windows filtering platform and winsock kernel next generation kernel networking apis

Windows Filtering Platform And Winsock Kernel: Next-Generation Kernel Networking APIs

Madhurima Pawar

Program Manager

Windows Networking

mpawar @ microsoft.com

Microsoft Corporation

Eric Stenson

Development LeadWindows Networking

ericsten @ microsoft.com

Microsoft Corporation

session outline
Session Outline
  • Windows Filtering Platform (WFP)
    • WFP Introduction
    • WFP Basics
    • WFP Architecture
    • WFP Configuration
    • WFP Callout Drivers
    • Case Study: Data logging callout driver
  • Winsock Kernel (WSK)
    • Why WSK?
    • TDI Shortcomings
    • WSK Benefits
    • WSK Versus TDI Scenario Comparison
  • Questions
session goals
Session Goals
  • Attendees should leave this session with the following
    • An introduction to Windows Firewall Platform (WFP)
    • An introduction to Winsock Kernel (WSK)
    • Knowledge of where to find resources for WFP and WSK
wfp introduction
WFP Introduction
  • What is WFP?
    • Windows Filtering Platform exposes a set of Application Programming Interfaces (APIs) to permit, block, modify and/or secure inbound and outbound traffic
    • APIs are categorized as
      • Management APIs
        • Filter management, provider management, callout management
      • IKE (Keying Module) Management APIs
      • Internet Protocol Security (IPsec) Management APIs
    • APIs are for user mode as well as kernel-mode components
    • APIs can be used for
      • Firewall
      • Antivirus
      • Parental control
      • Diagnostics
wfp basics
WFP Basics
  • Why WFP?
    • Easier and cleaner interface to the network stack
      • Filter hooks and firewall hooks are no longer supported
    • Reduces and/or eliminates the use of Network Driver Interface Specification (NDIS) or LSP
      • Callout drivers allow content inspection and data modification
    • Provides rich set of filters in user and kernel mode
    • Allows multiple providers to co-exist on Windows Codename Longhorn
    • Supports both IPv4 and IPv6
    • Allows integration of IPsec and firewall policies
    • Improves diagnostics and traceability
    • Reduces firewall and anti-virus crashes
      • 12% of all OS crashes
wfp architecture
WFP Architecture

Provided by:

Microsoft

LH Firewall

Firewall or other filter applications

ISV

IHV

WFP APIs

OEM

Base Filtering Engine

user

kernel

TDI,

WSK

ALE

Filtering Engine

Anti-virus

Stream

Layer

Parental

control

TCP, UDP

Transport Layer

Callout APIs

Packetprocessing path

Callout modules

Forwarding

Layer

IDS callout

Network

Layer

NAT

NDIS

Layer

wfp configuration
WFP Configuration
  • WFP can be configured using
    • User mode components (applications and services) for filtering operations
    • Kernel mode components (callout drivers) for deep packet inspection and modification
  • User mode components can configure WFP by plumbing appropriate filters
    • Filters can be added by calling FwpmFilterAdd0 function
    • Filters can specify either permit or block action
    • Filters can be plumbed at different layers in the stack
  • Traffic can be secured by invoking IPsec callout
  • Secure Socket APIs for socket level security
callout drivers
Callout Drivers
  • Callout drivers can perform the following tasks
    • Deep inspection
    • Packet modification
    • Stream modification
    • Data logging
  • Callout drivers can be hooked at different layers in the stack, namely
    • Network layer
    • Forwarding layer
    • Transport layer
    • Stream layer
    • ALE layer
case study data logging callout
Case Study: Data Logging Callout
  • Initializing a callout driver:
    • Specify an Unload function in its driver entry
    • Open a handle to the filter engine
    • Add callout functions to the filter engine using FwpmCalloutAdd0
    • Close the handle to the filter engine using FwpmEngineClose0
case study data logging callout11
Case Study: Data Logging Callout
  • Callout implements the following function
    • Notifyfn() is called by the Filtering Engine when a filter that specifies the callout driver’s callout function is added or deleted
    • Classifyfn() is called by the Filtering Engine when a filter that specifies the callout driver’s callout
    • Flowdeletefn() is called by the Filtering Engine to notify the callout driver when the flow being processed by it is terminated
case study data logging callout12
Case Study: Data Logging Callout
  • Initialize the callout driver in its Driver Entry function

