  1. FOROMIC

  2. Instituto Cultural Cabañas – Sede del evento

  3. Justificación Técnica Para el evento a realizarse en el Patio Mayor del Instituto Cultural Cabañas se colocará una tarima con un back formado por tres mamparas en distintos planos para darle juego y profundidad, con una línea gráfica alusiva al evento. La ambientación se complementará con iluminación arquitectónica.

  4. AUDIO Ubicación de Escenario

  5. ESCALERA ACCESO INGRESO ESCENARIO MAMPARAS ESCALERA ACCESO TARIMA ESCENARIO Planta Escenario

  6. 3.66 m Tarima = 80 cm altura 12.20 m AUDIO AUDIO Propuesta Escenario con Gráfico
