bring pen and touch input to your metro style apps with ink
PLAT-192C

Bring pen and touch input to your Metro style apps with ink

Annie Chowdhry

Program Manager

Microsoft Corporation

Jay Pittman

Developer

Microsoft Corporation

metro style apps in windows 8 are so much better with ink
Metro style apps in Windows 8 are so much better with Ink!

Code for touch, get mouse and pen for free

agenda
Agenda
  • How Inking Works
  • Inking API architecture
  • Demos
    • Creating and rendering Ink to a canvas
    • Managing Ink from pen and touch input
    • Converting Ink to text (handwriting recognition)

You’ll leave with examples of how to

    • Write an Ink-enabled Metro style app in Windows 8
how inking works

Recognize

How Inking works

Capture and Manipulate

HI!

Hi!

Hit

Hid

hi!

HI !

Reco API returns interpreted combination of strokes from recognizer (rich recognition results)

Pointer API captures pen motion, passing coordinates to Ink API

X,Y….Xn,Yn

HI !

l

Optional

Ink API helps render and stores motion as ink. Ink manipulation.

Ink API groups strokes and passes them to recognizer

inking api architecture e xecution flow
Inking API architecture – execution flow

Render

Metro style app

Input

Obtains Raw Dataposition, id and pressure using MSPointer(JavaScript / ICoreWindow(XAML)

and passes this to stroke builder: Begin/Append/End Stroke methods

Windows.UI.Input.Inkingstroke builder,rendering helper,ink manipulation,handwriting recognition with rich recognition results with alernates,clipboard,serialization

Renders Strokes

render using rendering helper method:InkRenderingSegmentdoes not return packets but stroke rendering segments such as Bezier curves

slide7

Code Snippets

  • Register for events
  • ProcessPointerDown
  • ProcessPointerUpdate
  • ProcessPointerUp
  • Render everything
slide8

Register for events

html:

    <canvas id="myCanvas" width="1000" height="1000"></canvas>

js:

var canvas = document.getElementById("myCanvas");

var context = canvas.getContext("2d");

canvas.addEventListener("MSPointerDown", handlePointerDown, false);

canvas.addEventListener("MSPointerMove", handlePointerMove, false);

canvas.addEventListener("MSPointerUp", handlePointerUp, false);

varinkManager = new Windows.UI.Input.Inking.InkManager();

slide9

ProcessPointerDown

functionhandlePointerDown(evt)

{

if ((evt.pointerType === 3) || ((evt.pointerType === 4) && (evt.button === 1)))

{

evt.preventManipulation();

inkManager.processPointerDown(evt.currentPoint);

context.beginPath();

context.moveTo(evt.currentPoint.rawPosition.x, evt.currentPoint.rawPosition.y);

}

else if ((evt.pointerType === 2) || ((evt.pointerType === 4) && (evt.button === 2)))

{

// Handle touch down

}

}

slide10

ProcessPointerUpdate

functionhandlePointerMove(evt)

{

if ((evt.pointerType === 3) || ((evt.pointerType === 4) && (evt.button === 1)))

{

evt.preventManipulation();

inkManager.processPointerUpdate(evt.currentPoint);

context.lineTo(evt.currentPoint.rawPosition.x, evt.currentPoint.rawPosition.y);

context.stroke();

    }

else if ((evt.pointerType === 2) || ((evt.pointerType === 4) && (evt.button === 2)))

{

// Handle touch move

}

}

slide11

ProcessPointerUp

functionhandlePointerUp(evt)

{

if ((evt.pointerType === 3) || ((evt.pointerType === 4) && (evt.button === 1)))

{

evt.preventManipulation();

inkManager.processPointerUp(evt.currentPoint);

context.lineTo(evt.currentPoint.rawPosition.x, evt.currentPoint.rawPosition.y);

context.stroke();

context.closePath();

}

else if ((evt.pointerType === 2) || ((evt.pointerType === 4) && (evt.button === 2)))

{ // Handle touch up

}

renderAllStrokes();

}

slide12

Render everything

functionrenderAllStrokes()

{

inkManager.getStrokes().forEach(function (stroke)

{var first = true;

stroke.getRenderingSegments().forEach(function (segment)

{ if (first)

            {

context.moveTo(segment.position.x, segment.position.y);

                first = false;

            }

else

{context.bezierCurveTo(segment.bezierControlPoint1.x, segment.bezierControlPoint1.y,

segment.bezierControlPoint2.x, segment.bezierControlPoint2.y,

segment.position.x, segment.position.y);

            }

        });

    });

context.stroke();

context.closePath();

}

slide14

Code Snippets

  • Select strokes using Touch
  • Moving selected strokes
  • Selecting and Erasing modes
  • Deleting selected strokes
slide15

Selecting individual strokes (using touch)

functionhandlePointerDown(evt)

{. . .

else if ((evt.pointerType === 2) || ((evt.pointerType === 4) && (evt.button === 2)))

{ var hit = false;

inkManager.getRecognitionResults().forEach(function (result)

{ if (inRect(evt.offsetX, evt.offsetY, result.boundingRect))

{result.getStrokes().forEach(function (stroke)

{

stroke.selected= true;

hit = true;

});

}

});

if (hit)

{ evt.preventManipulation();

prevX= evt.offsetX; prevY= evt.offsetY;

}

}

}

slide16

Moving selected strokes

functionhandlePointerMove(evt)

{

if ((evt.pointerType === 3) || ((evt.pointerType === 4) && (evt.button === 1)))

{

// Handle pen move

    }

else if ((evt.pointerType === 2) || ((evt.pointerType === 4) && (evt.button === 2)))

