p2p sip peer to peer internet telephony using sip

P2P-SIPPeer to peer Internet telephony using SIP

Kundan Singh and Henning Schulzrinne

Columbia University, New York

June 2005

http://www.cs.columbia.edu/IRT/p2p-sip

overview
Introduction

What is P2P? and SIP? Why P2P-SIP?

Architecture

SIP using P2P vs P2P over SIP; Components that can be P2P

Implementation

Choice of P2P (DHT); Node join, leave; message routing

Conclusions and future work

Overview

Total 33 slides

what is p2p

Communication and collaboration

Computer systems

Magi

Groove

Skype

Centralized

Distributed

mainframes

workstations

Peer-to-peer

Client-server

Napster

Gnutella

Kazaa

Freenet

Overnet

C

C

P

P

Flat

Hierarchical

Pure

Hybrid

RPC

HTTP

DNS

mount

Gnutella

Chord

S

Napster

Groove

File sharing

Kazaa

C

C

P

P

SETI@Home

folding@Home

C

P

Distributed computing

What is P2P?
  • Share the resources of individual peers
    • CPU, disk, bandwidth, information, …
p2p goals
Resource aggregation - CPU, disk, …

Cost sharing/reduction

Improved scalability/reliability

Interoperability - heterogeneous peers

Increased autonomy at the network edge

Anonymity/privacy

Dynamic (join, leave), self organizing

Ad hoc communication and collaboration

Definition fuzzy

both client and server?

true for proxy

no need for central server

true for SIP-based media

SIP can be e2e

proxy functions distributed among end systems

P2P goals
distributed hash table dht
Distributed Hash Table (DHT)
  • Types of search
    • Central index (Napster)
    • Distributed index with flooding (Gnutella)
    • Distributed index with hashing (Chord)
  • Basic operations

find(key), insert(key, value), delete(key),

but no search(*)

why p2p sip

REGISTER

INVITE alice

P2P overlay

Alice

128.59.19.194

128.59.19.194

No central server, search latency

Why P2P-SIP?

REGISTER

alice@columbia.edu =>128.59.19.194

INVITE alice@columbia.edu

Contact: 128.59.19.194

Alice’s host

128.59.19.194

Bob’s host

columbia.edu

Client-server=> maintenance, configuration, controlled infrastructure

how to combine sip p2p
SIP-using-P2P

Replace SIP location service by a P2P protocol

P2P-over-SIP

Additionally, implement P2P using SIP messaging

How to combine SIP + P2P?

P2P network

REGISTER

INVITE alice

FIND

INSERT

P2P-SIP

overlay

Alice

128.59.19.194

INVITE sip:alice@128.59.19.194

Alice

128.59.19.194

sip using p2p
SIP-using-P2P
  • Reuse optimized and well-defined external P2P network
  • Define P2P location service interface to be used in SIP
  • Extends to other signaling protocols
p2p over sip
P2P-over-SIP
  • P2P algorithm over SIP without change in semantics
  • No dependence on external P2P network
  • Reuse and interoperate with existing components, e.g., voicemail
  • Built-in NAT/media relays
  • Message overhead
what else can be p2p
What else can be P2P?
  • Rendezvous/signaling
  • Configuration storage
  • Media storage
  • Identity assertion (?)
  • Gateway (?)
  • NAT/media relay (find best one)
our p2p sip approach
Our P2P-SIP approach
  • Unlike server-based SIP architecture
  • Unlike proprietary Skype architecture
    • Robust and efficient lookup using DHT
    • Interoperability
      • DHT algorithm uses SIP communication
    • Hybrid architecture
      • Lookup in SIP+P2P
  • Unlike file-sharing applications
    • Data storage, caching, delay, reliability
  • Disadvantages
    • Lookup delay and security
background dht chord

0 1 2 3 4 5 6 7 8

Background: DHT (Chord)
  • Identifier circle
  • Keys assigned to successor
  • Evenly distributed keys and nodes
  • Finger table: logN
    • ith finger points to first node that succeeds n by at least 2i-1
  • Stabilization for join/leave

1

54

8

58

10

14

47

21

42

38

32

38

24

30

design alternatives

d471f1

1

d467c4

d46a1c

8

d462ba

58

54

d4213f

14

10

47

21

Route(d46a1c)

d13da3

42

38

32

65a1fc

38

24

30

Design alternatives

servers

1

54

10

38

24

30

clients

Use DHT in server farm

Use DHT for all clients - but some are resource limited

Use DHT among super-nodes

Hierarchy

Dynamically adapt

architecture of prototype

Discover

DHT (Chord)

User location

Audio devices

User interface (buddy list, etc.)

