Rate of reaction and activation energy

Rate of reaction and activation energy. The rate of reaction is defined as the change in concentration of reactants (or products) per unit time.

mozellaj
Download Presentation

Rate of reaction and activation energy

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript


  1. Rate of reaction and activation energy The rate of reaction is defined as the change in concentration of reactants (or products) per unit time. The activation energy for a reaction is the minimum amount of energy that particles need to have if a collision between them is to result in a reaction. Reactionsoccur when reactant particles collide with a minimum amount of energy called the activation energy.

  2. Factors affecting rate of reaction

  3. Rates: true or false?

  4. Measuring rates of reaction concentration of reactants concentration of products time time To measure the rate of reaction, we need to be able to measure either how quickly the reactants are used up or how quickly the products are formed. The method used for measuring depends on the substances involved. If a graph of concentration or volume of products or reactants is plotted against time, the gradient will be the rate of reaction.

  5. Measuring rates

  6. Rates of reaction: testing

  7. The rate equation Rate = k[A]m[B]n m + n = overall order of the reaction The rate equation is an equation that relates the concentrations of substances involved in a reaction to the rate of the reaction. For the reaction A + B C the rate of reaction depends on the concentrations of A and B ([A] and [B]) and various constants in the following way: • k is the rate constant (units depend of values of m and n) • m is the order of reaction with respect to A • n is the order of reaction with respect to B.

  8. Determining the rate equation A + B C The rate equationcan be determined by completing a series of experiments varying the concentrations of each of the reactants. To determine how [A] affects the rate, several different experiments can be carried out in which [B] is kept constant and [A] is changed. The data can then be used to work out the relationship between rate and [A]. A similar set of experiments can be carried out keeping [A] constant and varying [B] to determine how changing [B] affects the rate of reaction.

  9. Orders of reaction

  10. Orders of reaction: summary

  11. The effect of temperature on k When temperature increases, rate of reaction increases. This is because the rate constant, k, increases with temperature. rate constant, k (moldm3s–1) temperature (K) k (moldm3s–1) temp. (K) 556 4.45 × 10–5 575 1.37 × 10–4 629 2.52 × 10–3 666 1.41 × 10–2 700 6.43 × 10–2 781 1.34

  12. Rate equations: true or false?

  13. Example rate calculations

  14. Rate calculations

  15. Rate determining step BrO3– + 6H+ + 5Br– 3Br2 + 3H2O Many reactions take place using more than one step. In a reaction such as this one, it is highly unlikely that all three reactant particles will collide at the same time. It is more likely that this reaction will take place in a number of steps that involve other species, called intermediates. In a multi-step reaction, the slowest step is called therate determining step. Any step that occurs after the rate determining step will not affect the rate of reaction, and therefore will not appear in the rate equation.

  16. More about the rate determining step

  17. The rate equation and mechanisms

  18. Rate determining step: questions

  19. Glossary

  20. What’s the keyword?

  21. Multiple-choice quiz
