building the perfect sharepoint 2010 farm best practises from the field

SESSION CODE: OFS306

Michael Noel

Partner

Convergent Computing

Building the ‘Perfect’ SharePoint 2010 FarmBest Practises from the Field

(c) 2011 Microsoft. All rights reserved.

michael noel
Michael Noel

Sydney

Brisbane

Canberra

Tasmania

Katoomba

Skippy

Hungry

Quokkas

Bondi

Melbourne

12 (11)

Apostles

Adelaide

Perth

Great to be back in Beautiful Australia!

what we will cover
What we will cover
  • Examine various SharePoint 2010 farm architecture best practisesthat have developed over the past year
  • Examine SharePoint Best Practice Farm Architecture
  • Understand SharePoint VirtualisationOptions
  • Explore SharePoint DR and HA strategies using Database Mirroring
  • Explore other common best practises (RBS, SSL, NLB)
  • Examine best practice security for SharePoint
  • A large amount of best practisescovered (i.e. Drinking through a fire hose,) goal is for you to be able to take away at least 2-3 useful pieces of information that can be used in your environment
slide7

Architecting the FarmSmall Farm Examples

  • ‘All-in-One’ (Avoid)
  • DB and SP Roles Separate
slide8

Architecting the FarmSmallest Highly Available Farm

  • 2 SharePoint Servers running Web and Service Apps
  • 2 Database Servers (Clustered or Mirrored)
  • 1 or 2 Index Partitions with equivalent query components
  • Smallest farm size that is fully highly available
slide9

Architecting the FarmBest Practice ‘Six Server Farm’

  • 2 Dedicated Web Servers (NLB)
  • 2 Service Application Servers
  • 2 Database Servers (Clustered or Mirrored)
  • 1 or 2 Index Partitions with equivalent query components
slide10

Architecting the FarmScaling to Large Farms

  • Multiple Dedicated Web Servers
  • Multiple Dedicated Service App Servers
  • Multiple Dedicated Query Servers
  • Multiple Dedicated Crawl Servers, with multiple Crawl DBs to increase parallelisation of the crawl process
  • Multiple distributed Index partitions (max of 10 million items per index partition)
  • Two query components for each Index partition, spread among servers
slide11

Architecting the FarmFAST Search

  • Previously a third party product ($$$$)
  • More reasonable pricing now
  • Highly tuned and specialised search engine for SharePoint and also as an enterprise search platform
  • Replaces SharePoint 2010 Native Search if used
  • ‘Net new’ features built-in.
slide17

Virtualisation of SharePoint ServersSample 1: Small Single Server Environment / No HA

  • Allows organisations that wouldn’t normally be able to have a test environment to run one
  • Allows for separation of the database role onto a dedicated server
  • Can be more easily scaled out in the future
slide18

Virtualisation of SharePoint ServersSample 2: Two Server Highly Available Farm

  • High-Availability across Hosts
  • All components Virtualised
  • Uses only two Windows Ent Edition Licenses
slide19

Virtualisation of SharePoint ServersSample 3: Mix of Physical and Virtual Servers – Best Perf

  • Highest transaction servers are physical
  • Multiple farm support, with DBs for all farms on the SQL cluster
slide21

Virtualisation of SharePoint ServersVirtualisation Performance Monitoring

  • Processor (Host Only)
    • <60% Utilisation= Good
    • 60%-90% = Caution
    • >90% = Trouble
  • Available Memory
    • 50% and above = Good
    • 10%-50% = OK
    • <10% = Trouble
  • Disk – Avg. Disk sec/Read or Avg. Disk sec/Write
    • Up to 15ms = fine
    • 15ms-25ms = Caution
    • >25ms = Trouble
  • Network Bandwidth – Bytes Total/sec
    • <40% Utilisation = Good
    • 41%-64% = Caution
    • >65% = Trouble
  • Network Latency - Output Queue Length
    • 0 = Good
    • 1-2= OK
    • >2 = Trouble
slide22

Virtualisation of SharePoint ServersQuick Farm Provisioning using VMM/Virtual Center

  • Create new Virtual Guest (Windows Server 2008 R2)
  • Install SP2010 Binaries. Stop before running Config Wizard
  • Turn Virtual Guest into Template, modify template to allow it to be added into domain
  • Add PowerShell script to run on first login, allowing SP to be added into farm or to create new farm

End Result - 15 minute entire farm provisioning…quickly add servers into existing farms or create new farms (Test, Dev, Prod) on demand

slide25

Data ManagementDistribute Data Across Content DBs and Site Collections

  • Start with a distributed architecture of content databases from the beginning, within reason (more than 50 per SQL instance is not recommended)
  • Distribute content across Site Collections from the beginning as well, it is very difficult to extract content after the face
  • Allow your environment to scale and your users to ‘grow into’ their SharePoint site collections
slide27