{

evt.preventManipulation();

var shift = {x: evt.offsetX - prevX, y: evt.offsetY - prevY};

inkManager.moveSelected(shift);

renderAllStrokes();

prevX = evt.offsetX;

prevY= evt.offsetY;

}

}

slide17

Selecting mode (Lasso) and erasing mode

inkManager.mode = Windows.UI.Input.Inking.InkManipulationMode.selecting;

inkManager.mode = Windows.UI.Input.Inking.InkManipulationMode.erasing;

inkManager.mode = Windows.UI.Input.Inking.InkManipulationMode.inking;

// These 3 modes all use the same down/move/up handlers

inkManager.deleteSelected();

slide18
demo

Ink Pad App Converting Ink to text (handwriting recognition) and searching

slide19

Code Snippets

  • Recognition
  • Find and select all strokes
slide20

Recognition

function recognize()

{

inkManager.recognizeAsync(Windows.UI.Input.Inking.InkRecognitionTarget.all).then(

function(results)

    {

inkManager.updateRecognitionResults(results);

    });

}

slide21

Find and select all strokes

functionrecognizeThenFindAndSelect(target)

{

inkManager.recognizeAsync(Windows.UI.Input.Inking.InkRecognitionTarget.all).then(function (results)

{

results.forEach(function (result)

{

result.getTextCandidates().forEach(function(candidate)

{

if (target.toLowerCase() === candidate.toLowerCase())

{

result.getStrokes().forEach(function (stroke)

{

stroke.selected = true;

                    });

                }

            });

        });

    });

}

slide22

The new Ink API has been optimized to enable you with easier ramp-up while still covering the most important Metro style app scenarios.

call to action
Call to action
  • Capture Ink
  • Manipulate Ink
  • Recognize Ink

Create Ink enabled Metro style apps

related sessions
Related sessions
  • [APP-185T] Make great Metro style apps that are touch-optimized using HTML5
  • [APP-186T] Build advanced touch apps in Windows 8
  • [APP-395T] Designing Metro style: principles and personality
  • [APP-740T] Metro style apps using HTML5 from start to finish
further reading and documentation
Further reading and documentation
  • Quickstart: Capturing and displaying ink
    • Metro style apps > Learn > Developing basic Metro style apps > Developing basic apps (JavaScript) > Responding to user input
  • Ink App sample in Windows SDK for Metro style apps
  • Contact:
    • For questions, please visit the forums on the Windows Dev Center at http://forums.dev.windows.com
    • For best response, please include the Build Session # in the title of your post
feedback and q uestions http forums dev windows com session f eedback http bldw in sessionfeedback
thank you

Feedback and questions http://forums.dev.windows.com

Session feedbackhttp://bldw.in/SessionFeedback

slide27

© 2011 Microsoft Corporation. All rights reserved. Microsoft, Windows, Windows Vista and other product names are or may be registered trademarks and/or trademarks in the U.S. and/or other countries.

The information herein is for informational purposes only and represents the current view of Microsoft Corporation as of the date of this presentation. Because Microsoft must respond to changing market conditions, it should not be interpreted to be a commitment on the part of Microsoft, and Microsoft cannot guarantee the accuracy of any information provided after the date of this presentation. MICROSOFT MAKES NO WARRANTIES, EXPRESS, IMPLIED OR STATUTORY, AS TO THE INFORMATION IN THIS PRESENTATION.

inking api architecture binary perspective

Metro style app built for Windows using JavaScript / C++ or C# runtime environment

Inking API Architecture – Binary perspective

Metro style app

obtains position, id, & pressure from MSPointer (JavaScript)

/ ICoreWindow (C++/C#)

manages ink with calls to Windows.UI.Input.Inking

renders using HTML5 Canvas (JavaScript), D2D and DUI

Windows runtime

Windows.UI.Input.Inkingnamespace for ink management

Windows.Graphicsnamespace for rendering

IE events for JavaScript / Windows.Foundationnamespace for ICoreWindow (C++ / C#)

slide29

Save

functionsaveToFile()

{

var picker = new Windows.Storage.Pickers.FileSavePicker();

picker.pickSingleFileAsync().then(function (file)

{

file.openAsync(Windows.Storage.FileAccessMode.readWrite).then(function (stream)

{

varoutputStream = fileStream.getOutputStreamAt(0);

inkManager.saveAsync(outputStream).then(function()

            {

outputStream.flushAsync().then(function()

{

                });

            });

        });

    });

}

slide30

Load

functionloadFromFile()

{

var picker = new Windows.Storage.Pickers.FileOpenPicker();

picker.pickSingleFileAsync().then(function (file)

{

file.openAsync(Windows.Storage.FileAccessMode.read).then(function (stream)

{

varinputStream = fileStream.getInputStreamAt(0);

inkManager.Load(inputStream);

renderAllStrokes();

        });

    });

}

slide31

Copy and Paste

functionpasteFromClipboard(point)

{

inkManager.pasteFromClipboard(point);

}

functioncopySelectedToClipboard()

{

inkManager.copySelectedToClipboard();

}

slide32

Select with Recent Recognition

functionrecognizeRecentThenFindAndSelect(target)

{

inkManager.recognizeAsync(Windows.UI.Input.Inking.InkRecognitionTarget.recent).then(function (results)

    {

inkManager.updateRecognitionResults(results);

inkManager.getRecognitionResults().forEach(function (result)

        {

result.getTextCandidates().forEach(function (candidate)            {

if (target.toLowerCase() === candidate. toLowerCase())

{

result.getStrokes().forEach(function (stroke)

{

stroke.selected = true;

});

                }

            });

});

    });

}
