Presentation Transcript
atmospheric results from the nacp s mid continent intensive field campaign
Atmospheric Results from the NACP’s Mid Continent Intensive Field Campaign

Natasha Miles, Scott Richardson, Arlyn Andrews, Kathy Corbin, Kenneth Davis, Liza Diaz, Scott Denning, Erandi Lokupitiya, Douglas Martins, Paul Shepson,

Colm Sweeney, and Tris West

ICDC8: September 2009

slide2

Atmospheric results from the NACP’sMid Continental Intensive

Rosemount

LEF

  • Overall goal of Mid-Continental Intensive: Seek convergence between top-down and bottom-up estimates of the regional flux
  • “Oversample” the atmosphere in the study region
  • Atmospheric results
    • Purdue Univ / NOAA ALAR (aircraft) Campaign
    • NOAA aircraft program
    • 9 tower sites (NOAA, PSU, U of Minn)
    • NOAA Carbon Tracker
    • CSU SiBcrop-RAMS model
    • Comparisons to agricultural and satellite data

~ 500 km

noaa purdue university alar
NOAA / Purdue University ALAR

Regional Survey

15 – 25 June 2007

Colm Sweeney (NOAA/ESRL)

Paul Shepson (Purdue University)

Doug Martins (Purdue University)

385 ppm

Front

365 ppm

17 June 2007

15 June 2007

noaa purdue university alar1
NOAA / Purdue University ALAR

Lagrangian Flux Estimates: 19 June 2007

Tower-based eddy covariance fluxes from the Brooks Field Site near Ames, IA

Flux tower: soybeans

Flight Path

Flux tower: corn

Regionally-averaged aircraft CO2 flux

Flux = -10.3±2.4 μmol/m2/s

In-situ Profiles

Martins et al., 2009

slide5

NOAA Aircraft Program CO2 Measurements

8000

8000

8000

8000

  • Climatology of 12 of 16 currently running NOAA aircraft project sites
  • 2 – 3 profiles / month at each site
  • Increase in amplitude of the seasonal cycle from west to east

18

CO2 (ppm)

Altitude (m)

4000

4000

4000

4000

0

200

200

200

200

-15

8000

8000

0

6

12

0

6

12

0

6

12

0

6

12

18

CO2 (ppm)

Altitude (m)

4000

4000

0

200

200

-15

8000

8000

0

6

12

0

6

12

18

CO2 (ppm)

Altitude (m)

4000

4000

0

200

200

-15

8000

8000

8000

8000

0

6

12

0

6

12

CO2 (ppm)

18

Altitude (m)

4000

4000

4000

4000

0

200

200

200

200

-15

0

6

12

0

6

12

0

6

12

0

6

12

C. Sweeney (NOAA)

Deviation from global mean [CO2]

slide6

NOAA tall towers in MCI region

  • Non-dispersive infrared spectroscopy (LiCor, Inc.) instruments
  • LEF (1994 – current)
  • WBI (July 2007 – current)

PSU Ring 2 towers

  • Network of 5 cavity ring-down spectroscopy (Picarro, Inc.) instruments surrounding Iowa (April 2007 – October 2009)
    • Centerville, IA
    • Galesville, WI
    • Kewanee, IL
    • Mead, NE
    • Round Lake, MN
  • Additional well-calibrated site on Ameriflux tower at Missouri Ozarks, MO

Rosemount

LEF

U. Of Minn Rosemount* tower

  • Tunable diode laser instrument
  • May 2007 – current

* data courtesy of T. Griffis

spatial differences gradients during 2007 growing season on a daily time scale
Spatial differences / gradients during 2007 growing season on a daily time scale
  • Large differences / gradients for some site pairs
  • West Branch - Centerville

Difference

Gradient

spatial differences gradients during growing season on a daily time scale
Spatial differences / gradients during growing season on a daily time scale
  • Large differences / gradients for some site pairs
  • West Branch - Centerville (160 km)
  • Other site pairs: lower differences / gradients
  • Mead – Centerville(300 km)
  • Median differences:6.0and 1.7 ppm
  • Median gradients:0.04and 0.006 ppm/km

Difference

Gradient

seasonal cycle
Seasonal cycle
  • Large variance in seasonal drawdown, despite being separated by ~ 500 km
  • 2 groups: 33 – 39 ppm drawdown and 24 – 29 ppm drawdown (difference of about 10 ppm)