Data ManagementBinary Large OBject (BLOB) Storage

  • BLOBs are unstructured content stored in SQL
  • Includes all documents, pictures, and files stored in SharePoint
  • Excludes Metadata and Context, information about the document, version #, etc.
  • Until recently, could not be removed from SharePoint Content Databases
  • Classic problem of structured vs. unstructured data – unstructured data doesn’t really belong in a SQL Server environment
slide28

Data ManagementGetting your BLOBs out of the Content DBs

  • Can reduce dramatically the size of Content DBs, as upwards of 80%-90% of space in content DBs is composed of BLOBs
  • Can move BLOB storage to more efficient/cheaper storage
  • Improve performance and scalability of your SharePoint deployment – But highly recommended to use third party
slide30

SQL Database OptimisationContent Databases Distributed Between Multiple Volumes

Volume #1

Volume #2

Volume #3

Volume #4

DB-A

File 1

DB-B

File 1

DB-A

File 2

DB-B

File 2

DB-A

File 3

DB-B

File 3

DB-A

File 4

DB-B

File 4

Tempdb File 1

Tempdb File 2

Tempdb File 3

Tempdb File 4

slide31

SQL Database OptimisationContent Databases Distributed Between Multiple Volumes

  • Break Content Databases and TempDB into multiple files (MDF, NDF), total should equal number of physical processors (not cores) on SQL server.
  • Pre-size Content DBs and TempDB to avoid fragmentation
  • Separate files onto different drive spindles for best IO perf.
  • Example: 100GB total Content DB on Four-way SQL Server would have four database files distributed across four sets of drive spindles = 25GB pre-sized for each file.
slide32

SQL Database OptimisationTempDB Best Practises

  • TempDB is critical for performance
  • Pre-size to 20% of the size of the largest content database.
  • Break into multiple files across spindles as noted
  • Note there is a separate TempDB for each physical instance
  • Note that if using SQL Transparent Data Encryption (TDE) for any databases in an instance, the tempDB is encrypted.
high availability and disaster recovery data tier clustering vs mirroring
High Availability and Disaster RecoveryData Tier – Clustering vs. Mirroring
  • Clustering is Shared Storage, can’t survive storage failure, makes Mirroring more attractive
  • Clustering fails over more quickly
  • Mirroring is not supported for all databases, but Clustering is
  • Both Clustering and Mirroring can be used at the same time (Instance to Instance)
high availability and disaster recovery data tier sql database mirroring
High Availability and Disaster RecoveryData Tier – SQL Database Mirroring
  • Introduced in SQL 2005 SP1
  • Greatly improved in SQL 2008 and now SQL 2008 R2
  • Available in Enterprise and Standard (Synchronous only) editions
  • Works by keeping a mirror copy of a database or databases on two servers
  • Can be used locally, or the mirror can be remote
  • Can be set to use a two-phase commit process to ensure integrity of data across both servers
  • Can be combined with traditional shared storage clustering to further improve redundancy
  • SharePoint 2010 is now Mirroring aware!
slide36

High Availability and Disaster RecoveryData Tier – Database Mirroring Model #1 – Single Site

Single Site

Synchronous Replication

Uses a SQL Witness Server to Failover Automatically

Mirror all SharePoint DBs in the Farm

Use a SQL Alias to switch to Mirror Instance

slide37

High Availability and Disaster RecoveryData Tier – Database Mirroring Model #2 – Cross-Site with HA

Two Sites

1-10 ms Latency max

1Gb Bandwidth minimum

Farm Servers in each location

Auto Failover

slide38

High Availability and Disaster RecoveryData Tier – Database Mirroring Model #2 – Remote Farm

Two Sites

Two Farms

Mirror only Content DBs

Failover is Manual

Read-only Mode possible

Must Re-Attach and Re-Index

slide39

High Availability and Disaster RecoveryData Tier – Database Support for Mirroring – Slide 1 of 2

slide40

High Availability and Disaster RecoveryData Tier – Database Support for Mirroring – Slide 2 of 2

