case report
Case Report:
  • CC: Shortness of Breath
  • HPI: 62 y/o Caucasian male, without previous significant medical history, presents with 6-8 months of progressively worsening dyspnea. Recalls 1 month h/o new onset leg and belly swelling. Describes 2 pillow orthopnea and occasional PND. Denies CP, syncope, or lightheadedness.
case report3
Case Report:
  • PMHx: Childhood murmur
  • Meds: None
  • All: NKDA
  • SHx: Denies etoh, smoking, or illicit drugs
  • FMHx: Did not have a relationship with his family, and therefore, is was not familiar with their medical problems.
case report4
Case Report:
  • PE:

97.6 115 159/109 26 100%2L

Gen: Middle aged male with mild

respiratory distress

Neck: Short and thick, No obvious jvd

CV: Tachycardic w/ RR, nl S1 S2, +S3, 2/6

crescendo decrescendo systolic murmur at URSB

Pulm: Mild bilateral base crackles

Abd: Diffuse abdominal wall edema, +shifting dullness

GU: +scrotal edema

Ext: 3+ Bilateral pitting edema

case report5
Case Report:
  • Na 143, K 4.3, Cl 105, CO2 30, BUN 23, Cr 1.3, Glu 108………
  • WBC 10.6 w/ NL diff, Hg 15.8, Hct 50.8, Platelets 219,000 …….
  • Tprot 6.7, Alb 3.5, Ast 66, Alt 57, Alkphos 127, Tbili 1.2
  • UA: +protein
  • BNP 3690
case report6
Case Report:
  • EKG: STach 115, LVH
  • CXR: CM, Increased PVC, Small bil pleural

effusions

Initial A/P: New CHF…..Started on Natrecor,

Lasix, Digoxin, Captopril, and

Aldactone……More to

follow………………………

cardiac cath measurement of stenotic aortic valve area7
Cardiac Cath Measurement of Stenotic Aortic Valve Area
  • As valvular stenosis develops, the valve orifice produces more resistance to blood flow, resulting in a pressure gradient (pressure drop) across the valve
gorlin formula
Gorlin Formula
  • Calculates cardiac valvular orifice area from flow and pressure-gradient data
  • Incorporates 3 preexisting formulas
gorlin formula9
Gorlin Formula
  • 1.) Torricelli’s Law (flow across a round orifice)

F = AVCc

F = Flow Rate

A = Orifice Area

V = Velocity of Flow

Cc = coefficient of orifice contraction

(compensates for the physical phenomenon, that except for a perfect orifice, the area of a stream flowing through an orifice will be less than the true area of the orifice)

gorlin formula10
Gorlin Formula
  • 2.) Relates pressure gradient to velocity of flow

V2 = (Cv)2 x 2gh

Cv = coefficient of velocity, corrects for energy

loss as pressure energy is converted to

kinetic energy

g = acceleration due to gravity (980 cm/sec/sec)

h = pressure gradient in cm H2O

gorlin formula11
Gorlin Formula
  • Combining the two equations, yields:

F

A = ----------------------------

(C)(44.3) (sq root of h)

C = Empirical constant incorporating Cv and Cc, and accounting for h adjusted to units of mmHg, and correcting calculated valve area to actual valve area as measured at surgery or autopsy. Using this constant, the maximum derivation of calculated valve area from measured valve area was 0.2 cm2.

gorlin formula12
Gorlin Formula
  • Since antegrade aortic flow occurs only in systole, F is the total CO during which there is forward flow across the valve

F = CO/(SEP)(HR)

F (cm3/sec)

CO (cm3/min)

SEP (sec/beat) HR (beats/min)

slide13

*SEP (systolic ejection period) begins with aortic valve opening and proceeds to the dicrotic notch or other evidence of valve closure.

gorlin formula14
Gorlin Formula
  • Thus, the final Gorlin equation for the calculation of valve orifice area (in cm2) is:

CO/(SEP)(HR)

  • Area = ----------------------------------------

44.3(C)(sq rt of pressure gradient)

Where C = empirical constant

For MV, C = 0.85 (Derived from comparative data)

For AV, TV, and PV, C = 1.0 (Not derived, is assumed based

on MV data)

alternative to the gorlin formula
Alternative to the Gorlin Formula

*A simplified formula for the calculation of stenotic cardiac valves proposed by

Hakki et al…Circulation 1981. Tested 100 patients with either AS or MS.

