Presentation Transcript
outline
Outline
  • Web App Case Study
  • Modern Web Characteristics
  • Modern Web Architecture : Open Social
    • Architecture
    • Components
    • Security
      • Background
      • Authorization
      • Out of Scope: Authentication
  • Future Directions

2

modern web app case study facebook

Your current status

Friends

Activities of your friends

photos

Video

Comment, Rate

Aggregationwith Picasa

Chat

groups

More apps!

Modern Web App Case Study : Facebook
  • Facebook
    • More than 200 million active users
    • MS paid $240 million for 1.6 percent

3

web 2 0
Web 2.0
  • “Second generation of web development and web design”
  • Web 2.0 vs. Web 1.0
    • Technical point of view
      • Similar technologies as Web 1.0: HTML, Javascript, XML, HTTP, etc.
      • Web2.0 makes the web programmable
    • User’s point of view
      • Read-write collaborative web
        • Sharing, creation of data
      • Participatory nature
        • Blogging, commenting, rating
      • Cooperate, not control
        • Facebook interoperates with Google Picasa, Yahoo! Flickr, Blogs, etc
      • User centric
        • Web is a platform. Users add content (“value”)

6

web 2 07
Web 2.0
  • Debate (Buzzword vs. Real progress) is going on, but it has begun to coalesce.
    • “Web 2.0 Architectures: What entrepreneurs and information architects need to know”
    • OpenSocial: case study that illustrates or motivates several Web 2.0 topics of discussion.
  • We will use Open Social to illustrate Web 2.0 architecture
opensocial
OpenSocial
  • A coherent open architecture designed for social network services and applications.
    • Common APIs across many websites
      • REST/RPC protocols – for server-to-server interactions
      • Javascript APIs – for browser-to-server interactions
    • Authorization mechanism, Data model …
  • Usage
    • Supported by MySpace, Google Orkut, Twitter, LinkedIn, XiaoNei…
      • Internationalization
    • Rival: Facebook

8

open social javascript api example
Open Social Javascript API Example

Person: ID, NAME, NICKNAME, ADDRESSES, EMAILS, STATUS, MOVIES, MUSIC,FOOD …

Activity: TITLE, URL, BODY, PRIORITY …

Data

Model

// Creates a data request object to use for

// sending and fetching data from the server.

var req = opensocial.newDataRequest();

// Adds an item to fetch data from the server

req.add(req.newFetchPersonRequest('OWNER'), “owner”);

// Sends a data request to the server

req.send(function(data) {

owner = dataResponse.get("owner").getData();

});

Fetch profileinformationof owner

JavaScript

API

example

AJAX!!!

9

open social message examples
Open Social Message Examples

Request (HTTP POST)

[{"method" :"people.get",

"params" :{

"userId" : ["@owner"],

"groupId" : "@self",

"id" : "owner",

"fields" :

["id","name", "thumbnailUrl", "profileUrl", "id", "displayName"]}}]

157 Bytes

How about the corresponding

representation in XML???

Response

JSON

[{"id" :"owner",

"data" :{

"displayName" : "Guo Zhenhua" "profileUrl" : "/Main#Profile.aspx?uid=3672642670645936703,

"id" : "06881043280087178653",

"thumbnailUrl": "http://www.orkut.com/img/i_nophoto64.gif",

"name" : { "familyName":"Zhenhua", "givenName":"Guo" },

...... }}]

10

slide11
JSON

Lightweight, Simple

Can represent basic data structures (number, string, boolean, object, array)

Textual human-readable

Easy to generate and manipulate

Not extensible, No namespace

Hard to represent complex data structures

References

User-defined type

Request message

represented in XML

<request>

<method>people.get<method><params>

<userId>

<id>@owner</id>

</userID>

<groupId>@self</groupId>

<id>owner</id><fields>

<field>id</field>

<field>name</field>

<field>thumbnailUrl</field>

<field>profileUrl</field>

<field>id</field>

<field>displayName</field>

</fields>

<params>

</request>

XML

  • Extensible
  • Support namespace
  • Support representation of complex data structures.
  • Heavyweight
  • Slow and verbose

281 Bytes

opensocial architecture
OpenSocial - Architecture

Logic level

Components

  • Interface – REST, Javascript APIs
  • Client – Ajax, Gadget
  • Message Format - JSON
  • Security - OAuth
  • Data Model

12

opensocial interface rest

resource

verb

OpenSocial Interface – REST

REST – REpresentational State Transfer

  • Based on HTTP (client/server + stateless server)
  • Resource-oriented (resource can be anything)
  • Each resource is identified by a unique URL
  • State transition (Link resources together)
  • Resources have multiple representations (json, xml)
  • Uniform interfaces

How to access top ten Twitter topics?

analysis of rest
Analysis of REST
  • Treat the web as a big database of resources
    • Good for CRUD operations
  • A strong constraint – Stateless
  • Beyond REST
    • Stateful applications
      • Streaming Applications
      • Workflow Execution
    • Push-Based systems
      • Pub-Sub systems

14

rest alternative
REST Alternative
  • SOAP based WS
    • SOAP

Message format

    • UDDI

Service registration

    • WSDL

Service description interface

1

2

3

4

Publish – Find – Bind

  • About 60 core ws-* protocols
  • Designed for server-server interactions
    • SOAP and WSDL are really complicated
    • Browser-based apps are second-class citizens.

