slide2
LSST is a multi-agency project

NSF / DOE coordinated – MOU established

National Science Board: NSF Director can move LSST forward

DOE has assigned SLAC National Accelerator Center to build the Camera

LSST is now an independent AURA Center for construction

LSST Center and NOAO Center have MOU for specific cooperation

Project is organized and preparing for July 2014 construction

New C.A for Design and Development FY13- FY15

Budget set: Requesting $466M NSF, $160M DOE, $36M Private

Schedule duration is 7 years 3 months from NSF construction start

The LSST Project continues to progress steadily in anticipation of a July 2014 formal construction start

LSST was ASTO 2010 highest ranked new ground based facility – We are preparing for a 2014 Start

the need for a new survey telescope has been recognized for many years
The need for a new survey telescope has been recognized for many years
  • 1996-2000 “Dark Matter Telescope”

Emphasizedmapping dark matter in the universe

  • 2000 - “LSST”

Emphasizes a broad range of science from the same multi-wavelength survey data, including unique time domain exploration

  • 2003 - LSST Corporation
  • 2011 – AURA LSST Center
the lsst science book describes the investigations possible from a single survey
The LSST Science Book describes the investigations possible from a single survey
  • Strong end user case
  • 245 contributors
  • 11 science collaborations
  • 598 pages
  • Living document

(on lsst.org)

  • arXiv/0912.0201

http://www.lsst.org/lsst/scibook

the lsst survey will address today s compelling questions in astro physics
The LSST survey will address today’s compelling questions in astro-physics
  • Probing dark matter and dark energy
  • Mapping the Milky Way
  • Finding Near earth asteroids and other transients
  • A single unprecedented survey:
    • 20 billion objects cataloged
    • 4 billion galaxies with redshifts
    • 6 filters covering 320 – 1050 nm
    • Time domain information x1000 (106 supernovas)
    • High precision, high uniformity, calibrated data

Finding Near Earth Asteroids

lsst receives strong astro2010 decadal survey endorsement
LSST receives strong Astro2010 decadal survey endorsement
  • LSST ranked as the highest priority large ground-based facility for the next decade.
    • Compelling Science case
    • Addresses many science goals

(massively parallel astro-physics)

    • Technical maturity
    • Risk and appraised costs are ready for construction process
    • LSST is most “ready-to-go”
large synoptic survey telescope lsst
Large Synoptic Survey Telescope (LSST)
  • To build an observing facility, conduct 10-year survey, archive and serve images and developed data products
  • Wide Fast Deep Optical Survey
  • 8.4 M Primary Aperture
  • 3.5 Degree Field Of View
  • 3.2 Billion Pixel Camera
  • ~40 Second Cadence
    • Two 15 second exposures
    • Full sky coverage every few nights
  • Data Served and Archived
    • Alerts of new events
    • Catalogs of objects
  • Education and Public Outreach is included

2012

what makes the lsst a unique telescope

(Full moon is 0.5 degrees)

What makes the LSST a unique Telescope?

Primary Mirror

Diameter

Field of

View

0.2 degrees

Gemini South

Telescope

8 m

3.5 degrees

LSST

8.4 m

wide fast deep coverage of the available sky
Wide Fast Deep coverage of the available sky
  • Each sky patch will be visited >800 times
  • Asurvey of 20 billion objects in space and time
lsst probes 100x fainter enables the exploration of the time domain
LSST probes 100x fainter & enables the exploration of the time domain

ca. 1950 POSS

(Photographic)

ca. 2000 SDSS

(Digital)

ca. 2021 LSST

(Digital + Time Domain)

lsst designed to be a community resource
LSST Designed to be a Community Resource

Open data

    • No proprietary period for U.S. and Chilean astronomers
    • Funding model designed to serve these two communities

Open Source Software

New Model for Astronomy

    • Excites significant scientific enthusiasm
    • Agency Support
    • Public excitement
  • Huge opportunity for education and multi discipline interaction
    • STEM education and public interaction
    • Database technology and Data intensive science
lsst has attracted a great deal of interest
LSST has attracted a great deal of interest
  • LSST Corporation has 36 institutional partners
  • Operations strategy now includes 66 international institutions
  • Over 400 scientists in 12 different Science collaborations
  • ~10 years of DOE and NSF design support
  • ~$40 in Private donations
lsst is investing in significant survey and image simulation
LSST is investing in significant survey and image simulation

Observing an LSST simulation

Producing a simulated image

Pointing, Filter, Airmass, Time and Atmosphere from Op Sim

Custom instance of field of view

1010 photons per CCD

Separate amplifiers

site selection was an early trade that supports design and construction readiness
Site selection was an early trade that supports design and construction readiness

Central Chile Location Map

Cerro Pachón chosen in 2006 after 2 year global evaluation by international committee.

