Presentation Transcript
slide2

The Company

Sonakshi Industries is a JAY Group Company , manufacturer of Hard Washers, Circlips, Spring Washers, Sheet Metal Parts, Auto Electrical Switches, Cock Assy. Fuel & Cap Assy. Noise suppressor

slide3

The Company

SONAKSHI INDUSTRIES

Establishment Year - 2004

Sec.-37, Gurgaon –HR.

slide7

Quality System

Sonakshi Industries is ISO 9001 : 2008 & Direct On Line Supplier (for M/S HHML) certified Company.

Quality Policy

Sonakshi Industries is committed to enhance satisfaction level of our customer by manufacturing electrical & sheet metal , spring steel components of consistence quality and supplying quantity at right time.

We strive to continually improve the effectiveness of Quality Management System.

slide8

Our Products

  • Hard Washers & Sheet Metal Parts

CUSTOMERS

HERO HONDA MOTORS LTD.

MUSASHI AUTO PARTS INDIA LTD.

MAHINDRA 2 WHEELERS LTD

LIFE LONG INDIA LTD.

TATA MOTORS LTD.

SUPPLIED QTY. – 28 LACS / MONTH (APPROX.)

slide10

Manufacturing Capabilities

We have well equipped infrastructure to manufacture and produce wide range of products.

  • High Pressure Die Casting Machines
  • Vertical & Horizontal Injection Moulding Machines
  • Power Presses
  • Rotary Table Grinding Machine
  • Automatic Aus Tempered Heat Treatment Plant
  • Nitrogen generation Plant
  • Special Purpose Machines for Spring washers
slide11

Design & Development Capabilities

We are capable of designing & development of any type/size of product within our range of product on desired Quality, Cost & Delivery.

  • IDEAS -9 & 11 2 NOS
  • UGS NX 6.0 1 NOS
  • AUTOCAD 2004 & 2007 5 NOS
slide12

Tool Room Facility

We are capable of In house Tool Room facility which is equipped with latest machines

Automatic CNC Milling M/c

Make : Maximart (Taiwan)

slide13

Automatic Wire Cut M/c

Make : Electronica

slide14

Automatic EDM M/c

Make : AGIE Charmilles (Singapore)

slide15

HEAT TREATMENT PLANT

We have one of the best in house heat treatment plant (Continuous Mesh Belt Austempring furnace) with latest quality equipments.

WASHER DIVISION

3 stage

1 stage –material heating

Zone temp.-860 ± 5 ºC

Z1,z2,z3,z4

18 min to 35 min

Total length- 3500 mm

conveyer speed 1150

2 stage- salt conveyer – 1150

Quenching

Temp.-355 ± 5 ºC

Time- 15~30 min

Length-5000mm

Speed- 100 mm/min

3 stage- washing

Hot water

Cold water

Total cycle time- max 2 hours ,min 1 ½ hour

slide16

NITROGEN PLANT

We have nitrogen plant for generating the specific nitrogen (oxygen level Zero PPM & below -60 degree dew point) for developing proper inert atmosphere in furnace chamber .

slide17

POWER PRESS DIVISION

  • POWER PRESS 50 TON 1 NOS
  • POWER PRESS 30 TON 3 NOS
  • POWER PRESS 20 TON 5 NOS
  • POWER PRESS 10 TON 30NOS
slide18

GRINDING

We have Rotary Table Grinding Machine to maintain highly required surface finish and flatness

  • BARRELING

BARRELING M/C 4 NOS

slide19

STORAGE

  • RAW MATERIAL STORE
  • PRESS TOOLS
slide20

Inspection, Testing & Lab Facilities

ROCKWELL HARDNESS TESTER

METLURGICAL MICRO SCOPE (100 MAG.)

TENSILE TESTER (500 KG)

MEGGER - 500V D.C.

M. VOLT TESTER

slide21

SHOWER CHAMBER

HOT CHAMBER – 0 ~ 310°C

DUST SPRAY CHAMBER

MUFFLE FURANCE

(900 °C MAX.)

SALT SPRAY CHAMBER

HOT AIR OVEN

(300 °C MAX.)

our additional central reliability section
OUR ADDITIONAL CENTRAL RELIABILITY SECTION

1.Dust Spray Chamber

2.Water spray Chamber

3.Environmental Chamber

4.Vibration Machine

5.Salt Spray Chamber

6.Humidity Chamber

7.Hardness Tester

slide23

8.Endurance Testing in following conditions:-

a. Cold condition(-80˚C)

b.Hot Condition(150 ˚C)

c.Ambient condition

9.Torque Testing

10.Spring Testing

11.Chemical Testing

slide24

MOULDING DIVISION

  • MOULDING M/C (WINDSOR) 130 TON 1 NOS
  • MOULDING M/C (HAITEN) 90 TON 1 NOS
  • MOULDING M/C (WINDSOR) 80 TON 3 NOS
  • MOULDING M/C 50 TON 1 NOS
  • BAKELITE INJ. MOULDING 50 TON 2NOS
  • MOULDING M/C (ARICO) 20 TON 4 NOS
  • MOULDING M/C (JOY) 15 TON 2 NOS
  • MOULDING M/C (JOY) 10 TON 2 NOS

CASTING DIVISION

  • AUTOMATIC CASTING M/C 80 TON 1NOS
  • AUTOMATIC CASTING M/C 50 TON 2 NOS
slide25

Switches (Hero Honda Motors Ltd.)

Super Splendor

Splendor +

Passion Pro

Glamour

CD -100

Splendor

Passion +

CBZ

Hunk

Karizma

Street

slide26

Street

CBZ

Hunk

Karizma

Sw. Assy. Rear Stop

Sw. Assy. Front Stop

All Models for Disc Type (HHML & HMSI)

CBZ

Hunk

Karizma

slide27

Sw.Comp.Front Lever ( Clutch Switch)

All models in Self Start

  • Cap Assy. Noise Supp.

Splendor+

Passion+

Super Splendor

Splendor – NXG

CDN- DLX

Glamour

CBZ

Hunk

slide28

Cock Assy. Fuel (Hero Honda Motors Ltd.)

CD-100

SPLENDOR +

PASSION +

SPLENDOR-NXG

PASSION –PRO

GLAMOUR

  • Cock Assy. Fuel (Honda Power Products Ltd.)

ESK – 2000

ESK – 2800

EBK – 1000

GK - 200
