Presentation Transcript
the akamai platform world s largest on demand distributed computing platform
The Akamai PlatformWorld’s Largest On-DemandDistributed Computing Platform

Always OnNo systemic network failure since inception

Always Available14,000+ servers1,100+ Networks 70 Countries

Always CapableNetwork averages 35Gbps dayPeak 72Gbps 4/15/045B hits/day

Always SecureSecurity at the physical, host, network, and software layers

Always EvolvingObjects, whole sites, streaming, secure content, applications

Predictable Performance

Scalability On Demand

Increased Security

slide4

Akamai Performance and

Reliability Impact for

State of Iowa

performance reliability testing methodology
Performance/Reliability Testing Methodology
  • Use of 3rd party web performance monitoring service by Keynote Systems, Inc.
  • 20+ Keynote “agents” spread around the US downloading exact same Iowa.gov and Iowa Education web content with and without Akamai
  • Download times and any errors (e.g. connection timeout) are recorded
akamai performance impact on iowa gov homepage
Akamai Performance Impact on Iowa.gov Homepage

Without Akamai

0.7 sec vs. 2.1 sec (3.0x faster on average)

(4.8x faster during peak)

With Akamai

Total Data Points Collected: over 16,000

akamai performance impact on iowa gov network perspective
Akamai Performance Impact on Iowa.gov(Network Perspective)

With Akamai – Green; Without Akamai - Orange

akamai reliability impact on iowa gov homepage
Akamai Reliability Impact on Iowa.gov Homepage

Total errors without Akamai – 200

Total errors with Akamai – 16

Error reduction – 92%

(Errors include request timeout, page timeout, connection timeout, content error, etc.)

akamai performance impact on iowa education homepage
Akamai PerformanceImpact on IowaEducation Homepage

Without Akamai

0.41 sec vs. 1.17 sec (2.9x faster on average)

(4.3x faster during peak)

With Akamai

Total Data Points Collected: over 14,000

akamai reliability impact on iowa education homepage
Akamai ReliabilityImpact on IowaEducation Homepage

Total errors without Akamai – 184

Total errors with Akamai – 12

Error reduction – 93%

(Errors include request timeout, page timeout, connection timeout, content error, etc.)

akamai performance impact on iowa education network perspective
Akamai PerformanceImpact on Iowa Education(Network Perspective)

With Akamai – Green; Without Akamai - Orange

akamai performance impact on iowaroad conditions org
Akamai Performance Impact on IowaRoad Conditions.org

Without Akamai

0.8 sec vs. 5.4 sec (6.8x faster on average)

With Akamai

Total Data Points Collected: over 1,000

akamai performance impact on iowaroad conditions org network perspective
Akamai Performance Impact on IowaRoad Conditions.org(Network Perspective)

With Akamai – Green; Without Akamai - Orange

akamai reliability impact on iowaroad conditions org
Akamai Reliability Impact on IowaRoad Conditions.org

Total errors without Akamai – 4

Total errors with Akamai – 1

Error reduction – 75%

(Errors include request timeout, page timeout, connection timeout, content error, etc.)

edge platform basics
Edge Platform Basics

Web Server

Maintained by Customer

for publishing content

Whole Site,

Streaming, Forms

End Users

Akamai Edge Servers

Origin Server

  • Information Delivery:
  • Whole Site
  • Streaming
availability without akamai
Availability – Without Akamai

AT&T

Genuity

WorldCom

Qwest

UUNET

Cable &

Wireless

Sprint

SBC

www.colorado.gov

AOL

Level 3

PeeringPoints

Network Providers

EndUsers

availability with akamai
Availability – With Akamai

Akamai

Storage

Back-up Site

Option 1

Option 2

End

Users

Primary

www.colorado.gov

Akamai

Edge Server

Network Providers

PeeringPoints

the akamai proposal
The Akamai Proposal

25 month contract for price of 24
