    1. Operating Systems Networking for Home and Small Businesses – Chapter 2

    2. Objectives • Describe the purpose of an OS and identify common operating systems available. • Perform an actual or simulated installation of an operating system and prepare the computer to participate on the network. • Maintain the operating system.

    3. Purpose of an Operating System • Describe the purpose of an operating system • User Interface: CLI vs. GUI • Connects the user to hardware • CLI: Command Line Interface • GUI: Graphical User Interface • Use of resources: OS vs. NOS • OS provides functionality for one user at a time. • NOS provides resources to multiple users simultaneously

    4. Purpose of an Operating System • Identify common operating systems and describe license requirements

    5. Purpose of an Operating System • Operating System Requirements • Go to the Operating system vendors website • Check hardware compatibility www.microsoft.com/hcl

    6. Operating system considerations: • Security – is this operating system secure? • Support – who will support it? • Politics – do managers support this effort? • Cost – is this within budget? • Availability – is this product readily available? • Resources – are the resources necessary to deploy it available? • Platform – is this the right technology for the company? • Use – will the users be able to use this product?

    7. Installation of an Operating System • Installation methods: • Virtualization (VMWare, Virtual PC) • Clean Install (Clean hard drive) • Multi-boot (Multiple OS, Multiple Partitions) • Upgrade (Install new OS over existing OS)

    8. Installation of an Operating System • Pre-Installation Checklist: • 1. Verify that all hardware is certified to work with the OS. • 2. Verify that the hardware resources meet or exceed the published minimum requirements. • 3. Confirm that the appropriate installation medium (CD/DVD) is available. • 4. If the OS is to be installed on a system that already contains data: (a) Use system diagnostic tools and utilities to ensure the current OS installation is in good condition, free of malicious or damaging files and codes; (b) Complete a full backup of all important files. • 5. If performing a clean-install, verify that all application software is available for installation.

    9. Prepare your computer to participate in the network

    10. Configuring a Computer for the Network • To participate in a network a computer must have a Network Interface Card (NIC) • Each computer must be configured to participate in the network: • IP address - identifies the computer on the network. • Subnet mask - is used to identify the network on which the computer is connected. • Default gateway - identifies the device that the computer uses to access the Internet or another network. • A computer can be configured manually or dynamically (DHCP)

    11. Computer Naming • A computer name should be descriptive so that it can be easily identified on the network • A computer name must be unique on each local network • A computer description can be given to provide additional information • Computer names must be unique and should be consistent • IP addresses are like phone numbers on the network • IP addresses must be unique • A computer may have multiple NICs and each NIC may have more than one IP address – each address must be unique

    12. Operating System Maintenance • A patch fixes a problem or enhances functionality and are provided by the application or OS vendor to fix a vulnerability • Patches should be test thoroughly with business critical software to ensure that they function appropriately before they are applied in a production environment. • Automatic Installation • Prompt for Permission • Manual

    13. Operating System Maintenance • Identify sources of Applications patches

    14. Summary • An operating system is the most important software in a PC.  It is responsible for making all of the components and software applications work together. • An OS is installed in a disk partition. • To participate in a network, a computer requires an IP address, subnet mask and default gateway. • An OS must be kept up-to-date with the latest revisions, or patches. • Before installing a wireless network an installation plan should be created.