slide41
High Availability and Disaster RecoveryTwo Node/Two Instance Cluster – Take Advantage of both servers
high availability and disaster recovery network load balancing
High Availability and Disaster RecoveryNetwork Load Balancing
  • Hardware Based Load Balancing (F5, Cisco, Citrix NetScaler – Best performance and scalability
  • Software Windows Network Load Balancing fully supported by MS, but requires Layer 2 VLAN (all packets must reach all hosts.) Layer 3 Switches must be configured to allow Layer 2 to the specific VLAN.
  • If using Unicast, use two NICs on the server, one for communications between nodes.
  • If using Multicast, be sure to configure routers appropriately
  • Set Affinity to Single (Sticky Sessions)
  • If using VMware, note fix to NLB RARP issue (http://tinyurl.com/vmwarenlbfix)
high availability and disaster recovery windows software network load balancing recommendations
High Availability and Disaster RecoveryWindows Software Network Load Balancing Recommendations
  • Best Practice – Create Multiple Web Apps with Load-balanced VIPs (Sample below)
    • Web Role Servers
      • sp1.companyabc.com (10.0.0.101) – Web Role Server #1
      • sp2.companyabc.com (10.0.0.102) – Web Role Server #2
    • Clustered VIPs shared between SP1 and SP2 (Create A records in DNS)
      • spnlb.companyabc.com (10.0.0.103) - Cluster
      • spca.companyabc.com (10.0.0.104) – SP Central Admin
      • spsmtp.companyabc.com (10.0.0.105) – Inbound Email VIP
      • home.companyabc.com (10.0.0.106) – Main SP Web App (can be multiple)
      • mysite.companyabc.com (10.0.0.107) – Main MySites Web App
sharepoint installation scripted installations
SharePoint InstallationScripted Installations
  • Good to understand how to install SharePoint from the command-line, especially if setting up multiple servers.
  • Allows for options not available in the GUI, such as the option to rename databases to something easier to understand.
  • Use PowerShell with SharePoint 2010
  • Sample scripts available for download…
sharepoint installation samples scripts http tinyurl com spfarm config
SharePoint InstallationSamples Scripts – http://tinyurl.com/SPFarm-Config

Function Configure-SPSearch {

PARAM($AppPool, $FarmName, $SearchServiceAccount)

$searchServiceInstance = Get-SPEnterpriseSearchServiceInstance -local

Start-SPEnterpriseSearchServiceInstance -Identity $searchServiceInstance

$dbName = $FarmName + "_SearchServiceApplication"

$searchApplication = New-SPEnterpriseSearchServiceApplication -Name "$FarmName Search Service Application" -ApplicationPool $AppPool -DatabaseName $dbName

$searchApplicationProxy = New-SPEnterpriseSearchServiceApplicationProxy -name "$FarmName Search Service Application Proxy" -SearchApplication $searchApplication

Set-SPEnterpriseSearchAdministrationComponent -SearchApplication $searchApplication -SearchServiceInstance $searchServiceInstance

$crawlTopology = New-SPEnterpriseSearchCrawlTopology -SearchApplication $searchApplication

$crawlDatabase = Get-SPEnterpriseSearchCrawlDatabase -SearchApplication $searchApplication

New-SPEnterpriseSearchCrawlComponent -CrawlTopology $crawlTopology -CrawlDatabase $crawlDatabase -SearchServiceInstance $searchServiceInstance

while($crawlTopology.State -ne "Active")

{

$crawlTopology | Set-SPEnterpriseSearchCrawlTopology -Active -ErrorActionSilentlyContinue

if ($crawlTopology.State -ne "Active")

{

Start-Sleep -Seconds 10

}

}

$queryTopology = New-SPenterpriseSEarchQueryTopology -SearchApplication $searchApplication -partitions 1

$searchIndexPartition = Get-SPEnterpriseSearchIndexPartition -QueryTopology $queryTopology

New-SPEnterpriseSearchQueryComponent -indexpartition $searchIndexPartition -QueryTopology $queryTopology -SearchServiceInstance $searchServiceInstance

$propertyDB = Get-SPEnterpriseSearchPropertyDatabase -SearchApplication $searchApplication

Set-SPEnterpriseSearchIndexPartition $searchIndexPartition -PropertyDatabase $propertyDB

while ($queryTopology.State -ne "Active")

{

$queryTopology | Set-SPEnterpriseSearchQueryTopology -Active -ErrorActionSilentlyContinue

if ($queryTopology.State -ne "Active")

{

Start-Sleep -Seconds 10

}

}

}

sharepoint installation some manual service apps still required
SharePoint InstallationSome Manual Service Apps Still Required
  • Due to complexity and/or bugs, certain Service Apps will need to be manually configured in most cases.
  • This includes the following:
    • PerformancePoint Service Application
    • User Profile Service Application
    • Web Analytics Service Application
sharepoint security layers of security in a sharepoint environment
SharePoint SecurityLayers of Security in a SharePoint Environment
  • Infrastructure Security and Best Practises
    • Physical Security
    • Best Practice Service Account Setup
    • Kerberos Authentication
  • Data Security
    • Role Based Access Control (RBAC)
    • Transparent Data Encryption (TDE) of SQL Databases
    • Antivirus
  • Transport Security
    • Secure Sockets Layer (SSL) from Server to Client
    • IPSec from Server to Server
  • Edge Security
    • Inbound Internet Security (Forefront UAG/TMG)
  • Rights Management
sharepoint security infrastructure enable kerberos when using classic auth
SharePoint SecurityInfrastructure – Enable Kerberos when using Classic-Auth
  • When creating any Web Applications in Classic-mode, USE KERBEROS. It is much more secure and also faster with heavy loads as the SP server doesn’t have to keep asking for auth requests from AD.
  • Kerberos auth does require extra steps, which makes people shy away from it, but once configured, it improves security considerably and can improve performance on high-load sites.
  • Should also be configured on SPCA Site! (Best Practice = Configure SPCA for NLB, SSL, and Kerberos (i.e. https://spca.companyabc.com)
sharepoint security data role based access control rbac
SharePoint SecurityData – Role Based Access Control (RBAC)
  • Role Groups defined within Active Directory (Universal Groups) – i.e. ‘Marketing,’ ‘Sales,’ ‘IT,’ etc.
  • Role Groups added directly into SharePoint ‘Access Groups’ such as ‘Contributors,’ ‘Authors,’ etc.
  • Simply by adding a user account into the associated Role Group, they gain access to whatever rights their role requires.

