Error Patterns in MLC NAND Flash Memory:Measurement, Characterization, and Analysis

Yu Cai1, Erich F. Haratsch2 , Onur Mutlu1 and Ken Mai1

  • DSSC, ECE Department, Carnegie Mellon University
  • LSI Corporation
evolution of nand flash memory
Evolution of NAND Flash Memory
  • Flash memory widening its range of applications
    • Portable consumer devices, laptop PCs and enterprise servers

CMOS scaling

More bits per Cell

Seaung Suk Lee, “Emerging Challenges in NAND Flash Technology”, Flash Summit 2011 (Hynix)

reliability and endurance challenges for nand flash memories
Reliability and Endurance Challenges for NAND Flash Memories
  • Endurance continues to deteriorate
    • Only a few thousand reliable P/E cycles of NAND Flash memory
  • Error correction capability requirements of ECC keep increasing
  • Big gap between MLC flash endurance and storage reliability requirements
    • Enterprise storage needs >50k P/E cycles
future nand flash storage architecture
Future NAND Flash Storage Architecture

Raw Bit

Error Rate

Memory

Signal

Processing

Error

Correction

BER < 10-15

Noisy

  • Read voltage adjusting
  • Data scrambler
  • Data recovery
  • Soft-information estimation
  • Hamming codes
  • BCH codes
  • Reed-Solomon codes
  • LDPC codes
  • Other Flash friendly codes

Need to understand NAND flash error patterns

test system infrastructure
Test System Infrastructure

Algorithms

Wear Leveling

Address Mapping

Garbage Collection

ECC

(BCH, RS, LDPC)

  • Reset
  • Erase block
  • Program page
  • Read page

Control

Firmware

Signal Processing

Software Platform

USB

PHYChip

FPGA

USB controller

NAND

Controller

Flash

Memories

USB Driver

Host USB PHY

Host Computer

USB Daughter Board

Mother Board

Flash Board

nand flash testing platform
NAND Flash Testing Platform

USB Daughter Board

USB Jack

HAPS-52 Mother Board

Virtex-II Pro

(USB controller)

NAND Daughter Board

3x-nm

NAND Flash

Virtex-V FPGA

(NAND Controller)

nand flash usage and error model
NAND Flash Usage and Error Model

Read Errors

Retention Errors

Program Errors

Erase Errors

Read Errors

Retention Errors

Start

P/E cycle n

P/E cycle i

P/E cycle 0

Erase

Block

Program

Page

(Page0 - Page128)

Retention1

(t1 days)

Retention j

(tj days)

Read

Page

Read

Page

End of life

testing methodology
Testing Methodology
  • Erase errors
    • Count the number of cells that fail to be erased to “11” state
  • Program interference errors
    • Compare the data immediately after page programming and the data after the whole block being programmed
  • Read errors
    • Continuously read a given block and compare the data between consecutive read sequences
  • Retention errors
    • Compare the data read before retention and after retention
      • Characterize short term retention errors under room temperature
      • Characterize long term retention errors by baking in the oven under 125℃
flash error rates comparison
Flash Error Rates Comparison
  • Error rate increases with P/E cycles
  • Retention errors are the most dominant errors
  • Retention error rates increase as retention time increase

retention errors

retention error mechanism
Retention Error Mechanism
  • Electrons loss from the floating gate causes retention errors
    • Cells with more programmed electrons suffer more from retention errors
    • Threshold voltage is more likely to shift one interval than multiple intervals

LSB/MSB

Stress Induced Leakage Current (SILC)

Floating

Gate

REF2

REF1

REF3

10

00

11

01

Vth

Erased

Fully programmed

retention error value dependency 3 months
Retention Error Value Dependency (3 months)
  • Cells with more programmed electrons tend to suffer more from retention noise (i.e. 00 and 01)

01 10

00 01

2 bit mlc background overview
2-bit MLC Background Overview
  • Internal Architecture of 2-bit NAND Flash Memory

LSB-Even Page Sets

LSB-Odd Page Sets

MSB-Even Page Sets

MSB-Odd Page Sets

retention error location dependency
Retention Error Location Dependency
  • LSB page has less BER

Even Page Cells

Odd Page Cells

  • Even pages have less BER

REF1

REF3

REF2

LSB/MSB

00

10

01

11

Vth

program interference
Program interference
  • Program interference errors are caused by extra electrons injection when programming neighbor cells
    • Cells with less programmed electrons suffer more from interference errors
    • Threshold voltage is less likely to shift up more than one level

LSB/MSB

Additional Electrons Injected

Floating

Gate

REF2

REF1

REF3

10

11

01

00

VT

Erased

Fully programmed

program interference error value dependency
Program Interference Error Value Dependency
  • Cells with less programmed electrons tend to suffer more from neighboring cell interference (i.e. 11 and 10)

10  01

11  10

program interference error location dependency
Program Interference Error Location Dependency
  • Program interference errors appear in even-MSB pages
  • BER of bottom pages are orders of magnitude higher
write interference on bottom wordline
Write Interference on bottom wordline
  • Potential of drain edge of SGS transistor is raised by channel boosting
  • Electrons are accelerated between SGS and WL0 and are quite possible to injected into the floating gate of WL0
  • HCI noise generated by source/drain hot-electrons in WL0
  • Threshold voltage of cells on WL0 shift right and it can even shift across more than one level (e.g. 11->01 or 00)

0 V

Vpgm(20V)

Vpass(10V)

Vpass(10V)

Vdd

Vdd

bitline

SGD

WL n

WL31

SGS

WL0

GND

10 V

Channel Voltage

0 V

-

read error analysis
Read Error Analysis

Floating

Gate

Erased

Fully programmed

REF2

REF1

REF3

10

00

11

01

VT

erase errors analysis
Erase Errors Analysis

0 V

  • Continuous erases can significantly reduce errors
    • remove residual electrons

n+

n+

+18 V

conclusions future work
Conclusions & Future work
  • Flash errors could show up for any operations
    • Erase error, program error, retention error and read error
  • Retention errors are the most dominant errors
  • Flash errors show explainable error patterns
    • Cycle-dependency, value-dependency and location-dependency
  • Understanding of modern flash memory error patterns will enable designing effective error tolerance mechanisms
    • Value-asymmetry aware coding techniques
    • Cell location-aware wear leveling mechanisms
