Presentation Transcript
perfect matching
Perfect Matching
  • Given graph G=(V,E)
  • Perfect matching is M⊆E such that each vertex incident with exactlyone edge in M
slide3

Matching History

Dense Graphs

m=n2

O(n4)

  • All are non-trivial
  • Mucha-Sankowski uses sophisticateddynamic connectivity data structures (Holm et al. ’01)to maintain “canonical partition” (Cheriyan ’97)

O(n2.5)

O(n2.38)

(n = # vertices, m = # edges)

  • All are non-trivial!
  • Mucha ’05: “[Our] algorithm is quite complicated and heavily relies on graph theoretic results and techniques. It would be nice to have a strictly algebraic, and possibly simpler, matching algorithm”.

(<2.38 is exponent for matrix multiplication)

slide4

Matching Algorithms

Dense Graphs

m=n2

  • Conceptually simple
  • Implemented in ~200 lines of MATLAB

*

*

* Randomized, but Las Vegas via [Cheriyan ’97]

linear matroid intersection
(Linear) Matroid Intersection
  • Find largest set of columns S such thatAS and BS are both linearly independent

AS

A =

BS

B =

matroid intersection
Matroid Intersection
  • Find largest set of columns S such thatAS and BS are both linearly independent
  • Why?
  • Many problems are a special case:
    • Bipartite matching
    • Arboresence (directed spanning tree), …
  • Powerful tool:
    • Bounded-Degree Sp. Tree [Goemans ’06]
slide7

Matroid Intersection History

(for matrices of size n x m)

slide8

Matroid Intersection History

  • Essentially optimal:
    • Best known alg to compute rank takes O(mn-1)
    • Computing rank reduces to matroid intersection

*

*

*

O(mn1.38)

* Assumes matroids are linear

† Randomized, and assumes matroids can berepresented over same field

generic matching algorithm
Generic Matching Algorithm

For each e E

If e is contained in a perfect matching

Add e to solution

Delete endpoints of e

Else

Delete edge e

generic matching algorithm10
Generic Matching Algorithm

Key step

For each e E

If e is contained in a perfect matching

Add e to solution

Delete endpoints of e

Else

Delete edge e

  • How can we test this?
  • Randomization and linear algebra play key role
matching outline
Matching Outline
  • Implementing Generic Algorithm
    • Tutte Matrix & Properties
    • Rabin-Vazirani Algorithm
    • Rank-1 Updates
    • Rabin-Vazirani with Rank-1 Updates
    • Our Recursive Algorithm (overview)
    • Our Recursive Algorithm (fast updates)
matching tutte matrix
Matching & Tutte Matrix
  • Let G=(V,E) be a graph
  • Define variable x{u,v} {u,v}∈E
  • Define a skew-symmetric matrix T s.t.

± x{u,v}

if {u,v}∈E

Tu,v =

0

otherwise

a

b

c

properties of tutte matrix
Properties of Tutte Matrix

Lemma [Tutte’47]: G has a perfect matchingiff T is non-singular.

Lemma [RV’89]: G[V\{u,v}] has a perfect matching iff (T-1)u,v 0.

properties of tutte matrix14
Properties of Tutte Matrix

Lemma [Tutte’47]: G has a perfect matchingiff T is non-singular.

Lemma [RV’89]: G[V\{u,v}] has a perfect matching iff (T-1)u,v 0.

u

(T-1)u,v 0

v

properties of tutte matrix15
Properties of Tutte Matrix

Lemma [Tutte’47]: G has a perfect matchingiff T is non-singular.

Lemma [RV’89]: G[V\{u,v}] has a perfect matching iff (T-1)u,v 0.

G[V\{u,v}] has

perfectmatching

(T-1)u,v 0

properties of tutte matrix16
Properties of Tutte Matrix

Lemma [Tutte’47]: G has a perfect matchingiff T is non-singular.

Lemma [RV’89]: G[V\{u,v}] has a perfect matching iff (T-1)u,v 0.

G[V\{u,v}] has

perfectmatching

(T-1)u,v 0

properties of tutte matrix17
Properties of Tutte Matrix

Lemma [Tutte’47]: G has a perfect matchingiff T is non-singular.

Lemma [RV’89]: G[V\{u,v}] has a perfect matching iff (T-1)u,v 0.

u

G[V\{u,v}] has

perfectmatching

(T-1)u,v 0

v

properties of tutte matrix18
Properties of Tutte Matrix

Lemma [Tutte’47]: G has a perfect matchingiff T is non-singular.

Lemma [RV’89]: G[V\{u,v}] has a perfect matching iff (T-1)u,v 0.