VOID  Unload(    IN PDRIVER_OBJECT DriverObject    );NTSTATUS  DriverEntry(    IN PDRIVER_OBJECT DriverObject,    IN PUNICODE_STRING RegistryPath    ){  ...  // Specify the callout driver's Unload function  DriverObject->DriverUnload = Unload;  ...}

case study data logging callout13
Case Study: Data Logging Callout
  • Open handle to filtering Engine

FWP_ENGINE_HANDLE engineHandle;NTSTATUS status;// Open a handle to the filter enginestatus =  FwpmEngineOpen0(    NULL,              // The filter engine on the local system    RPC_C_AUTHN_WINNT, // Use the Windows authentication service    NULL,              // Use the calling thread's credentials    NULL,              // There are no session-specific parameters    &engineHandle      // Pointer to a variable to receive the handle    );

case study data logging callout14
Case Study: Data Logging Callout
  • Notifyfn()

// notifyFn callout functionNTSTATUS NTAPI  NotifyFn(    IN FWP_NOTIFY_TYPE  notifyType,    IN const GUID  *filterKey,    IN const FWPS_FILTER0  *filter    ){  // Switch on the type of notification  switch(notifyType) {    // A filter is being added to the filter engine    case FWP_NOTIFY_ADD:      // Allocate the filter context structure      context =        (PFILTER_CONTEXT)ExAllocatePoolWithTag(          NonPagedPool,          sizeof(FILTER_CONTEXT),          FILTER_CONTEXT_POOL_TAG);

case study data logging callout15
Case Study: Data Logging Callout
  • Notifyfn()

// Check the result of the memory allocation      if (context == NULL) { // Return error  return STATUS_INSUFFICIENT_RESOURCES;   }  // Initialize the filter context structure  ...  // Associate the filter context structure with the filter  filter->context = (UINT64)context;  // Increment the filter count  InterlockedIncrement(&filterCount);      break;  }  return STATUS_SUCCESS;}

case study data logging callout16
Case Study: Data Logging Callout
  • Classifyfn()

// classifyFn callout function VOID NTAPI  ClassifyFn(    IN const FWPS_INCOMING_VALUES0  *inFixedValues,    IN const FWPS_INCOMING_METADATA_VALUES0  *inMetaValues,    IN OUT VOID  *layerData,    IN const FWPS_FILTER0  *filter,    IN UINT64  flowContext,    OUT FWP_ACTION_TYPE  *action,    OUT UINT64  *outContext    ){  UINT32 index;  // Increment the total count of discarded packets  InterlockedIncrement(&TotalDiscardCount);  // Loop through the metadata values  for (index = 0; index < inMetaValues->numMetadataValues; index++) {

case study data logging callout17
Case Study: Data Logging Callout
  • Classifyfn()

 // Check if this value is a general discard reason    if (inMetaValues->metadataValues[index].fieldId ==        FWPS_METADATA_FIELD_GENERAL_DISCARD) {      // Check if discarded by a filter      if (inMetaValues->metadataValues[index].value ==          FwpDiscardFirewallPolicy) {        // Increment the count of packets discarded by a filter        InterlockedIncrement(&FilterDiscardCount);      }      // Break out of the for loop      break;    }  }  // Take no action on the data  *action = FWP_ACTION_CONTINUE;}