Mauna Loa

wbi aircraft

* NOAA (Andrews/Sweeney) ** U of Minn (Griffis)

seasonal cycle1
Seasonal cycle
  • Large variance in seasonal drawdown, despite being separated by ~ 500 km
  • 2 groups: 33–39 ppm drawdown and 24 – 29 ppm drawdown (difference of about 10 ppm)

Mauna Loa

wbi aircraft

* NOAA (Andrews/Sweeney) ** U of Minn (Griffis)

seasonal cycle2
Seasonal cycle
  • Large variance in seasonal drawdown, despite being separated by ~ 500 km
  • 2 groups: 33 – 39 ppm drawdown and 24 – 29 ppm drawdown (difference of about 10 ppm)

Mauna Loa

wbi aircraft

* NOAA (Andrews/Sweeney) ** U of Minn (Griffis)

corn npp in the mid continental intensive region 20071
Corn NPP in the Mid Continental Intensive region: 2007

Sites with larger seasonal [CO2] drawdown

- Consistent with “Corn belt” according to NPP

T. West

model data comparisons forwards results
Model-data comparisons (forwards results)
  • SiBcrop-RAMS (K. Corbin; A. Schuh; E. Lokupitiya; A.S. Denning)
    • June-August 2007
    • Regional
    • Coupled with crop phenology model for corn and soybean developed by Lokupitiya et al. (2009); *wheat to be added
  • NOAA-ESRL Carbon Tracker (A. Andrews; A. Jacobson)
    • 2007
    • Global
    • Optimized to best fit data on global obs network (not including Ring 2)

wheat*

corn

soy

http://carbontracker.noaa.gov

slide15

Observations vs Carbon Tracker: 2007

  • Overall drawdown in CT 2008 is too weak
  • But some features of modeled variability are consistent with obs- large variability- mm has less drawdown than wbi, rl, and kw in both model and obs
slide16

Observations vs Carbon Tracker: 2007

Obs - model (ppm)

2007

  • Suggestive that CT model could be improved by adding crop details
  • Trajectory analysis: LEF residuals large for southerly trajectories, small for northerly trajectories

Corn belt sites

Liza Diaz (PSU)

slide17

Observations vs SiBcrop-RAMS: 2007 growing season

growing

season

  • Overall drawdown compares well
  • Problems with spatial distribution
slide18

Observations vs SiBcrop-RAMS: 2007 growing season

Obs – model (ppm)

  • Problems with spatial distribution
    • Corn belt sites: not enough drawdown
    • Centerville, LEF: too much drawdown
    • Using more realistic percentages for land cover, especially for corn, may improve results

Corn belt sites

seasonal cycle interannual variability
Seasonal cycle: interannual variability
  • West Branch (wbi) and Centerville (ce) differ significantly from 2007 to 2008
  • From agricultural statistics (NASS), total estimated NPP of corn (T. West) 222 PgC for 2007 207 PgC for 2008

Mauna Loa

wbi aircraft

* NOAA (Andrews/Sweeney) ** U of Minn (Griffis)

flooding in the midwestern u s june 2008

Cedar Rapids, IA Don Becker (USGS)

Dell Creek breach of Lake Delton, WI U.S. Air Force

Flooding in the Midwestern U.S.: June 2008
delay in seasonal drawdown
Delay in seasonal drawdown

2008

  • 2008 [CO2] minima is delayed by 2 – 4 weeks, compared to 2007
  • Effect of flood?

2007

2007 solid

2008 dashed

normalized difference vegetation index ndvi for iowa crops
Normalized Difference Vegetation Index (NDVI) for Iowa crops
  • Satellite-based: 2-week delay of phenological curve for 2008 compared to 2007, for both corn and soy

T. West

slide24

Summary

  • Aircraft and tower results both indicate large spatial gradients between sites despite relatively small site separations
  • Seasonal cycle:
    • Difference amongst sites, some with very large seasonal drawdown
  • Comparisons of tower obs to CarbonTracker and SiBcrop-RAMS
    • Important to model agriculture correctly
    • Transport important also
  • Interannual variability: flooding in June 2008, atmospheric data corroborated by satellite and agricultural statistics data
  • What spatial density of tower measurements is necessary? To be answered by including subsets of the Ring 2 data in the inversions

Natasha Miles

Penn State University