Computing T-1 very slow: Contains variables!

Lemma [Lovász’79]: These results hold w.h.p. if we randomly choose values for x{u,v}’s.

matching algorithm
Matching Algorithm

Rabin-Vazirani ’89

(Takes O(n) time)

Compute T-1

For each {u,v}  E

If T-1u,v 0

Add {u,v} to matching

Recurse on G[V\{u,v}]

  • Total time: O(n+1) time
  • Natural question: Can we recomputeT-1 quickly in each iteration?
matching outline20
Matching Outline
  • Tutte Matrix & Properties
  • Rabin-Vazirani Algorithm
  • Rank-1 Updates
  • Rabin-Vazirani with Rank-1 Updates
  • Our Recursive Algorithm (overview)
  • Our Recursive Algorithm (fast updates)
rank 1 updates
Rank-1 Updates
  • Let T be a n x n matrix
  • T + uvT is called a rank-1 update of T

+

T

u

vT

rank 1 updates22
Rank-1 Updates
  • Let T be a n x n matrix
  • T + uvT is called a rank-1 update of T
  • Computing rank-1 update takes O(n2) time

+

T

uvT

rank 1 updates23
Rank-1 Updates
  • Let T be a n x n matrix
  • T + uvT is called a rank-1 update of T
  • Claim: If you modify one entry of T,then T-1 is modified by a rank-1 update.

T =

T-1 =

rank 1 updates24
Rank-1 Updates
  • Let T be a n x n matrix
  • T + uvT is called a rank-1 update of T
  • Claim: If you modify one entry of T,then T-1 is modified by a rank-1 update.
  • Claim: If you delete O(1) rows and columns of T then T-1 is affected by O(1) rank-1 updates.

T-1 can be updated in O(n2) time

matching outline25
Matching Outline
  • Tutte Matrix & Properties
  • Rabin-Vazirani Algorithm
  • Rank-1 Updates
  • Rabin-Vazirani with Rank-1 Updates
  • Our Recursive Algorithm (overview)
  • Our Recursive Algorithm (fast updates)
rv algorithm rank 1 updates
RV Algorithm + Rank-1 Updates

Mucha-Sankowski ’04

Compute T-1

For each {u,v}  E

If T-1u,v 0

Add {u,v} to matching

Update T-1(via rank-1 updates)

Recurse on G[ V\{u,v} ]

  • Total runtime: O(n3) time
  • Can updates use Fast Matrix Multiplication?
    • Bipartite graphs: Yes
    • Non-bip. graphs: Yes, but non-trivial

[MS’04]

rv algorithm rank 1 updates27
RV Algorithm + Rank-1 Updates

Mucha-Sankowski ’04

Compute T-1

For each {u,v}  E

If T-1u,v 0

Add {u,v} to matching

Update T-1(via rank-1 updates)

Recurse on G[ V\{u,v} ]

  • Total runtime: O(n3) time
  • Can updates use Fast Matrix Multiplication?

New approach: An unusual recursion!

matching outline28
Matching Outline
  • Tutte Matrix & Properties
  • Rabin-Vazirani Algorithm
  • Rank-1 Updates
  • Rabin-Vazirani with Rank-1 Updates
  • Our Recursive Algorithm (overview)
  • Our Recursive Algorithm (fast updates)
new recursive approach
New Recursive Approach

(Here c=4 parts)

  • Partition into c parts {V1,…,Vc} (arbitrarily)
  • For each pair of parts {Va,Vb} (arbitrary order)
    • Recurse on G[Va ⋃Vb]
new recursive approach30
New Recursive Approach
  • Partition into c parts {V1,…,Vc} (arbitrarily)
  • For each pair of parts {Va,Vb} (arbitrary order)
    • Recurse on G[Va ⋃Vb]
new recursive approach31
New Recursive Approach
  • Partition into c parts {V1,…,Vc} (arbitrarily)
  • For each pair of parts {Va,Vb} (arbitrary order)
    • Recurse on G[Va ⋃Vb]
new recursive approach32
New Recursive Approach
  • Partition into c parts {V1,…,Vc} (arbitrarily)
  • For each pair of parts {Va,Vb} (arbitrary order)
    • Recurse on G[Va ⋃Vb]
  • Base case: 2 vertices
new recursive approach33
New Recursive Approach
  • Partition into c parts {V1,…,Vc} (arbitrarily)
  • For each pair of parts {Va,Vb} (arbitrary order)
    • Recurse on G[Va ⋃Vb]
  • Base case: 2 vertices {u,v}
    • If T-1u,v0, add {u,v} to matching, update T-1
recursion f a q
Recursion F.A.Q.
  • Why not just recurse on G[ Va ]?
    • Edges between parts would be missed
    • Claim: Our recursion examines every pair of vertices  examines every edge
  • Why does algorithm work?
    • It implements Rabin-Vazirani Algorithm!
  • Isn’t this horribly slow?
    • No: we’ll see recurrence next
  • Partition into c parts {V1,…,Vc} (arbitrarily)
  • For each pair of parts {Va,Vb} (arbitrary order)
    • Recurse on G[Va ⋃Vb]
  • Base case: 2 vertices {u,v}
    • If T-1u,v0, add {u,v} to matching, update T-1
final matching algorithm
Final Matching Algorithm

