  1. ProvideX Report Writer Presented by: Jane Raymond

  2. Presentation Overview • Introduction • Designer Enhancements • Object-Oriented Interface • New User Interfaces • The Future

  3. Introduction ProvideX Report Writer • Add-on for designing and generating reports. • Creates and manipulates layout of report like a spreadsheet application. • Features: • Data drag & drop • Column/row sizing • Formula definition • Cell formatting • Outputs to printer, PDF, HTML, ProvideX Viewer, Clipboard… • Sorting rules • Data groupings • Data filters • External parameters

  4. Designer Enhancements • Defining the Data • New input sources • Enhanced Sorting and Filtering • Grouping the Data • New group option • Conditional detail groups • Editing the Layout • Cut / Copy / Paste • Report Elements • Hyperlinks • Images

  5. Designer Enhancements • Formatting • Display formats • Background colour • Wordwrap • Conditional Cell Definitions • Report Options • Empty report suppression • PDF Bookmarks • Paginated HTML • Alternating background colours • Custom Output Destination • Report Destinations • ProvideX Viewer, Custom output objects • Saving the Report

  6. Defining the Data • New Input Sources • Support for external databases using Views: • ODBC • Oracle • DB2 • Reports with no input source are supported • Output consists of page header, report summary and page footer. • Defining the Data / Selecting the Input Source

  7. Defining the Data • Expanded Custom Sort Sequence • Define up to 16 segments • Defining the Data / Sort Sequence

  8. Defining the Data • Enhanced Data Filters • Filter sets allow multiple sets of conditions • Defining the Data / Data Filters

  9. Enhanced Data Filters All conditions within a filter set must be true for the set to be true If a filter set is not true, the sets are evaluated in sequence until one is true Option to accept/reject the data if the set is true If no set is true, result is based on the inverse of the last filter set Allows logical OR and NOT processing Defining the Data • Defining the Data / Data Filters

  10. New Group Option Page Reset Reset page number to one whenever group changes Conditional Detail Groups Multiple detail line groups Associated conditions determine which group to use to display a record Grouping the Data • Defining the Data / Data Filters

  11. Editing Features • Cut / Copy / Paste • Contents • Format • Font • Colour • Alignment • Borders • Conditions • Internal only – Does not use Clipboard • Creating the Report Layout / Editing the Layout

  12. Report Elements • Hyperlinks • For HTML output • Creating the Report Layout / Selecting Report Elements

  13. Report Elements • Images • Supported on Windows and WindX systems • Supported on UNIX and Linux systems using *PDF* channel and .jpg images only • Options include resizing and alignment • When combined with a hyperlink in HTML output, becomes a clickable image • Creating the Report Layout / Selecting Report Elements

  14. Cell Formatting • Display Format Masks • Now supports expressions • Background Colours • Word wrap • Wrap text within defined cell dimensions • Creating the Report Layout / Formatting

  15. Conditional Cell Definitions • Alternate cell definition • Includes contents and formatting • Associated condition • Determines which definition is used when displaying the cell Default SalesYTD>=500,000 • Creating the Report Layout / Conditional Cell Definition

  16. Report Options • General • Suppress empty reports • Bookmark PDF output when group changes • Paginate HTML output when specified group changes • ‘Start new page when group changes’ option must be set at group level • Browser-dependent • Report Options / General Options

  17. Report Options • Colours • To set alternating background colours on detail lines • One or two colours • Options • Default – Uses colours defined in %RW_BgColour1$ and %RW_BgColour2$, if set • On – Uses colours set in Options/Colours interface • Off – No alternating background colours • Report Options / Colours

  18. Report Options • Custom Interfaces • For specifying a custom output destination • User-created output object • Default object • *rpt/useroutput or object specified in %RW_UserOUtput$ • Report-specific object • Report Options / Custom Interfaces

  19. Report Destinations • ProvideX Viewer • Output to the Viewer to preview the report • From the Viewer, output can then be sent to the printer or PDF file • Custom Output • Sends output to a user-created object • Uses (in order of precedence): • The Report Options / Custom Interfaces / Custom Output Destination entry. • Object specified in %RW_UserOutput$ • *rpt/useroutput.pvc • Setting the Report Destination