wsk goals
WSK Goals
  • Simple and consistent API
  • Efficient and scalable
  • Support serviceability of networking components
  • Expose full power of the new transport stack
  • Easy to port to for existing TDI client applications
  • General Sockets programming concepts
    • Similar to user-mode Sockets
    • NOT targeted to be API-compatible with User Mode Winsock
transport driver interface tdi shortcomings
Transport Driver Interface (TDI) Shortcomings
  • TDI Deeply tied to the Windows I/O Manager and Object Manager
    • All TDI Objects are File Objects
      • TDI Objects must be created at PASSIVE_LEVEL (IRQL)
      • However, Transport may indicate new connections at DISPATCH_LEVEL
      •  TDI Client must pre-create and manage a cache of Connection Objects (CO)
    • TDI Clients must use Windows Object Manager APIs to control TDI Objects
      •  TDI Clients exposed to unnecessary complexity
      •  TDI Clients use memory for File Objects for each Address Object (AO) and Connection Object (CO)
tdi shortcomings
TDI Shortcomings
  • Servicing TDI Providers requires reboot
    • TDI Providers have no way of detaching from TDI clients
  • Each TDI Provider has unique mechanism for surfacing Options
    • TDI Clients must have specific knowledge about the underlying TDI Transport Provider
  • Discovery of Transports is difficult
    • TDI Clients specify bindings at install time and receive transport-to-NIC binding notifications
      • Or: TDI Clients must use hard-coded device names (e.g., \Device\TCP, \Device\UDP, etc.)
tdi overview
TDI Overview

Provided by:

Microsoft

Kernel Mode Networking Client Apps

ISV

IHV

I/O Manager

TDI.SYS

Transport

(TCP/IPv4)

Transport (TCP/IPv6)

Transport

(3rd Party)

\Device\TCP

\Device\UDP

\Device\RAW

\Device\TCP6

\Device\UDP6

\Device\RAW6

\Device\<proto>

<proto> – Determined by 3rd Party Transport Implementers

windows codenamed longhorn stack overview
Windows Codenamed “Longhorn” Stack Overview

Winsock 1.0/2.x

WFP

WS2_32.DLL

Winsock

Catalog

SPI

LSP #1

SPI

SPI

LSP #2

MSWSOCK.DLL

User

Kernel

HTTP.SYS

WSK

TDI

NetBT

3rd Party

TDX

AFD

WSK

Private

Next Generation

TCP/IP Stack

LSP = Winsock Layered Service Provider

wsk benefits
WSK Benefits
  • No file objects!
    • Can create Sockets at DISPATCH_LEVEL
  • Simplified, separate API
    • Create Sockets by specifying {ST, AF, P}
      • No more static Device string and cumbersome PFILE_FULL_EA_INFORMATION!
    • Connect using SOCKADDR
      • No more cumbersome TA_ADDRESS cracking!
wsk benefits25
WSK Benefits
  • No need to attach directly to Transport Device
    • WSK handles Dynamic Transport Discovery and Status Notifications via Network Module Registration (NMR)
    • Improved Serviceability!
  • Only element from WDM is use of IRPs for completion mechanism
    • Insulated from many I/O Manager APIs!
    • Still receive benefits
      • Driver Verifier
      • Existing KD extensions
      • I/O request tracking
      • Ease of porting existing TDI clients to WSK
  • No need to attach directly to Transport Device
    • WSK handles Dynamic Transport Discovery and Status Notifications via Network Module Registration (NMR)
    • Improved Serviceability!
  • Only element from WDM is use of IRPs for completion mechanism
    • Insulated from many I/O Manager APIs!
    • Still receive benefits
      • Driver Verifier
      • Existing kernel debugger extensions
      • I/O request tracking
      • Ease of porting existing TDI clients to WSK
wsk overview

Provided by:

WSK Overview

Microsoft

ISV

IHV

Kernel Mode Networking Client Apps

I/O Manager

Network

Module

Registration

(NMR)

Winsock Kernel

(WSK)

Transport

(TCP/IPv4)

Transport (TCP/IPv6)

Transport

(3rd Party)

...

wsk scenarios create connection tdi
WSK Scenarios: Create Connection (TDI)

//

// Create AO

//

Build FILE_FULL_EA_INFORMATION (TA_ADDRESS)

InitializeObjectAttributes (TDI Device Name)