If base case with 2 vertices {u,v}

If T-1u,v 0, add {u,v} to matching

Else

Partition into c parts {V1,…,Vc}

For each pair {Va,Vb}

Recurse on G[Va ⋃Vb]

Apply updates to current subproblem

s = size of subproblem

final matching algorithm36
Final Matching Algorithm

If base case with 2 vertices {u,v}

If T-1u,v 0, add {u,v} to matching

Else

Partition into c parts {V1,…,Vc}

For each pair {Va,Vb}

Recurse on G[Va ⋃Vb]

Apply updates to current subproblem

s = size of subproblem

final matching algorithm37
Final Matching Algorithm

If base case with 2 vertices {u,v}

If T-1u,v 0, add {u,v} to matching

Else

Partition into c parts {V1,…,Vc}

For each pair {Va,Vb}

Recurse on G[Va ⋃Vb]

Apply updates to current subproblem

Assume:

O(s) time

s = size of subproblem

slide38

Time Analysis

  • Basic Divide-and-Conquer
    • If then
  • Since ,just choose c large enough!

c = 13 is large enough if  = 2.38

handling updates40
Handling Updates

v

v

u

u

u

u

v

v

T =

T-1 =

  • Delete vertices u and v
handling updates naively
Handling Updates (Naively)

v

v

u

u

u

u

v

v

T =

T-1 =

  • Delete vertices u and v clear rows / columns
  • Causes rank-1 updates to T-1
  • Algorithm still takes (n3) time
matching outline42
Matching Outline
  • Tutte Matrix & Properties
  • Rabin-Vazirani Algorithm
  • Rank-1 Updates
  • Rabin-Vazirani with Rank-1 Updates
  • Our Recursive Algorithm (overview)
  • Our Recursive Algorithm (fast updates)
just in time updates

Postponed

Just-in-time Updates

v

u

u

v

T-1 =

  • Don’t update entire matrix!
  • Just update parent in recursion tree
  • Updates outside of parent are postponed
postponed updates

Invert

Multiply

Postponed Updates

v

u

u

v

T-1 =

  • Accumulate batches of updates
  • Claim: New updates can be applied with matrix multiplication and inversion
final matching algorithm45
Final Matching Algorithm

If base case with 2 vertices {u,v}

If T-1u,v 0, add {u,v} to matching

Else

Partition into c parts {V1,…,Vc}

For each pair {Va,Vb}

Recurse on G[Va ⋃Vb]

Apply updates to current subproblem

Invariant: Before / after child subproblem,parent’s submatrix is completely updated

 in every base case, T-1u,v is up-to-date!

slide46

Graph G

children

Just apply postponed updates

All edges chosen in base cases

Only take edges that can be extended to a perfect matching in the whole graph.

This decision is possible because invariant ensures that T-1u,v is up-to-date.

matching summary
Matching Summary
  • Can compute a perfect matching inO(n) = O(n2.38) time
  • Algorithm uses only simple randomization, linear algebra and divide-and-conquer
  • Easy to implement
  • Extensions for: (by existing techniques)
    • maximummatchings
    • Las Vegas
more extensions

J

A

Matroid Intersection

O(mn-1) algorithm

J

x3

x4

BT

x5

x6

x7

x8

More Extensions
  • Same philosophy applies to manymatching-like problems
    • Design matrix capturing problem
    • Design algorithm to test if element in OPT
    • Design method to efficiently do updates
  • Design “algebraic structure” capturing problem
more extensions49
More Extensions
  • Same philosophy applies to manymatching-like problems
    • Design matrix capturing problem
  • Design “algebraic structure” capturing problem

Bipartite Matroid Matching

& Basic Path-Matching

O(n) algorithm

open problems
Open Problems
  • Fast, deterministic methods to choosevalues for indeterminates?
    • Implications for Matching in NC
  • Scaling algorithms for weighted problems?
  • O(n2) algorithms for matching bycompletely different techniques?
    • e.g., via Karger-Levine randomized max flow