*Based on the observation that the product of HR, SEP or DFP, and the Gorlin

equation constant was nearly the same for all patients measured in the resting

state (pt. not tachycardic). Values of this product were close to 1.0.

*Calculations somewhat comparable………

aortic valve area cm2
Aortic Valve Area (cm2)
  • Critical AS: < 0.7

Moderate AS: 0.7 – 1.5

Mild AS: 1.5 - 2.5

NL Aortic Valve: 2.5 - 3.5

*Ranges have variability based on body size (i.e. a larger person, requiring higher CO for perfusion, may become symptomatic at a larger aortic valve area)

slide17
Relationship between CO and Aortic Pressure Gradient over a range of values for AV area (Based on Gorlin formula)

A

slide18

*As HR increases (i.e. during exercise), the SEP shortens. However, SEP shortening is attenuated by increased venous return and peripheral arteriolar vasodilation.

CO / (HR)(SEP) 2

Change in pressure = [ ------------------- ]

(44.3)(AVA)

Therefore, the increase in CO will be partially offset by the increase in

(HR)(SEP), so that the gradient across the valve will not quadruple with

a doubling of CO during exercise.

slide19
Relationship between CO and Aortic Pressure Gradient over a range of values for AV area (Based on Gorlin formula)

*As HR slows in patients with AS, the SV increases if CO remains constant. Thus,

Flow across the valve increases, as does the pressure gradient.

B

slide20
Relationship between CO and Aortic Pressure Gradient over a range of values for AV area (Based on Gorlin formula)

C

acquiring hemodynamic data25
Acquiring Hemodynamic Data
  • Indicator Dilution Method (CO):

*Based on the principle that a single injection of a known amount of indicator (cold/room temperature saline for thermodilution technique or indocyanine green dye) injected into the central circulation mixes completely with blood and changes concentration as it flows distally.

acquiring hemodynamic data26
Acquiring Hemodynamic Data
  • Thermodilution Indicator Method:

*Rapidly inject 10 cc of saline through proximal port of PA catheter. An external thermistor measures the temperature of the injectate. Complete mixing of saline with blood causes a decrease in the blood temperature, which is sensed by a distal thermistor. Computer calculates CO based on the change in indicator concentration (using temperature over time).

acquiring hemodynamic data27
Acquiring Hemodynamic Data
  • O2 consumption measured from metabolic hood or Douglas bag; it can also be estimated as 3 ml/min/kg or 125 ml/min/m2.
  • AVo2 difference calculated from arterial – mixed venous (pulmonary artery) O2 content, where O2 content = saturation x 1.36 x Hg

*Accurate method of measuring CO, especially in patients with low cardiac output.

slide28

*Metabolic Hood (Polaragraphic method)

*Utilizes a polaragraphic oxygen sensor cell to measure oxygen content of

expired air.

*Room air is withdrawn at a constant rate through a plastic hood over the

patient’s head.

*Measures the contents of the hood (room air/expired air) through a flexible

tubing that feeds to the polaragraphic oxygen sensor.

*Douglas Bag

*Patient is asked to breathe into a large, sealed, air-tight bag for a specific

period of time.

*The mouthpiece to the bag has a two-way valve.

*Allows patient to inspire room air, while the expired air (pt. wears a nose

clip) goes into the Douglas bag.

*After the specified interval, the bag is sealed and the contents analyzed.

cardiac output by fick method example
Cardiac Output by Fick Method (example)

Arterial saturation 95%

Pulmonary artery saturation 65%

Hg = 13

O2 consumption is 210 ml/min (3 ml/kg given a 70 kg person)

slide32

*Multiple sites for recording transaortic

valve gradients

*Simultaneous tracings between site 1

and 3 would give the most accurate

pressure gradient

*Usually use sequential readings

(pullback) from 1 to 3, and

use simultaneous tracings at 1 + 5

*Assey et al. measured the transaortic

valve gradients in 15 patients from

eight different combinations of catheter

locations. In some patients, the

differences in gradient among the

different measurement sites were as

much as 45 mmHg.

slide34

*In addition to time delay, peripheral artery waveforms are distorted by systolic

amplification and widening of the pressure waveforms.