ICE

RTP/RTCP

Codecs

SIP

Architecture of prototype

Signup,

Find buddies

IM,

call

On reset

Signout,

transfer

On startup

Leave

Find

Join

REGISTER,

INVITE,

MESSAGE

Peer found/

Detect NAT

Multicast REGISTER

REGISTER

SIP-over-P2P

P2P-using-SIP

naming and authentication
Naming and authentication
  • SIP URI as node and user identifiers
    • Known node: sip:15@192.2.1.3
    • Unknown node: sip:17@example.com
    • User: sip:alice@columbia.edu
  • User name is chosen randomly by the system, by the user, or as user’s email
  • Email the randomly generated password
    • TTL, security
sip messages
SIP messages

1

  • DHT (Chord) maintenance
    • Query the node at distance 2k with node id 11

REGISTER

To: <sip:11@example.invalid>

From: <sip:7@128.59.15.56>

SIP/2.0 200 OK

To: <sip:11@example.invalid>

Contact: <sip:15@128.59.15.48>; predecessor=sip:10@128.59.15.55

    • Update my neighbor about me

REGISTER

To: <sip:1@128.59.15.60>

Contact: <sip:7@128.59.15.56>; predecessor=sip:1@128.59.15.60

10

22

7

15

Find(11) gives 15

sip messages1
SIP messages
  • User registration

REGISTER

To: sip:alice@columbia.edu

Contact: sip:alice@128.59.19.194:8094

  • Call setup and instant messaging

INVITE sip:bob@example.com

To: sip:bob@example.com

From: sip:alice@columbia.edu

node startup

sipd

DB

Node startup

columbia.edu

  • SIP
    • REGISTER with SIP registrar
  • DHT
    • Discover peers: multicast REGISTER
      • SLP, bootstrap, host cache
    • Join DHT using node-key=Hash(ip)
      • Query its position in DHT
      • Update its neighbors
      • Stabilization: repeat periodically
    • User registers using user-key=Hash(alice@columbia.edu)

REGISTER

alice@columbia.edu

Detect peers

REGISTER alice=42

58

42

12

14

REGISTER bob=12

32

node leaves
Node leaves
  • Chord reliability
    • Log(N) successors, replicate keys
  • Graceful leave
    • Un-REGISTER
    • Transfer registrations
  • Failure
    • Attached nodes detect and re-REGISTER
    • New REGISTER goes to new super-nodes
    • Super-nodes adjust DHT accordingly

REGISTER key=42

REGISTER

OPTIONS

DHT

42

42

implementation

1

30

26

9

19

11

Implementation

31

  • sippeer: C++, Unix (Linux), Chord
    • Node join and form the DHT
    • Node failure is detected and DHT updated
    • Registrations transferred on node shutdown

29

31

25

26

15

adaptor for existing phones
Adaptor for existing phones
  • Use P2P-SIP node as an outbound proxy
  • ICE for NAT/firewall traversal
    • STUN/TURN server in the node
hybrid federated architecture
Hybrid (federated) architecture
  • Cross register, or
  • Locate during call setup
    • DNS, or
    • P2P-SIP hierarchy
evaluation scalability
Evaluationscalability
  • #messages depends on
    • Keep-alive and finger table refresh rate
    • Call arrival distribution
    • User registration refresh interval
    • Node join, leave, failure rates

M={rs+ rf(log(N))2} + c.log(N) + (k/t)log(N) + (log(N))2/N

  • #nodes = f(capacity,rates)
    • CPU, memory, bandwidth
  • Verify by measurement and profiling
evaluation reliability and call setup latency
Evaluationreliability and call setup latency
  • User availability depends on
    • Super-node failure distribution
    • Node keep-alive and finger refresh rate
    • User registration refresh rate
    • Replicate user registration
    • Measure effect of each
  • Call setup latency
    • Same as DHT lookup latency: O(log(N))
      • Calls to known locations (“buddies”) is direct
      • DHT optimization can further reduce latency
    • User availability and retransmission timers
    • Measure effect of each
p2p vs server based sip
P2P vs. server-based SIP
  • Prediction:
    • P2P for smaller & quick setup scenarios
    • Server-based for corporate and carrier
  • Need federated system
    • multiple p2p systems, identified by DNS domain name
    • with gateway nodes

2000 requests/second ≈7 million registered users

explosive growth further study
Explosive growth (further study)
  • Cache replacement at super-nodes
    • Last seen many days ago
    • Cap on local disk usage (automatic)
  • Forcing a node to become super node
  • Graceful denial of service if overloaded
  • Switching between flooding, CAN, Chord, …
  • . . .
more open issues further study
More open issues (further study)
  • Security
    • Anonymity, encryption
    • Attack/DOS-resistant, SPAM-resistant
    • Malicious node
    • Protecting voicemails from storage nodes
  • Optimization
    • Locality, proximity, media routing
  • Deployment
    • SIP-P2P vs P2P-SIP, Intra-net, ISP servers
  • Motivation
    • Why should I run as super-node?
catastrophic failure
Catastrophic failure
  • Server redundancy is well-understood  can handle single-server failures
  • Catastrophic (system-wide) failure occurs when common element fails
  • Both server-based and P2P:
    • all servers crash based on client stimulus (e.g., common parser bug)
  • Traditional server-based system:
    • servers share same facility, power, OS, …
  • P2P system
    • less likely
    • share same OS?
conclusions

d471f1

d467c4

d46a1c

d462ba

d4213f

763

427

C

C

P

P

S

364

123

Route(d46a1c)

d13da3

324

C

C

P

P

365

135

564

65a1fc

C

P

Conclusions
  • P2P useful for VoIP
    • Scalable, reliable
    • No configuration
    • Not as fast as client/server
  • P2P-SIP
    • Basic operations easy
      • Implementation
        • sippeer: C++, Linux
      • Interoperates
    • Some potential issues
      • Security
      • Performance

http://www.p2psip.org/

http://www.cs.columbia.edu/IRT/p2p-sip
