Presentation Transcript
slide1

In silico aided metaoblic engineering of Saccharomyces cerevisiae for improved bioethanol production

Christoffer Bro et al. 2005

the problem
The problem
  • Under anaerobic conditions, S. cerevisiae produces only four major products from glucose:
    • CO2, ethanol, biomass and glycerol
  • To increase the ethanol yield, the flow of carbon going to biomass or glycerol should be redirected towards ethanol.
previous work
Previous work
  • Some of the carbon flowing to biomass can be redirected towards ethanol by increasing the consumption of ATP for biomass production or reducing the amount of ATP formed in association with ethanol production. (Nissen et al. 2000)
  • Deletion of the structural genes in glycerol biosynthesis is not a successful strategy.
    • The maximum specific growth rate is severely lowered in such strains
    • Formation of glycerol is necessary for maintaining the redox balance by oxidizing NADH
strategy 1
Strategy #1
  • Substitution of NADPH-oxidizing reactions in biomass formation with NADH-oxidizing reactions
strategy 2
Strategy #2
  • Substitution of NAD+-reducing reactions in biomass formation by NADP+-reducing reactions.
strategy 3
Strategy #3
  • Introduction of a reaction which either directly or via a cycle converts NADH into NADPH.
strategy 4
Strategy #4
  • Substitution of the glycerol production with production of ethanol, which has a net oxidation of NADH.
in silico model
In silico model
  • iFF708 (Forster et al., 2003)
    • 708 genes
    • 584 metabolites
    • 1175 reactions
method
Method
  • A database of 3800 biochemical reactions is derived from the LIGAND database of KEGG.
  • Each gene (corresponding to a specific biochemical reaction) was inserted one at a time into the genome-scale metabolic model, and the performance of the engineered strain was evaluated.
  • Two other engineered strains:
    • Heterologous expression of a non-phosphorylating, NADP+-dependent D-GAPN
    • Deletion of GDH1 combined with simultaneous overexpression of GDH2 or GLN1 and GLT1.
      • GDH1: AKG + NH3 + NADPH -> GLU + NADP
      • GDH2: GLU + NAD -> AKG + NH3 + NADH
      • GLN1: GLU + NH3 + ATP -> GLN + ADP + PI
      • GLT1:AKG + GLN + NADH -> NAD + 2 GLU
in vivo testing of the best strategy
In vivo testing of the best strategy
  • Ethanol production increased by 3%
  • Reasons for disagreement between experiment and model:
    • Limited GAPN activity in vivo
    • Low intracellular NADP+ concentrations compared with NADPH
discussion
Discussion
  • “The success of the strategies is due to the tight linking of the different parts of the metabolic network through the common usage of co-factors like NADH, NADPH and ATP, and the genome-scale metabolic model represents a valuable tool for studying how these co-factors link the different parts of the metabolism in a quantitative fashion.”
efficiency of amino acid production in escherichia coli

Efficiency of amino acid production in Escherichia coli

Anthony Burgard & Costas Maranas, 2001

slide16

iJR904

20

8.2609

15.68

18.627

9.4501

11.322

11.81

26.122

7.8728

7.4219

7.5

7.8512

5.7951

5.4913

10.074

20

12.601

4.4907

5.6886

10

universal model
Universal model
  • The universal model is constructed by incorporating 3400 cellular reactions from the KEGG into the modified Keasling stoichiometric model.
