  1. 3/16” 1” 1”

  2. Tab shown setting on tee surface This gap can be more than what is shown, + .0625, but if the piece bottoms out here, but the top tab doesn’t sit on top of the tee, then the tab is bent incorrectly. .06” Cladding edge should fit snugly against the edge of the tab, in fact this is an automatic aligning feature for locating the cladding correctly.