SharePoint Group

sharepoint security data transparent data encryption tde
SharePoint SecurityData - Transparent Data Encryption (TDE)
  • New in SQL Server 2008
  • Only Available with the Enterprise Edition
  • Seamless Encryption of Individual Databases
  • Transparent to Applications, including SharePoint
sharepoint security transport secure sockets layer ssl encryption
SharePoint SecurityTransport - Secure Sockets Layer (SSL) Encryption
  • External or Internal Certs highly recommended
  • Protects Transport of content
  • 20% overhead on Web Servers
  • Can be offloaded via SSL offloaders if needed
  • Don’t forget for SPCA as well!
sharepoint security transport ipsec from server to server
SharePoint SecurityTransport – IPSec from Server to Server
  • By default, traffic between SharePoint Servers (i.e. Web and SQL) is unencrypted
  • IPSec encrypts all packets sent between servers in a farm
  • For very high security scenarios when all possible data breaches must be addressed
sharepoint security rights management active directory rights management services
SharePoint SecurityRights Management - Active Directory Rights Management Services
  • AD RMS is a form of Digital Rights Management (DRM) technology, used in various forms to protect content
  • Used to restrict activities on files AFTER they have been accessed:
    • Cut/Paste
    • Print
    • Save As…
  • Directly integrates with SharePoint DocLibs
for more information
For More Information
  • SharePoint 2010 Unleashed from SAMS Publishing (http://www.samspublishing.com)
  • Windows Server 2008 R2 Unleashed and/or Hyper-V Unleashed (http://www.samspublishing.com)
  • Microsoft ‘Virtualizing SharePoint Infrastructure’ Whitepaper (http://tinyurl.com/virtualsp)
  • Microsoft SQL Mirroring Case Study (http://tinyurl.com/mirrorsp )
  • Failover Mirror PowerShell Script (http://tinyurl.com/failovermirrorsp )
  • SharePoint Kerberos Guidance (http://tinyurl.com/kerbsp)
  • SharePoint Installation Scripts (http://tinyurl.com/SPFarm-Config)
  • Contact us at CCO.com
thanks for attending questions
Thanks for attending!Questions?

Michael Noel

Twitter: @MichaelTNoel

www.cco.com

Slides: slideshare.net/michaeltnoel

enrol in microsoft virtual academy today
Enrol in Microsoft Virtual Academy Today

Why Enroll, other than it being free?

The MVA helps improve your IT skill set and advance your career with a free, easy to access training portal that allows you to learn at your own pace, focusing on Microsoft technologies.

  • What Do I get for enrolment?
  • Free training to make you become the Cloud-Hero in my Organization
  • Help mastering your Training Path and get the recognition
  • Connect with other IT Pros and discuss The Cloud

Where do I Enrol?

www.microsoftvirtualacademy.com

Then tell us what you think. TellTheDean@microsoft.com

slide62

© 2010 Microsoft Corporation. All rights reserved. Microsoft, Windows, Windows Vista and other product names are or may be registered trademarks and/or trademarks in the U.S. and/or other countries.

The information herein is for informational purposes only and represents the current view of Microsoft Corporation as of the date of this presentation. Because Microsoft must respond to changing market conditions, it should not be interpreted to be a commitment on the part of Microsoft, and Microsoft cannot guarantee the accuracy of any information provided after the date of this presentation. MICROSOFT MAKES NO WARRANTIES, EXPRESS, IMPLIED OR STATUTORY, AS TO THE INFORMATION IN THIS PRESENTATION.

(c) 2011 Microsoft. All rights reserved.

resources
Resources
  • www.msteched.com/Australia
    • Sessions On-Demand & Community
  • www.microsoft.com/australia/learning
  • Microsoft Certification & Training Resources
  • http:// technet.microsoft.com/en-au
    • Resources for IT Professionals
  • http://msdn.microsoft.com/en-au
    • Resources for Developers

(c) 2011 Microsoft. All rights reserved.
