This article explores the decay of transverse magnetization and the recovery of longitudinal magnetization in MRI using inversion recovery techniques. The characteristic time constants, T1 and T2, as well as different echo times (TE) and inversion times (TI) are analyzed. The article also discusses the contrast between T1-weighted (IR) and T2-weighted (SE) images in the brain.

msykes
Download Presentation

Exponential decay

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. Exponential decay  = 30 ms Inversion Recovery

  2. T2: decay of transverse magnetization after excitation TE = 15 ms TE = 20 ms  = T2= 30 ms T2= 50 ms TE = 30 ms TE = 60 ms Inversion Recovery

  3. Inversion Recovery B0 180º Longitudinal magnetization relaxes back to equilibrium with characteristic time constant, T1 M|| Inversion Recovery

  4. Negative magnetization looks like positive magnetization in magnitude images T1 Inversion recovery T1= 900 ms T1= 1100 ms T1= 2000 ms TI = 50 ms 100 ms 400 ms 800 ms 1600 ms 3200 ms 4800 ms Inversion Recovery

  5. Contrast in the brain T1 (IR) T2 (SE) Inversion Recovery
