  1. Depicting Electrons ELECTRON-DOT NOTATION

  2. Atoms consist of inner and outer electrons. • Only the outermost electrons in an atom can participate in bonding. • Called valence electrons. • The inner electrons do not participate in bonding. • Called non-bonding electrons. Inner & Outer Electrons

  3. Each group on the periodic table has a set number of valence electrons. • Group 1 elements have 1 valence electron. • Group 2 elements have 2 valence electrons. • Group 13 elements have 3 valence electrons. • Group 14 elements have 4 valence electrons. • Group 15 elements have 5 valence electrons. • Group 16 elements have 6 valence electrons. • Group 17 elements have 7 valence electrons. • Group 18 elements have 8 valence electrons. Determining Number of Valence Electrons

  4. Depiction of the valence electrons of an atom. • Valence electrons are represented as dots surrounding the elemental symbol. • Fill in the blank periodic table with electron-dot notations. USE PENCIL. Electron-Dot Notation

  5. Ions form when atoms gain or lose electrons. • Cations form when electrons are lost. • Positively charged. • Charge is determined by number of electrons lost. • Anions form when electrons are gained. • Negatively charged. • Charge is determined by number of electrons gained. • Octet rule: atoms will gain or lose electrons so that they have 8 valence electrons. Ions

  6. Atoms with fewer than four valence electrons will lose electrons to form cations. • A group 1 atom will lose 1 electron to form a 1+cation. • A group 2 atom will lose 2 electrons to form a 2+cation. • A group 13 atom will lose 3 electrons to form a 3+cation. • Atoms with more than four valence electrons will gain electrons to form anions. • A group 15 atom will gain 3 electrons to form a 3- anion. • A group 16 atom will gain 2 electrons to form a 2- anion. • A group 17 atom will gain 1 electron to form a 1- anion. Predicting Ions

  7. Certain groups do not form ions. • Group 14 (carbon group). • Group 18 (noble gases). Predicting Ions

  8. Cation formation: • Remove the number of electrons appropriate for the group. • Charge is positive and equal to the number of electrons lost. • Anion formation: • Add the number of electrons appropriate for the group. • Charge is negative and equal to the number of electrons gained. • Edit your periodic table to show ion formation by removing or adding electrons to the electron-dot notation. Be sure to indicate the charge of the ions. Electron-Dot Notation of Ions