  20. Saving the Report • Report definition no longer must be saved before generating a report • Allows designer to test the report before saving the definition • Multiple-User Detection • If a report is in use, another user can only open the report in the Designer in read-only mode, or use the SaveAs option to save the definition using a different name • Saving the Report Definition

  21. Object-Oriented Interface • New properties, methods and objects to support all the new features AddAlternateCell( ), AddFilterSet( ), BookMarkPDF, CheckFilters( ), FilterSetCount( ), GetBackgroundColor$( ), GetBackgroundColorOption$( ), GetBackgroundColour$( ), GetBackgroundColourOption$( ), GetDestination$( ), GetDestinationFile$( ), GetDestinationOption$( ), GetFilter( ), GetFilterSet( ), GetSystemVariable$( ), GetSystemVariableCount( ), GetSystemVariableDescription$( ),GetSystemVariableDescriptions$( ), GetSystemVariableLength( ), GetSystemVariables$( ), GetUserOutputObject$( ), GroupCount( ),IsOutputNoChannel( ), IsOutputNoPaging( ), IsOutputPrinterCompatible( ), OutputDevice( ), OutputUser( ), OutputViewer( ), PaginateHTML, RemoveAlternateCell( ), RemoveFilterSet( ), SetBackgroundColor( ), SetBackgroundColorOption( ), SetBackgroundColour( ), SetBackgroundColourOption( ), SetHyperlink( ), SetImage( ), SetUserOutputObject( ), SuppressEmpty, UserLogic, etc. • Object-Oriented Interface

  22. User Interfaces • Optional • Must be created according to User Interface Specifications • Two interfaces: • Logic Object Interface • Custom Output Object Interface • Report Writer User Interfaces

  23. User Interfaces Logic Object Interface • Supplies additional generic logic for processing reports • Can be used to set up the execution environment, load variables, specify new system variables, adjust the report format, manipulate data, reset the environment • Used for all reports • *rpt/userlogic.pvc, or object defined in %RW_UserLogic$ • Report Writer User Interfaces / Logic Object Interface

  24. User Interfaces Logic Object Interface • User Interface Specifications • Properties • UserVariableCount • Functions • Initialize( ) • Reset( ) • UpdateReport(Rpt) • UpdateData$(Data$,Iolist$) • GetUserVariable$(idx) • GetUserVariableDescription$(idx) • GetUserVariableLength(idx) • GetUserVariableValue(idx) • Report Writer User Interfaces / Logic Object Interface

  25. User Interfaces Logic Object Interface • Template provided for user logic object *rpt/rptuserlogic.pvc • Report Writer User Interfaces / Logic Object Interface

  26. User Interfaces Custom Output Object Interface • Used to output the data generated by a report definition • Specify Custom Destination • Report-specific • Default • *rpt/useroutput.pvc, or object defined in %RW_UserOutput$ • Set Output Destination to Custom Output • Report Writer User Interfaces / Custom Output Object Interface

  27. User Interfaces Custom Output Object Interface • User Interface Specifications • Properties • MaxLines • NoChannel • NoPaging • PrinterCompatible • Functions • Initialize(Rpt) • GetIolist$(GroupIdx,LineIdx) • TranslateSpecialChars$(Record$) • PrintLine(Line$) • Close() • Destination$ • DestinationOption$ • DestinationFile$ • Report Writer User Interfaces / Custom Output Object Interface

  28. User Interfaces Custom Output Object Interface • Template provided for user output object *rpt/rptoutput.pvc • Report Writer User Interfaces / Custom Output Object Interface

  29. User Interfaces Custom Output Object Interface • Sample custom output object: DEF CLASS “outputpdf” LIKE "*rpt/rptprinter" PROPERTY Destination$="*pdf*" PROPERTY DestinationFile$=%PDFfile$ END DEF • Code to generate report: %PDFfile$="c:\tmp\sample.pdf" r=NEW("*rpt/pvxreport") r'RunReport("MyReport.pvr") DROP OBJECT r SYSTEM_HELP %PDFfile$ • Report Writer User Interfaces / Custom Output Object Interface

  30. The Future… • Unofficially… • Direct access to Views maintenance • Simpler way to process user-created parameter interfaces • Ability to directly associate group functions (i.e. totals, averages, etc.) with formulas • Easy way to select an entire row/column in the Designer • etc.

  31. QUESTIONS?

  32. THANK YOU! End of Presentation
