Presentation Transcript
slide1
Comparison of Different

WAP Gateways

Obaidullah Khan

Wireless Development, Fall 2002

University of Houston –Clear Lake

nokia activ server 2 1
Nokia Activ Server 2.1
  • WAP Functionality
    • WAP 1.2.1 June 2000 compliant
    • Nokia Wireless Protocol Stack
    • Encoder for WML and WMLScript to Binary
nokia activ server 2 11
Nokia Activ Server 2.1
  • Server Functionality
    • User authentication and access control
    • Application and content hosting
    • Open API for back-end integration
    • Web server functionality provisioning services
nokia activ server 2 12
Nokia Activ Server 2.1
  • Wireless Bearers
    • UDP/IP for:
      • GSM, TDMA, and CDMA Circuit Switch Data
      • GPRS and CDPD Packet Switched Data
    • SMS Centers:
      • Nokia SMSC ; CMG SMSC; Aldison SMSC
    • Nokia Communicator and phones
nokia activ server 2 13
Nokia Activ Server 2.1
  • Content Access
    • Textual to binary WML and WML Script
    • Automatic conversion of HTML, TTML to plain text WML
    • Access to HTTP 1.1 & HTTP 1.0 origin servers
    • Access to local file system
    • Access to 3rd party systems through Nokia API
    • WML and WMLScript 1.0 –1.3
nokia activ server 2 14
Nokia Activ Server 2.1
  • Application Programming Interface
    • WAP Server API
      • Java Servlet API 2.2
      • WAP Service API for WAP protocol data
      • Interface for customized creation of billing information
      • Authentication API for customized authentication
      • HTTP interface for provisioning solution
nokia activ server 2 15
Nokia Activ Server 2.1
  • Session Handling
    • Wireless Session Protocol (WSP)
    • WTLS sessions
    • HttpSession interface with Java Servlet API 2.2
    • Cookie support via cookie proxy*
nokia activ server 2 16
Nokia Activ Server 2.1
  • Access Control
    • Unknown and specified terminal
    • Mobile device identity number (MSISDN)
    • HTTP basic authentication
    • HTTP proxy authentication
    • URL access control
nokia activ server 2 17
Nokia Activ Server 2.1
  • Platform
    • Windows NT
    • Windows 2000
    • HP – UX 11i
    • Sun Solaris 8
nokia activ server 2 18
Nokia Activ Server 2.1
  • Other Features
    • Administration tools
    • Logging
    • User directory
    • Over-the-air (OTA) provisioning
    • Content adaptation
nokia wap server 1 1security pack
Nokia WAP Server 1.1Security Pack
  • Server authentication and data encryption
  • WAP 1.1 compliant – WTLS class 1 & 2
  • Levels of encryptions: 56-bit and 128-bit
  • SSL back-end support
nokia wap server 1 1security pack1
Nokia WAP Server 1.1Security Pack
  • Asymmetric cryptography:
    • RSA and RSA anon
  • Bulk encryption:
    • RC5
  • MAC algorithm:
    • SHA-1
nokia wap server 1 1security pack2
Nokia WAP Server 1.1Security Pack
  • Asymmetric Encryption Algorithms
    • Up to 768-bit key length – 56-bit pack
    • Up to 1024-bit key length – 128-bit pack
  • Symmetric (Bulk) Encryption Algorithms
    • 56-bit key length – 56-bit pack
    • 128-bit key length – 128-bit pack
  • SSL Encryption
    • HTTP connection from Nokia Server using SSL
comparison of wap gateways

Proxy Services

Security Supported

Traffic Interfaces

O & M Interfaces

Ericsson Proxy 1.0

Push, Pull, Push+Pull

WTLS class 1, 2 & 3

SSL v2 /v3 & TLS 1.0

WAP 2.0 Pull

WAP 1.2.1Push

HTTP 1.0/1.1,etc

SNMP, FTP XML, ASCII, CAI

Nokia Activ Server 2.1

WAP Push

WTLS

(128-bit SSL)

WAP 1.2.1

HTTP 1.0/1.1

SNMP

WAP Manager

Server Manager

Jinny

Push

128-bit SSL

WAP Push

-

Exomi 3.0

Push

 WTLS class 1 & 2

SSL v2/v3 & TLS 1.0

 WAP Push

HTTP 1.0/1.1

 SNMP,

Web console

Antinav’s

aveAccess

Push

WTLS / SSL

WAP Push

HTTP

-

Comparison of WAP Gateways

.

comparison of wap gateways1

Platform

Protocols Stacks

Mark-up Languages

Scalability

Networks supported

Ericsson Proxy 1.0

Sun Solaris

WAP 2.0

HTTP 1.0/1.1

WML, HTML, XHTML, SMIL

Compact HTML

Single Node,

Cluster

Network Independent

Nokia Activ Server 2.1

WinNT, 2000

HPUX/Solaris

WAP 1.2.1

June 2000

WML, HTML

WMLScript

Single Node,

Cluster

GSM, TDMA, CDMA, GPRS

Jinny

Linux

Sun Solaris

WAP (1.2.1)

WML, HTML

WML Script

-

GPRS, SMS

CSD & IS36

Exomi 3.0

Sun

Solaris 7 or 8

 WAP 1.2.1

( some WAP 2.0)

 WML, HTML

WMLScript

 Single Node,

Cluster

Mobile and TCP/IP bearer

Antinav’s

aveAccess

Independent

(Java-based)

WAP ?

HTTP

WML, HTML

WML Script

-

All Mobile & IP bearer

Comparison of WAP Gateways

.

wap 1 x and wap 2 0
WAP 1.x and WAP 2.0
  • The WAP gap
  • WTLS
  • SSL/ TLS
  • WP-TCP in WAP 2.0
  • WP-HTTP in WAP 2.0
references
References:
  • “Make your business mobile with the Nokia Activ Server 2.1”, Nokia Mobile Phones, www.nokia.com/corporate/wap
  • “Nokia WAP Server 1.1 Security Pack”, Nokia Mobile Phones www.nokia.com/corporate/wap
  • “Ericsson Mobile Internet Enabling Proxy 1.0”, Ericsson Radio Systems AB, www.ericsson.com
  • Product data sheet, Jinny WAP Gateway, www.jinny.ie
  • “WAP Gateway 3.0”, Exomi Oy, www.exomi.com
  • “aveAccess WAP Gateway”, Atinav Corporation, www.atinav.com
  • “WAP 2.0 Technical White Paper”, WAP Forum,www.wapforum.org, January 2002