15

opensocial client tech ajax
OpenSocial Client Tech – AJAX
  • Rationale

Update sections without refreshing the whole page

    • More interactive
    • More responsive
    • Less bandwidth usage
  • Asynchronous JavaScript and XML
    • HTML + CSS  Presentation
    • DOM  Document model (for dynamic manipulation)
    • XMLHttpRequest  Asynchronous Communication
    • JSON/XML  Data format
    • Javascript  Bring these together

17

opensocial data model
OpenSocial Data Model
  • Define data models for basic objects in social network
    • Person
    • Activity
    • AppData
  • Relationships between objects can not be represented.
    • Friend of a Friend (FOAF) – Based on W3C RDF
    • XHTML Friends Network (XFN)
  • Other possible issues
    • Groups, roles, communities
    • Strength of relationships
    • Relationships in which more than two objects are involved
    • Scalability (in terms of number of friends)
beyond functionalities security
Beyond Functionalities - Security
  • Identity
    • “On the internet, nobody knows you're a dog”
    • Claimed Identity ≠ Real Identity
  • Data protection
    • Who can access your Facebook data?
    • Increasing risk of identity theft and impersonation.
      • Favorite color, mother’s maiden name, …
      • “Friends” and applications have access to this
      • “Predicting Social Security numbers from public data”
  • Communication links

Messages are passed by intermediary machines

    • Intermediaries understand your messages?
    • Intermediaries alter your messages?
    • Intermediaries forge your messages?

Cartoon by Peter Steiner. The New Yorker, July 5, 1993 issue

(Vol.69 (LXIX) no. 20) page 61

21

21

security requirements in web

SSL/TLS

Securer programs +

User education

Security Requirements (in Web)
  • Connection level
    • Confidentiality
    • Integrity
    • Non-repudiation
    • Prevention of replay attack
  • System Implementation level
    • Redirect
    • Session stealing (cookie)
    • Cross-site scripting, Cross-site request forgery
  • Architecture level
    • Authentication
      • Single Sign-On
    • Authorization
      • Delegation

22

challenges
Challenges
  • Technical Challenges
    • Loosely coupled components
    • No single, isolated trusted base
    • Domain-specific policies
    • Separation of security policies and security mechanisms.
  • Possible solutions
    • Authentication
      • Central Authentication Service
      • Cosign
      • OpenID
    • Authorization
      • Shibboleth
      • OAuth

23

opensocial authorization oauth
OpenSocial Authorization – OAuth
  • Motivation
    • To allow third party apps to access users’ data stored at service provider without requiring username and password.
  • Solution
    • Delegated authorization protocol
    • Light-weight
    • Explicit user consent
    • Based on REST
  • Drawbacks
    • Vulnerable to session fixation attack (http://oauth.net/advisories/2009-1)
    • Delegation granularity (Service provider-specific)
    • Access token expiration and revocation
  • Resources
    • http://oauth.net/

3rd-party App

Twitter

24

authentication
Authentication
  • OpenSocial does not define authentication mechanism.
  • Different accounts for different service providers
    • Twitter, Facebook, Myspace, Orkut, Hi5 …
    • Same data everywhere
  • Account linking

Linking Disparate Account IDs Across Multiple Systems or Applications

Identity

Federation

=> Identity portability

25

authentication openid
Authentication – OpenID
  • Motivation
    • Provide lightweight authentication service across domains
  • Solution

Users are asked to prove ownership of their OpenID identifiers.

    • OpenID identifiers are URLs (e.g. http://zhenhua-guo.blogspot.com).
    • Service provider and identity provider are clearly separated.
    • Authentication delegation (service provider → identity provider)
  • Advantages
    • Cross-domain authentication
    • Attribute exchange beyond authentication
    • Single Sign-On
    • Easy OpenID provider switch
  • Drawbacks
    • Phishing attack
  • Resources
    • Supported by Facebook, Verisign, Sourceforge, Yahoo, etc.

http://fcom.us.es/blogs/nuevafcom/files/2008/09/openid-1.jpg

26

oauth and openid
OAuth and OpenID
  • Based on relaxed REST
  • Use SSL/TLS to guarantee confidentiality, integrity and non-repudiation.
  • Scalability
  • Vulnerable to
    • Phishing
    • Cross-site scripting
    • Cross-site forgery request

27

conclusions
Conclusions
  • Adoption of web 2.0
  • Services, not packaged software
  • Open Architecture and Open Standards
    • Interoperability
    • Flexibility
    • Integration
  • Security
  • Adoption in scientific communities
    • Traditional gateways
      • LEAD, Earth System Grid
    • Gateways that integrate web 2.0 technologies
      • myExperiment, SciVee, Sakai
      • Open Life Science Gateway
      • PolarGrid Portal
future directions
Future Directions
  • Semantic Web (Web 3.0?)
    • Machine-readable representations of resources and relationships
  • Artificial Intelligence, Data Mining
    • Search Engine
      • Information search
    • Recommendation System
      • Scaling
    • Question Answering
      • Information retrieval
    • Social Network Analysis
      • Flow pattern recognition
      • Strength of connections

29

my research
My Research
  • Gadget Layout Management
  • OAuth implementation
    • Implement 2-legged OAuth
    • Integrate 3-legged OAuth
  • PolarGrid Portal
