea, but overloading only 3GPP habit
    • New messages as alternative
  • GP Session has clear rules, but other SDOs (TISPAN) just ignore the Session ID
  • Enlarge the scope of the idea to address also signaling without Session ID
    • Focus on grouping for bulk signaling
what s next
What‘s Next?
  • Proposal to split the current draft
    • Target 2 separate documents
    • Approach meets all comments
  • (1) Diameter GPS
    • Focus on the use of a shared Session ID
    • Extension to Diameter base or New Application
    • May come with other functions
      • Query, State Restoration, ...
  • (2) Coding Options for bulk signaling
    • Enables use with other Diameter signaling
      • No limitation to Session ID based messages
what s next1
What‘s Next?
  • Interest in working on this?
  • Thanks for all comments !
idea behind the gp session 1 2
Idea behind the GP Session (1/2)
  • Eshablish a dedicated session (and Session-ID) to signal multi-user context (bulk signaling)  GP Session
  • Clarification: GP Session-ID does not identify a group of users!
  • GP Session-ID..
    • .. allows the re-use of available commands (e.g. STR), which mandate a single Session-ID AVP, to signal attribues/values applying to multiple users
      • RFC3588: Single Session-ID AVP at fixed location (after Diameter header) identifies the user where subsequent attribute/values apply to
    • .. indicates that attributes/values apply to a group of users or all users!
    • .. avoids specification of new command codes and formats for bulk signaling
again use cases
Again: Use cases
  • Bulk signaling, e.g.
    • Bulk Session Termination using STR
    • Bulk policy enforcement
  • Recovery from total/partial Diameter node failure

Server states restoration

Group policy enforcement

server

server

Req(multiple users [failed_server_id])

Req(multiple users, context1, context2, ...contextN)

Resp (multiple users,context1, context2,... contextN)

client

client

PCEF

data traffic

Policy Enforcement

stepwise realization of the extended session concept
Stepwise realization of the extended session concept

Deployment-specificguidelines forbulk signaling

Specify GP Sessionextension

Bulk-signaling operation andextensions specified in Applications

Deployment by usingRFC4006+ and RFC4005+

Deployment-specific guidelines and specification (e.g. By 3GPP)

NASREQRFC4005

BulkExt.

BulkExt.

NASREQRFC4005+

Credit ControlRFC4006

Credit ControlRFC4006+

GPS

GPS

Diameter Base RFC3588

Diameter Base RFC3588
