preview
Preview
  • The relationship (for a max problem) between the z-values for the current bfs and the new bfs:

z-value for new bfs= z-value of current bfs –(value of entering variable in new bfs) (coefficient of entering variable in row 0 of current bfs) (15)

preview1
Preview
  • (coefficient of entering variable in row 0)<0 and (value of entering variable in new bfs)≥0
  • We can deduce the following facts:

if (value of entering variable in new bfs)>0, then (z-value for new bfs)>(z-value for current bfs)

If (value of entering variable in new bfs)=0, then (z-value for new bfs)=(z-value for current bfs)

preview2
Preview
  • In each of the LP’s basic feasible solutions, all the basic variables are positive(>0). An LP with this property is a nondegenerate LP.
  • When the simplex is used to solve a nondegenerate LP, it is impossible to encounter the same bfs twice. We are guaranteed to find the optimal solution in a finite number of iterations.
preview3
Preview

The simplex may fail for a degenerate LP.

  • DEFINITION

An LP is degenerate if it has at least one bfs in which a basic variable ia equal to zero.

example
example
  • The following LP is degenerate:

max z=5x1+2x2

s.t. x1+x2≤6

x1-x2≤0 (16)

x1,x2≥0

Adding slack variables s1 and s2 to the two constraints.

example1
example
  • A degenerate LP

The basic variable s2=0, thus, (16) is a degenerate LP.

Note: any bfs that has at least one basic variable equal to zero( or equivalently, at least one constraint with a zero right-hand side) is a degenerate bfs.

example2
example
  • Since -5<-2, we enter x1 into the basis. The winning ratio is 0 in row 2.

Our new bfs has the same z-value as the old bfs. In the new bfs, all variables have exactly the same values as they had before the pivot! Thus, our new bfs is also degenerate.

example3
example
  • Continuing with the simplex, we enter x2 in row 1.

This is an optimal tableau, so the optimal solution to (16) is z=21, x2=3,x1=3,s1=s2=0.

slide10
In solving a degenerate LP, we arit is possible for a pivot to leave the value of z unchanged.
  • A sequence of pivots like the following may occur:

initial bfs(bfs 1):z=20

after first pivot(bfs 2):z=20

after second pivot(bfs 3):z=20

after third pivot(bfs 4):z=20

after fourth pivot(bfs 1):z=20

In this situation, we encounter the same bfs twice. This occurrence is called cycling.

slide11
If cycling occurs, we will loop forever among a set of basic feasible solutions and never get to the optimal solution.
  • The simplex algorithm can be modified to ensure that cycling will never occur.
  • In practice, cycling is an extremely rare occurrence.
  • If an LP has many degenerate basic feasible solutions (or a bfs with many basic variables equal to zero) , the simplex algorithm is often very inefficient.
the big m method
The big M method
  • The simplex algorithm requires a starting bfs. We found a starting bfs by using the slack variables as our basic variables.
  • If an LP has any ≥ or equality constraints, a starting bfs may not be readily apparent.
  • The big M method (or the two-phase simplex method) may be used.
example 4
Example 4
  • Bevco manufactures an orange-flavored soft drink called Oranj by combining orange soda and orange juice.

Each ounce of orange soda contains 0.5 oz of sugar and 1 mg of vitamin C. each ounce of orange juice contains 0.25 oz of sugar and 3 mg of vitamin C.

It costs Bevco 2¢ to produce an ounce of orange soda and 3¢ to produce an ounce of orange juice.

example 41
Example 4
  • Bevco’s marketing department has decided that each 10-oz bottle of Oanj must contain at least 20 mg of vitamin C and at most 4 oz of sugar.

Use LP to determine how Bevco can meet the marketing department’s requirements at minimum cost.

example 42
Example 4
  • Solution

Let

x1=number of ounces of orange soda in a bottle of Oranj

x2=number of ounces of orange juice in a bottle of Oranj

Then the appropriate LP is

min z=2x1+3x2

s.t. 1/2x1+1/4x2≤4 (sugar constraint)

x1+ 3x2≥20 (vitamin C constraint) (17)

x1+ x2=10 (10 oz in bottle of Oranj)

x1,x2≥0

example 43
Example 4
  • Put (17) into standard form

z -2x1 -3x2 =0

1/2 x1+1/4x2+s1 =4

x1+ 3x2 -e2=20

x1+ x2 =10

All variables nonnegative

example 44
Example 4
  • Search for a bfs

In row 1, s1=4 could be used as a basic variable

In row 2, e2=-20 violates the sign restriction.

In row 3, there is no readily apparent basic variable.

slide18
Artificial variables

To remedy this problem, we simply “invent” a basic feasible variable for each constraint that needs one. These variables are created by us and are not real variables, we call them artificial variables.

If an artificial variable is added to row i, we lable it ai.

example 45
Example 4
  • In th current problem, we need to add an artificial variable a2 to row 2 and an artificial variable a3 to row 3.

z -2x1 -3x2 =0

1/2 x1+1/4x2+s1 =4

x1+ 3x2 -e2+a2 =20 (18)

x1+ x2 +a3 =10

We now have a bfs: z=0,s1=4,a2=20,a3=10

slide20
There is no guarantee that the optimal solution to (18) will be the same as the optimal solution to (17).
  • In a min problem, we can ensure that all the artificial variables will be zero by adding a term Mai to the objective function for each artificial variable ai. (in a max problem, add a term –Mai to the objective function.)