slide35

*Errors in pressure gradient can also occur if, during pullback, the LV catheter

is placed in the LV outflow tract

slide36

*Alternative to measuring transaortic valve gradient using simultaneous LV and

femoral artery pressures, as introduced by Krueger et al. at the University of

Utah.

calculating aortic valve area example
Calculating Aortic Valve Area (example)
  • Mean aortic valve pressure gradient = 40 mm Hg
  • SEP = 0.33 sec
  • HR = 74
  • CO = 5000 mL/min
  • AV constant = 44.3
calculating aortic valve area example39
Calculating Aortic Valve Area (example)

CO/(SEP)(HR)

  • A = ----------------------------------------

44.3(C)(sq rt of pressure gradient)

assessment of aortic stenosis in patients with low cardiac output
Assessment of Aortic Stenosis in Patients with low Cardiac Output

* Valve calculations using the Gorlin formula

are flow dependent. Therefore, low CO states may give an errantly low

calculation of aortic valve area.

* Decreased flow through the stenotic valve in conjunction with decreased LV pressure, physically opens the valve to a lesser orifice area, and thus, the valve orifice really is smaller during low flow states.

* Should keep this in mind when calculating aortic valve area using standard techniques in patients with low cardiac output.

assessment of aortic stenosis in patients with low cardiac output41
Assessment of Aortic Stenosis in Patients with low Cardiac Output
  • In patients with AS, an infusion of nitroprusside or dobutamine substantially increases forward output, and may substantially decrease the transvalvular gradient.
  • Potentially dangerous
assessment of aortic stenosis in patients with low cardiac output42
Assessment of Aortic Stenosis in Patients with low Cardiac Output

*”Valve resistance” may be an adjunct to the Gorlin equation in differentiating truly severe AS in patients with low cardiac output states. (Cannon et al….JACC 1992)

(mean gradient)(SEP)(HR)(1.33)

VR = ----------------------------------------

CO

*Advantage of being calculated from two directly measured variables, and requires no discharge coefficient. Resistance appears to be less flow dependent than valve area.

slide43

*Patients with resistance > 250 dynes sec cm -5 are more likely to have significant

AS, while those with resistance < 200 dynes sec cm -5 are less so.

case report44
Case Report
  • Echo Clips…
case report45
Case Report:

2D-Echo:

LVEF 15-20%

Severely reduced RVEF

4-Chamber DCM

Abnormal LV Relaxation

Severe Aortic Stenosis (PK AV Vel 4.3 m/s, Mean AV

gradient 33 mmHg, AV area 1.0 cm2)

Mild Aortic Insufficiency, Mild Tricuspid

Regurgitation, and Mild Mitral

Regurgitation

lhc rhc
LHC + RHC
  • CO 4.2 L/min
  • CI 2.2 L/min/m2
  • RA pressure 12
  • RV pressure 65/10-13
  • PA pressure 56/41
  • Wedge 32-35
  • LV pressure 200/35
  • Aortic pressure 150/85
  • Simultaneous pressure gradient 48.5 mmHg
  • Valve Flow 178 cm3/sec
  • Mean gradient 60 mmHg
  • Aortic Valve Area 0.52 cm2
  • Distal LCX 80-90% prior to large PDA filling via right to left collaterals
case report48
Case Report

*LV to Aorta Pullback

case report49
Case Report

*Simultaneous pressure gradient

case report50
Case Report

*Planimetry of shaded area yields pressure gradient

case report51
Case Report:
  • Hospital Course and Discharge Plan:

*Achieved adequate diuresis in the

hospital

*Referral to CT Surgery for

possible AVR and 1V-CABG

summary
Summary:
  • Cath measurement of aortic valve stenosis is based on the Gorlin formula.
  • Proper calibration and procedural techniques using the catheter is important in acquiring accurate cardiac output and pressure gradients.
  • During low cardiac output states (i.e. CHF), may need to use adjunctive techniques to acquire reliable hemodynamic data to calculate accurate aortic valve area, and in turn, make the appropriate recommendation regarding valve replacement.
references
References
  • Baim, Grossman. Grossman’s Cardiac Catheterization, Angiography, and Intervention, 6th Edition. 2000. pp 193-207.
  • Kern, Morton. The Cardiac Catheterization Handbook, 2nd Edition. 1995. pp 108-138.
  • Braunwald. Heart Disease, 6th Edition. 2001. pp 371-385.