La Serena airport

La Serena

port

50 km paved highway

LSSTBase Facility

Coquimbo

Puclarodam & tunnel

Vicuña

CTIO

AURAproperty(Totoral)

40km dirt road

Pan-American Highway

Gemini & SOAR

N

LSST SITE

0

10

20 km

site choice supports design maturity cost basis risk and construction preparation
Site choice supports design maturity, cost basis, risk and construction preparation
  • Environmental and Use permits in place
  • Chilean “10%” agreement completed

LSST rendering

Gemini

SOAR

----2647 m

lsst corporation invested non federal funds for early site leveling in 2011
LSST Corporation invested non-federal funds for early site leveling in 2011
  • Stage 1 of summit leveling
    • ~4,000 kg of explosives
    • 12,500 m3 removed on main site

First production blast: March 8th 2011,

60 kg of explosive dislodges ~320 m3 of rock

the lsst optical system is 3 mirrors and 3 lenses to form 3 5 field of view
The LSST optical system is 3 mirrors and 3 lenses to form 3.5° field of view

Secondary Mirror

Camera Lenses

Primary and Tertiary Mirrors

mirror designs are advanced private funding enabled early start of both reflective optics
Mirror designs are advanced - Private funding enabled early start of both reflective optics
  • Primary-Tertiary cast in 2008.
  • Fabrication underway at the Steward Observatory Mirror Lab - completion in Summer 2013.
  • Secondary substrate fabricated by Corning in 2009.
  • Currently in storage waiting for construction.
lsst is ready for secondary mirror optical fabrication vendor selection process
LSST is ready for secondary mirror optical fabrication vendor selection process
  • Pre-solicitation announcement in FedBizOpps - 26 June 2012
  • Release Request for Proposal: August 2012
    • Full bid for optical fabrication
    • Time and materials hardware integration/test
    • Optional effort to build mirror support hardware
  • Phase A: Initial final design work and vendor specific risk reduction
  • Phase B: Fabrication phase authorized only after MREFC start
  • Early identification of optical fabrication contractor allows FDR preparation and cost basis
m2 proposal evaluation plans
M2 Proposal Evaluation Plans
  • Project Evaluation = 4 weeks.
  • AURA Approval = 3 weeks.
  • NSF Approval = 4 weeks (Longer for Holidays in this schedule).
  • Final Negotiation and contract placement = 3 weeks.
  • 3 1/2 months to let a contract assumes no significant issues.
  • This M2 procurement is a pathfinder to validate our approach.
camera system design is well advanced
Camera system design is well advanced
  • 3.2 Gigapixel science array – 63 cm diameter
  • Wavefront and guide sensors
  • 2 second readout
  • 5 filters in camera
  • Electronics

Utility Trunk—houses support electronics and utilities

Cryostat—contains focal plane & its electronics

L3 Lens

1.65 m

(5’-5”)

Filter

Focal plane

L2 Lens

L1 Lens

Camera ¾ Section

lsst focal plane is a modular design of 21 rafts totaling 189 science sensors
LSST focal plane is a modular design of 21 rafts totaling 189 science sensors

4K x 4K CCD with 10µm pixelsis divided into 16 1Mpix segments with individual readout

3X3 CCD “RAFT”

Each raft has electronics and thermal elements to be autonomous 144 Mpixel array

summit facility fixed building 90 design completed 100 before end of year
Summit facility (fixed building) 90% design completed – 100% before end of year

30 m diameter dome

1.2 m diameter atmospheric telescope

Control room and heat producing equipment (lower level)

1,380 m2 service and maintenance facility

Stray light and Wind Screen

Wind light screen prototype designed for mechanism and life testing

a peta scale data management system has been designed for the lsst
A Peta-scale data management system has been designed for the LSST
  • LSST Data Management System must deal with an unprecedented data volume.
    • one 6.4-gigabyte image every 17 seconds
    • 15 terabytes of raw scientific image data / night
    • 60-petabyte final image data archive
    • 20-petabyte final database catalog
    • 2 million real time events per night every night for 10 years
  • Provide a highly reliable open source system to provide:
    • Real time alerts,
    • catalog data products,
    • image data.
  • Provides the infrastructure to transport, process, and serve the data.
cyber infrastructure is defined and capacity has been identified to handle data volume
Cyber infrastructure is defined and capacity has been identified to handle data volume

Archive /Data Center

Data Release Production at IN2P3

  • Summit-Base network will be installed by the project.
  • Working with NSF funded network consortiums on capacity.
  • International protected network identified and quoted (upgraded.)

