  1. Basic Star I Controller Sales Training Module

  2. NexSentry Star I Controller • What is the NexSentry Star I Controller? • Multiple technology support • Modular components facilitate customization, expansion • Flexible wiring options allow easy installation, conversion • Save by integrating with current network

  3. What is the Star I Controller? • Advanced technology controller • Embedded Intel 32-bit Intel processor provides fast, dependable security • Affordable • 2-door standard controller for small applications • 4 and 8-door Personality Chips for larger installations • Convertible to Star II with Flash Memory upgrade • Control up to 100,000 cardholders without host

  4. Modular components facilitate system customization, expansion • Easily integrate a custom solution for each application • MIRO 16/8, MIRO 32/0, MIRO 64/0, MIRO 2/24,MIRO 4/2, WIRO Wiegand Interface Unit with 8/4 I/O • Analog Proximity System conversion components • 4-State monitor inputs • Greater security • Distinguish between Clear, Active, Open and Short

  5. Flexible wiring options allow easy installation, conversion • Twisted-pair wiring is easy, economical • Standard daisy chain configuration of readers and MIROs: • Most economical for most installations • Home Run Wiring for up to 8 readers: • Allows spec. compliance when star network (Home Run) configuration is required • Extra long wire runs with up to 4,000 feet between controller and readers

  6. 4100 Family ACU Applications • Star I with 2 DKR Readers, Home Run Wiring • Star I with 4 DKR Readers, Home Run Wiring • Star I with 4 DKR Readers, Multi Drop Wiring • Star I with 6 DKR Readers, Multi Drop Wiring • Star I with NexStar and 8 DKR Readers, Home Run Wiring

  7. NexSentry Manager Security management system with NexWatch quality and Windows NT 4 ease-of-use

  8. What is NexSentry Manager? • An access control and alarm management system • powerful and flexible • makes complex tasks easy • NexWatch quality • Microsoft Windows NT power

  9. NSM Client/Server HUB Report Log NSM Client NSM Client Modular Components for Easy Configuration

  10. Flexible • Client/server design • Open Database Connectivity (ODBC Database) Access • Conforms to most standard networking protocols: • TCP/IP, PPP, IPX/SPX and NETBIOS

  11. Interactive maps • Visual status of any location in a system • Accepts standard graphic formats • Bit Map • Auto Cad output to .bmp.jpg.gif • Control through the map • Unlock/Lock Doors • Operate Cameras • Control Equipment

  12. StarGaze Linux Host Linux Open Code Operating System ACU or Host Access Decisions Extensive Event / Task Relationships DataCard Badging Integration CCTV and Elevator Control Interface
