Presentation Transcript


  1. ASISTENTE PRODUCTOS FINALES

  2. Proceso Pre-Definido REDUCIR DATOS: • REDUCIR • REDUCCION TRANSVERSAL • SELECCION MONOHAZ: • MAPPER • Sin Reducción Datos Isóbatas: • Si • No HYPLOT PLTs, con o sin Plantillas PLT) Datos Editados: *.LOG O *.XYZ SB O MB REPORTERO CONDICION CANAL: Archivo Diseño EDITOR ENC Pronto! CONDICION CANAL REPORTE en PDF Sobrepuesta Profundidades S-57 PDFs o GeoTIFs

  3. Asistente Productos Finales

  4. Archivos y Marco Proceso Agregar/Remover Archivos de Datos Editados • EDT/LOG • HS2x/LOG • XYZ • Salve sus parámetros como un “Proceso”.Un proceso incluye su Selección de Sondajes y Parámetros de Isóbatas, junto con sus archivos de fondo seleccionados. • Listo?Entonces presione el botón “EJECUTAR - RUN”

  5. Marco Selección de Sondajes Parámetros cambiarán con base en el Método de Reducción. “Ninguno” es una opción si ya tiene reducidos sus datos.

  6. Marco Isóbatas Isóbatas pueden ser generadas.La rutina es la misma que en MODELO TIN. Sí ya ha creado sus isóbatas, puede agregarlas como un archivo de fondo.Hacer isóbatas en el ASISTENTE PRODUCTOS FINALES es opcional!

  7. Generando Hojas De Ploteo Agregue una Hoja de Ploteo (*.PLT) o múltiples hojas de ploteo. Aplicar un Archivo Plantilla Hojas de Ploteo (*.HYT) a un PLT o a varios PLTs. Seleccione sus Archivos de Fondo que desea incluir. Salida PDF o GeoTIF con resolución definida por el usuario. Generar Hojas De Ploteo es opcional!

  8. Generando Reportes de Condición Canal Necesita crear un Reporte Diseño Canal (*.RPT) en el REPORTERO CONDICION CANAL. Habilite la rutina y entre el nombre del archivo *.RPT. Listo! Hacer el reporte es opcional.