MOU in place – Technical details pending

lsst data processing pipelines are designed and prototyped and tested in data challenges
LSST data processing pipelines are designed, and prototyped and tested in data challenges
  • Data Challenges have continued every 6 months.
  • Unique database design to address multiple trillion row data sets.
epo is developing products and tools to meet the public user where they are
EPO is developing products and tools to meet the public user where they are
  • Collaborating with DM on User Interface Design: Sharing UML Domain Model.
  • Building Sustainable Partnerships: Outreach Advisory Board, Potential Collaborators.
  • Prototyping Modules: Citizen Science, iPhone app, WWT Tour, Multiuser Touchtable interfaces.
  • Documenting: Baseline Design, Subsystem Requirements, Inclusion in SysML model.
management team for construction period has continuity with current staff

Director / LSSTC President

  • Sidney Wolff
  • Deputy Director
  • Steve Kahn
Management team for construction period has continuity with current staff
  • Chief Scientist
  • Tony Tyson
  • Project Scientist
  • Zeljko Ivezic
  • Project Manager
  • Victor Krabbendam
  • Calibration Scientist
  • Tim Axelrod
  • Image Simulation Scientist
  • Andy Connolly
  • Op. Simulation Scientist
  • Abi Saha
  • Business Manager
  • Daniel Calabrese
  • Safety Manager
  • Chuck Gessner
  • Science Council
  • Systems Engineer
  • Chuck Claver
  • Systems Scientist
  • Open
  • Camera Project Manager
  • Nadine Kurita
  • Project Scientist
  • Andy Rasmussen
  • Data Management Project Manager
  • Jeff Kantor
  • Project Scientist
  • Mario Juric
  • Telescope and Site Project Manager
  • Bill Gressler
  • Project Scientist
  • Open
  • Education and Public Outreach Manager
  • Suzanne Jacoby
  • Project Scientist
  • Tim Axelrod
lsst total federal construction budget sets not to exceed levels
LSST total federal construction budget sets not to exceed levels

or

* Private funded construction not included in pie chart

construction budget profile matches each agency s funding plans and outlook
Construction budget profile matches each Agency’s funding plans and outlook
  • DOE yearly budget profile is included in department of Science budget
  • NSF MREFC funding fits within projections
lsst project objective is preparing for construction
LSST Project objective is “Preparing for Construction”

Highest Priority is Preparing for next Agency Reviews

  • CD3a and FDR late in 2013
  • Update/upgrade Project Management Control System

Prolonged D&D to “Time is money” construction

  • Maintain excellent scientific ties
  • Program is now constrained - Track progress toward plan

Staffing Additions

  • Director, Systems Engineer, PMCS, Office Administrator

Business System Updates

  • $10M/yr to $100M/yr organization
  • “Routine”, “Robust”, and some case “enhance”

Continue Technical Progress and Risk reduction

future home of lsst on cerro pach n
Future home of LSST on Cerro Pachón

LSST Site

Calibration Hill

Image credit: David Walker

lsst project and corporation have developed in preparation for mrefc construction
LSST Project and Corporation have developed in preparation for MREFC Construction
  • LSSTC is a 501(c) 3 founded in 2003 to build and operate the LSST
  • In October 2011 LSST construction project became and Independent AURA Center

- The University of Arizona

- University of Washington

- National Optical Astronomy Observatory

- Research Corporation for Science Advancement

- Adler Planetarium- Brookhaven National Laboratory (BNL) - California Institute of Technology- Carnegie Mellon University- Chile- Cornell University- Drexel University- Fermi National Accelerator Laboratory - George Mason University- Google, Inc.- Harvard-Smithsonian Center for Astrophysics- Institut de Physique Nucléaire et de Physique des Particules (IN2P3)- Johns Hopkins University- Kavli Institute for Particle Astrophysics and Cosmology

- Stanford University- Las Cumbres Observatory Global Telescope Network, Inc.

- Lawrence Livermore National Laboratory(LLNL)- Los Alamos National Laboratory (LANL)

  • - National Radio Astronomy Observatory (NRAO - Princeton University- Purdue University- Rutgers University- SLAC National Accelerator Laboratory- Space Telescope Science Institute- Texas A & M University- The Pennsylvania State University- University of California at Davis- University of California at Irvine- University of Illinois at Urbana- Champaign- University of Michigan- University of Pennsylvania- University of Pittsburgh- Vanderbilt University
several key and defining requirements flowdown to the observing system
Several key and defining requirements flowdown to the observing system
  • High throughput optical system for image depth.
    • 8.4 meter primary aperture and 1.6 meter diameter camera lens
    • 3.5 degree field of view, 6 filters, fast f/1.2 beam
  • Sky coverage with quick and agile telescope.
    • 15 second exposure – 2 second readout – 15 second exposure
    • “5 sec slew & settle” between visits
  • Tight control of systematic error and noise.
    • Image quality and PSF shape control
    • Well baffled camera, telescope and facility
  • High efficiency and duty cycle.
    • Repeating all night, each night for 10 years
    • Maintenance support to limit downtime
  • High Capacity data management system
    • 2.5 million visits – 5 million images
    • 15Tb /night – 100Pb after 10 years
