  1. Introducing a Revolutionary New Composite Tube Structure Technology...

  2. What is IsoGrid Technology? • A Flexible new Design & Processing Technology that permita variety of new product executions to be made. • The Technology was developed to bring new Performance levels to ultra-light composite tubular based structures. • Protected by an Array of Existing and/or Pending Patents. • Available Exclusively through VYATEK SPORTS, INC.

  3. What are the Technical Advantages of IsoGrid Technology? • IsoGrid Technology is designed to enhance the structural integrity of thin-wall structures prone to Buckling related failure modes. • The Array of Integral Monolithic Raised Ribs can be Optimized by using a variety of different Materials, Dimensions and/or Orientations. • The Materials in the Outer Shell region can also be Optimized by using different engineering materials, shapes and sizes.

  4. Why are “I” Beams more Efficient (stiffness/weight) than rectangular beams? AR = 3.0 in2 AI = 0.67 in2 (-78%) IC = 2.25 in4 ICI = 0.95 in4 (-58%) IC/AR = .75 in2 ICI/AI = 1.41 in2(+88%) Because designers can put material Where they need it...and Remove it from where they don’t!

  5. Introducing a Revolutionary New Composite Tube Technology: IsoGrid Technology enhances “Tube” Beam performance like an I-Beam does! At = 0.283 in2 Ai* = 0.178 in2 (-37%) Ic = 0.029 in4 Ic* = 0.020 in4 (-31%) Ip = 0.058 in4 Ip* = 0.040 in4 (-31%) Ic/At = 0.10 in2 Ic*/Ai* = 0.11 in2(+10%) Ip/At = 0.20 in2 Ip*/Ai* = 0.22 in2(+10%) This Technology is possible due to Advances in Composite Processing Science!

  6. Introducing a Revolutionary New Composite Tube Technology: 3-Point bend test of non IsoGrid ultra-light shaft design 3-Point bend test of IsoGrid reinforced ultra-light shaft design • Notes: • Both tests done under identical load/support conditions. • Shaft designs vary only by the addition of IsoGrid reinforcement ( approximately 4 gms). • IsoGrid design was slightly stiffer and therefore deflection at identical load was slightly lower.

  7. JEC “Innovation of the Year” (Paris - April 9, 2002) JEC Awards Gallery w/ Strategic Partners

  8. Summary of IsoGrid Technology: • IsoGrid Technology is a new tool to help product designers make parts that contain the following characteristics:1. Lighter2. Stronger3. Stiffer4. Possess unique damping (feel) characteristics • Contact VYATEK SPORTS, INC. @ 480.998.2046 to see if IsoGrid Technology makes sense for your next composite product.