Here M represents a “very large” positive number.

example 46
Example 4
  • In (18), we could change our objective function to

min z=2x1+3x2+Ma2+Ma3

The row 0 will change to

z-2x1-3x2-Ma2-Ma3=0

  • With this modified objective function, it seems reasonable that the optimal solution to (18) will have a2=a3=0. in this case, the optimal solution to (18) will solve the original problem (17).
  • Some of the artificial variables may assume positive values in the optimal solution. If this occurs, the original problem has no feasible solution.
description of big m method
Description of big M method
  • Step 1

Modify the constraints so that the right-hand side of each constraint is nonnegative.

Each constraint with a negative right-hand side be multiplied through by -1. if you multiply an inequality by any negative number, the direction of the inequality is reversed.

For example,

x1+x2≥-1 into –x1-x2≤1

x1-x2≤-2 into -x1+x2≥2

description of big m method1
Description of big M method
  • Step 1’

Identify each constraint that is now an = or ≥ constraint. Prepare for step 3 – which constraint will the artificial variable to be added.

  • Step 2

Convert each inequality constraint to standard form.

For ≤ constraint i, we add a slack variable si;

For ≥ constraint i, we add an excess variable ei;

description of big m method2
Description of big M method
  • Step 3

If constraint i is a ≥ or = constraint, add an artificial variable ai, also add the sign restriction ai≥0.

  • Step 4

Let M denote a vary large positive number.

If the LP is a min problem, add (for each artificial variable) Maito the objective function.

If the LP is a max problem, add (for each artificial variable) -Maito the objective function.

description of big m method3
Description of big M method
  • Step 5

Since each artificial variable will be in the starting basis, all artificial variables must be eliminated from row 0 before beginning the simplex. This ensures that we begin with a canonical form. In choosing the entering variable, remember that M is a very large positive number.

description of big m method4
Description of big M method

For example, 4M-2 is more positive than 3M+900, and -6M-5 is more negative than -5M-40.

  • Now solve the transformed problem by the simplex.

If all artificial variables are equal to zero in the optimal solution, we have found the optimal solution to the original problem.

If any artificial variables are positive in the optimal solution, the original problem is infeasible.

example 4 continued
Example 4 (continued)

Solution

  • Step 1

Since none of the constraints has a negative right-hand side, we don’t have to multiply any constraint through by -1.

  • Step 1’

Constraints 2 and 3 will require artificial variables.

example 4 continued1
Example 4 (continued)
  • Step 2

Add a slack variable s1 to row 1 and subtract an excess variable e2 from row 2.

min z= 2x1+ 3x2

row 1: 1/2x1+1/4x2+s1 =4

row 2: x1+ 3x2 -e2=20

row 3: x1+ x2 =10

example 4 continued2
Example 4 (continued)
  • Step 3

Add an artificial variable a2 to row 2 and an artificial variable a3 to row 3.

min z= 2x1+ 3x2

row 1: 1/2x1+1/4x2+s1 =4

row 2: x1+ 3x2 -e2+a2=20

row 3: x1+ x2 +a3=10

From this tableau, the initial bfs will be s1=4,a2=20 and a3=10.

example 4 continued3
Example 4 (continued)
  • Step 4

For the min problem, we add Ma2+Ma3to the objective function.

The objective function is now

min z=2x1+3x2+Ma2+Ma3

example 4 continued4
Example 4 (continued)
  • Step 5

Row 0 is now z-2x1-3x2-Ma2-Ma3=0

To eliminate a2 and a3 from row 0, simply replace row 0 by row 0+M(row 2)+M(row 3). This yields

Row 0: z- 2x1 -3x2 -Ma2-Ma3=0

M(row 2): mx1+3Mx2-Me2+Ma2 =20M

M(row 3): Mx1 +Mx2 +Ma3=10M

New row 0: z+(2M-2)x1+(4M-3)x2-Me2 =30M

example 4 continued5
Example 4 (continued)

Initial tableau for Bevco

Since we are solving a min problem, the variable with the most positive coefficient in row 0 should enter the basis.

Since 4M-3>2M-2, variable x2 should enter the basis. The ratio test indicates that x2 should enter the basis in row 2.

example 4 continued6
Example 4 (continued)
  • Replace row 2 by 1/3(row 2). The new row 2 is

1/3x1+x2-1/3e2+1/3a2=20/3

  • Eliminate x2 from row 0 by adding –(4M-3)(new row 2) to row 0. the new row 0 is

z+(2M-3)/3x1+(M-3)/3e2+(3-4M)/3a2=(60+10M)/3

  • Using ero’s to eliminate x2 from row 1 and 3.
example 4 continued7
Example 4 (continued)

First tableau for Bevco

The ratio test indicates that x1 should enter the basis in the third row of the current tableau.

example 4 continued8
Example 4 (continued)
  • Replace row 3 by 3/2(row 3). The new row 3 is

x1+1/2e2-1/2a2+3/2a3=5

  • Eliminate x1 from row 0 by adding (3-2M)/3 (new row 3) to row 0. the new row 0 is

z-1/2e2+(1-2M)/2a2+(3-2M)/2a3=25

  • Using ero’s to eliminate x1 from row 1 and 2.
example 4 continued9
Example 4 (continued)

Since all variables in row 0 have nonpositive coefficients, this is an optimal tableau.

Since all artificial variables are equal to zero, we have found the optimal solution to the Bevco problem.

The optimal solution to the Bevco problem: z=25,x1=x2=5, s1=1/4,e2=0.

Optimal tableau for Bevco

example 4 continued10
Example 4 (continued)

Note

  • The a2 column could have been dropped after a2 left the basis (at the conclusion of the first pivot), and the a3 column could have been dropped after a3 left the basis( at the conclusion of the second pivot).
summary
summary
  • If any artificial variable is positive in the optimal Big M tableau, the original LP has no feasible solution.
  • When the Big M method is used, it is difficult to determine how large M should be. Generally, M is chosen to be at least 100 times larger than the largest coefficient in the original objective function.
