  1. Representing Molecules Resonance Exceptions to the Octet Rule Formal Charge

  2. Bond Length • The average distance between two bonded atoms • The distance between nuclei at their minimum potential energy

  3. Bond Dissociation Energy • Also called “bond energy” • The energy required to break a bond and form neutral isolated atoms

  4. Trends in Bond Energy • C-C vs. C=C vs. C≡C • Higher bond energy for multiple bonds compared to single bonds • Triple bonds are shorter on average than single bonds • There can be a lot of variation in bond length, depending on other bonds for those atoms

  5. Bond Energy & Bond Length • Higher bond dissociation energy is linked to lower chemical reactivity • Longer bond lengths  lower bond dissociation energies • “Short bonds are strong bonds”

  6. Ozone, O3 • Draw a Lewis structure for ozone (the oxygen atoms are in a line) Both structures are equally correct!

  7. Resonance Structures • Sometimes, more than one correct Lewis structure can be drawn for a compound • A single Lewis structure may be inadequate for describing the situation • “resonance” structures • Same arrangement of atoms, same numbers of single and multiple bonds • Link the multiple structures with a double headed arrow

  8. Resonance • The actual structure is a “blend”, somewhere in between the Lewis structures • Alternating single/double bonds would have different bond lengths • In the real molecule, all the bond lengths are identical!

  9. Problem • A problem to try: • Draw resonance structures for the nitrate ion, NO3-

  10. Exceptions to the Octet Rule • Elements in row 3 or below on the periodic table can have expanded octets • i.e., they can have more than 8 electrons, because they may use d orbitals in bonding • B, Be may be “electron deficient” • Fewer than 8 electrons around central atom

  11. Nonequivalent Lewis Structures • If a molecule or polyatomic ion exceeds the octet rule, or if different skeletal arrangements (i.e. isomers) are possible, non-equivalent Lewis structures may be drawn. • Million dollar question: Which Lewis structure best describes the actual bonding situation? • Use “formal charge” to evaluate

  12. Formal charge • FC = # valence electrons – (# of lone pair electrons) – (# bonds) • Calculated for each atom • Sum of formal charges must equal overall charge of species • The most appropriate Lewis structures have: • Lowest formal charges (zero is best) • Negative formal charge on the most electronegative element

  13. Calculate formal charges • Which is the most appropriate structure for the molecule CCl2O?

  14. Problem • Below are two different Lewis structures for nitrous acid (HNO2). H-O-N=O: H-N=O :O: • Which is the better Lewis structure based only on formal charge arguments? .. .. .. .. .. .. .. ..
