tapering optimizations for tw level superconducting undulators summary of simulation results
Tapering optimizations for TW level superconducting undulators: summary of simulation results
  • Claudio Emma, Paul Emma, Claudio Pellegrini, Juhao Wu
  • SLAC
  • July 2014
simulation parameters and tapering optimisation
Simulation parameters and tapering optimisation

ρ=9.8535*10-4 Lg1D = 89 cm

Ming-Xie Parametrization

  • Kq,0 = 47.5 T/m
  • Lg3d = 0.99 m
time dependent results parabolic
Time Dependent Results (parabolic)
  • Time dependent effects do not spoil bunching
  • as they do after 200 m in NCU
radiation and coherence properties
Radiation and Coherence Properties
  • Coherence area
  • much larger than
  • radiation beam spot size