IoCreateFile(

&AOHandle,

MAXIMUM_ALLOWED, // DesiredAccess

&object_attributes,

&io_status_block,

0, // AllocationSize

0, // FileAttributes

0, // ShareAccess,

FILE_CREATE,

0, // CreateOptions.

ea_buffer,

ea_length,

CreateFileTypeNone,

NULL, // ExtraCreateParameters

create_options

);

//

// Create CO

//

Build FILE_FULL_EA_INFORMATION (TdiConnectionContext)

InitializeObjectAttributes (TDI Device Name)

IoCreateFile(

&COHandle,

MAXIMUM_ALLOWED, // DesiredAccess

&object_attributes,

&io_status_block,

0, // AllocationSize

0, // FileAttributes

0, // ShareAccess,

FILE_CREATE,

0, // CreateOptions.

ea_buffer,

ea_length,

CreateFileTypeNone,

NULL, // ExtraCreateParameters

create_options

);

//

// Associate CO to AO

//

Allocate IRP

Get File and Device Object pointers from CO_FileHandle

TdiBuildAssociateAddress(CO, AOHandle, CompletionRtn/Ctx)

IoCallDriver(IRP)

//

// Issue connect when AssociateAddress request is completed.

//

Allocate IRP or reuse IRP from previous step

TdiBuildConnect(CO, TA_ADDRESS, CompletionRtn/Ctx)

IoCallDriver(IRP)

wsk scenarios create connection wsk
WSK Scenarios: Create Connection (WSK)

//

// Create and connect a WSK socket in one call

//

Allocate IRP

IoSetCompletionRoutine(IRP, CompletionRtn/Ctx);

WskProviderDispatch->WskSocketConnect(

WskClient,

SOCK_STREAM,

IPPROTO_TCP,

LocalAddress, // SOCKADDR

RemoteAddress, // SOCKADDR

0, // Flags

SocketCallbackContext,

SocketCallbackDispatch,

Process,

Thread,

SecurityDescriptor,

IRP

);

wsk scenarios wsk socket control
WSK Scenarios: WSK Socket Control

//

// Setting SO_RCVBUF socket option

//

ULONG rcvbufsize = 16384;

Allocate IRP;

IoSetCompletionRoutine(IRP, CompletionRtn/Ctx);

WskSocketDispatch-> WskControlSocket (

WskSocket,

WskSetOption, // RequestType: set, get, ioctl

SO_RCVBUF, // OptionName

SOL_SOCKET, // Level

sizeof(rcvbufsize), // InputSize

&rcvbufsize, // InputBuffer

0, // OutputSize

NULL, // OutputBuffer

NULL, // OutputSizeReturned

IRP

);

call to action
Call To Action
  • WFP
    • Explore WFP API documentation in the WDK for kernel APIs and SDK for user APIs
    • Use WFP APIs instead of filter and firewall hooks
    • Consider using Callout drivers instead of NDIS and LSPs
  • WSK
    • Explore the WSK API Documentation in the Windows Driver Kit (WDK)
      • Sample WSK Client planned for Beta 2 WDK
    • Consider using WSK for new KM networking needs
    • Consider migrating old TDI client code to WSK
community resources
Community Resources
  • Windows Hardware and Driver Central (WHDC)
    • www.microsoft.com/whdc/default.mspx
  • Technical Communities
    • www.microsoft.com/communities/products/default.mspx
  • Non-Microsoft Community Sites
    • www.microsoft.com/communities/related/default.mspx
  • Microsoft Public Newsgroups
    • www.microsoft.com/communities/newsgroups
  • Technical Chats and Webcasts
    • www.microsoft.com/communities/chats/default.mspx
    • www.microsoft.com/webcasts
  • Microsoft Blogs
    • www.microsoft.com/communities/blogs
additional resources
Additional Resources
  • E-Mail
    • WFP: wfp @ microsoft.com
    • WSK: wskapi @ microsoft.com
  • Web Resources
    • Join the WFP beta program
      • Go to http://beta.microsoft.com
      • Choose the Guest ID sign-up option
      • Enter the Guest ID: WFPBeta5
      • Fill out the WFP beta program sign up survey
